Xceltronix Autocloser Installation Manual And User's Manual page 10

!!! WARNING !!!
THE POWER ADAPTER MUST BE SCREWED DOWN TO PREVENT THE
ADAPTER FROM BEING ACCIDENTALLY UNPLUGGED. THIS ADAPTER IS
HEAVY AND CAN CAUSE BODILY INJURY IF IT HITS SOMEONE!!! Bundle ex-
cess wire in a roll and apply a twist tie, to prevent it from hanging down and becoming an
obstruction.
3. Determine the Autocloser mounting location. The Autocloser uses an infrared
emitter/detector to determine the position of the garage door. Note the position (Fig.
3-1) of the infrared sensors. To ensure correct operation, the Autocloser unit must
be no more than 36 inches from the reflector plate when the door is fully open.
Fig. 3-1
!!!!!!WARNING!!!!!!
10
Vent
Hole
Infrared
Sensors
