Summary of Contents for Linn Majik 109
- Page 1 MAJIK 109 LOUDSPEAKER OWNER’S MANUAL...
-
Page 3: Important Safety Instructions
Replace the mains fuse in the plug with one of the same type and rating. • Disconnect supply cord before changing fuse. WARNING To reduce the risk of fi re or electric shock do not expose this apparatus to rain or moisture. Shock hazard - do not open. Majik 109... -
Page 4: General Safety Instructions
23. The apparatus has been designed for use in moderate and tropical climates. 12. Use only with the stand, tripod, bracket, or table specifi ed by the manufacturer, or sold with the apparatus. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. Majik 109... -
Page 5: Ce Declaration Of Conformity
CE Declaration of Conformity FCC notice Linn Products Ltd declare that this product is in conformance with the Low Voltage Note: This equipment has been tested and found to comply with the limits for Directive 73/23/EEC and Electromagnetic Compatibility 89/336/EEC as amended a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 6 The content of this manual is furnished for information use only, is subject to change without notice, and should not be construed as a commitment by Linn If you wish to dispose of this product and the product still functions, please Products Limited.
-
Page 7: Table Of Contents
CONTENTS INTRODUCTION INSTALLATION Unpacking Cleaning Accessories Positioning and levelling Positioning Levelling Connecting General Terminals Confi guration options Wiring and amping confi gurations TECHNICAL SPECIFICATIONS GUARANTEE AND SERVICE Majik 109... -
Page 9: Introduction
fl exibility to meet your future requirements. Majik 109 loudspeakers are the perfect partner for any of the fantastic products in Linn’s Majik range. Whether as part of a compete Majik system or as the loudspeakers in your current hi-fi... -
Page 10: Installation
Unpacking Cleaning The Majik 109 loudspeakers come packaged as a pair; take care when removing Remove dust and fi ngerprints from the cabinets with a soft, dry, lint-free cloth. them from their packaging to avoid damage to the cabinets. Do not lay the Avoid using domestic cleaning products as they may damage the veneer. -
Page 11: Positioning And Levelling
Positioning and levelling To get the best from your Linn Majik 109 loudspeakers, it is important they are positioned and levelled correctly. The acoustics of a room are dependent on many factors, including volume, shape and furnishings. The information below will assist in helping you fi... -
Page 12: Connecting
Terminals The Majik 109 loudspeakers are fi tted with 4mm socket terminals. These terminals can be used as sockets for the connection of 4mm banana plugs or appropriate spade terminated cables. To connect spade-terminated cables, loosen the gold collar with the provided spanner, insert the spade behind the gold collar, and fi... -
Page 13: Confi Guration Options
Confi guration options Aktiv operation The Majik 109 loudspeakers offer an array of confi guration options, as described The term ‘Aktiv’ refers to the proprietary Linn active crossover and loudspeaker below. Connections for each of the methods are shown in the Wiring and amping confi... -
Page 14: Link Strip Information
When multi-amping, ensure that the link plates do not short-circuit amplifi er channels together. Shorting the outputs of separate amplifi er channels together can damage the amplifi er(s) and the loudspeaker drive units. • Do not connect more than one strip per terminal. Majik 109... -
Page 15: Wiring And Amping Confi Gurations
Illustration shows position of link strips if bi-wiring (i.e. using two speaker cables from one power amplifi er channel) or bi-amping (i.e. using two power amplifi er channels). For optimum sound quality, connect the cables from the power amplifi er(s) to the terminals shown. Majik 109... - Page 16 Aktiv confi guration IMPORTANT NOTES ON AKTIV SYSTEMS Aktiv operation requires a modifi cation to your Majik 109s and your Linn amplifi ers, Do not use your amplifi ers with any other loudspeakers – which must be carried out by an authorised Linn retailer.
-
Page 17: Technical Specifications
TECHNICAL SPECIFICATIONS Three-way, bass refl ex, bookshelf loudspeaker incorporating the Linn 2K Ar- ray and a 5” bass driver. Cabinet volume 9 litres Impedance (passive) 4 Ω Impedance (Aktiv bass/mid) 7 Ω Impedance (Aktiv tweeter) 7 Ω Impedance (Aktiv super-tweeter) 7 Ω... -
Page 18: Guarantee And Service
In addition to any statutory Phone: +44 (0)141 307 7777 rights you may have, Linn undertake to replace any parts which have failed due Fax: +44 (0)141 644 4262 to faulty manufacture. To help us, please ask your Linn retailer about the Linn Helpline: 0500 888 909 warranty scheme in operation in your country. - Page 20 Pack 1451...
