Xceltronix Autocloser Installation Manual And User's Manual page 9

2. Connect power to the Autocloser. The Autocloser uses a 110 Volt AC / DC power
adapter. Attach each power wire to one of the screw terminals on the power adapter
(Fig. 2-1). Either wire may be attached to either terminal.
Unscrew the center screw on the plate of the household receptacle that you will be using
to power the Autocloser. With the plate held in position, plug the Autocloser power
adapter into the receptacle. Use the receptacle plate screw to screw down the adapter tab
(Fig. 2-2) .
Screw down
the adaptor
tab with the
receptable
plate center
screw.
Fig. 2-2
9
Bundle
wires with
twist tie.
