Garage door opener

power head assembly

The reflector should be
as low as the bottom of
Fig. 1-2
the garage door opener
power head assembly
1b. Attach reflective conspicuity tape to reflector plate. Peel off adhesive backing from the
conspicuity tape and affix to side of reflector plate facing the Autocloser unit. Tape should be
aligned to cover most of the rectangular portion of reflector plate (Fig. 1-3).
NOTE: Conspicuity tape is a special form of reflective tape which will improve the reflective
characteristics of the plate. The application of this tape will simplify the installation and en-
hance the performance of the unit.
Reflector
Conspicuity Tape
Fig. 1-3
8
