INSTALL AND CALIBRATE THE HINGES

(Supplied when purchasing the optional dust cover)
•
Locate the hinges in the lower section of the packaging and the appropriate allen key (3/32") from
the tool kit.
•
Mount the hinges to the plinth and do not tighten the screws completely. Make sure the dust
cover slots line up correctly with each other before the final tightening.
•
Install the dust cover by sliding it in the hinges slot.
Note: If the dustcover can not be lifted totally open in its playing area, it is possible to change the
spring tension of the hinges. The tension has been
pre-adjusted on both hinges at the factory to its best
performance.

INSTALL THE RECORD CLAMP

•
Tighten the clamp so the record is pushed flat against the mat.
Note: Damages may occur to your albums when over tightening the record clamp.
