Mounting

This section outlines the various mounting options available for the MPA 401-70V:
•
•
•
•
•
•

Plenum Placement

The MPA 401-70V amplifier meets UL 2043 requirements for heat and smoke release. It
can be installed in the ceiling, out of sight, with reduced risk of theft.
CAUTION: Although the amplifier is plenum rated, the power supply provided with it

Tabletop Placement

Attach the four provided rubber feet to the bottom of the unit and place it in any
convenient location.
Plenum Placement
Tabletop Placement
Rack Mounting
Under-desk Mounting
Through-desk Mounting
Projector Mounting
is not. The power supply must not be placed in the plenum space. Cables
to and from the amplifier must also be plenum rated.
MPA 401-70V • Mounting 14
