- Page 1 User Manual...
-
Page 2: Table Of Contents
General Troubleshooting ................14 Contact Procedure ..................15 CHAUVET® Contact Information ..............15 Returning Products to CHAUVET® ..............15 DMX Primer ..................... 16 6. Technical Specifications ..............20 Page 2 of 20 Obsession™ LED 2.0 User Manual (Rev. 03) -
Page 3: Before You Begin
For other issues such as missing components or parts, damage not related to shipping, or concealed damage, file a claim with CHAUVET® within seven (7) days of receiving the merchandise. Convention... -
Page 4: Product At A Glance
Use on Dimmer Auto Programs Product at a Outdoor Use Auto-ranging Power Supply Glance Sound Activated Replaceable Fuse User Serviceable Master/Slave Duty Cycle Safety Notes Please read the following Safety Notes carefully before working with this product. They include important safety information about its installation, usage, and maintenance. -
Page 5: Introduction
2. I NTRODUCTION Product Overview DMX In DMX Out Safety Loop Microphone Sensitivity Knob Fuse holder Microphone Power Out Power In Obsession™ LED 2.0 User Manual (Rev. 03) Page 5 of 20... -
Page 6: Product Dimensions
Product Dimensions Page 6 of 20 Obsession™ LED 2.0 User Manual (Rev. 03) -
Page 7: Setup
3. S ETUP This product has an auto-ranging power supply and can work with an input voltage AC Power range of 100~240 VAC, 50/60 Hz. To determine the power requirements for this product (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 8: Power Linking
Power Linking This product provides power linking via the IEC outlet located in the back of the unit. Please see the diagram below for further explanation. Power Linking Diagram Product Product Product Other products You can power link up to 37 Obsession™ LED 2.0 units on 230 VAC. Page 8 of 20 Obsession™... -
Page 9: Mounting
Mounting Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes section (page 2 of this manual). Orientation The Obsession™ LED 2.0 may be mounted in any position; however, make sure adequate ventilation is provided around the product. ... -
Page 10: Operation
4. O PERATION To access the control panel functions, use the four buttons located underneath the Control Panel display. Please refer to the Product Overview (page 5) to see the button locations on the Operation control panel. Button Function Press to find an operation mode or to back out of the current menu <MENU>... -
Page 11: Configuration (Standalone)
Configuration Set this product in one of the standalone modes to control without a DMX controller. 1. Connect the product to a suitable power outlet. (Standalone) 2. Turn the product on. Never connect a product that is operating in any standalone mode, whether Static, Automatic, or Sound to a DMX string connected to a DMX controller. -
Page 12: Master/Slave Mode
Master/Slave This mode allows a single Obsession™ LED 2.0 unit (the “master”) to control the actions of one or more Obsession™ LED 2.0 units (the “slaves”) without the need of a DMX Mode controller. The master unit will be set to operate in either Automatic or Sound Active mode, while the slave units will be set to operate in Slave Mode. -
Page 13: Technical Information
5. T ECHNICAL NFORMATION Product Dust build up reduces light output performance and can cause overheating. This can lead to reduction of the light source’s life. To maintain optimum performance and Maintenance minimize wear, you should clean your lighting products at least twice a month. However, be aware that usage and environmental conditions could be contributing factors to increase the cleaning frequency. -
Page 14: General Troubleshooting
Terminator not connected Install a terminator, as indicated in the DMX Primer section. If you still experience problems after trying the above solutions, contact CHAUVET® Technical Support. Page 14 of 20 Obsession™ LED 2.0 User Manual (Rev. 03) -
Page 15: Contact Procedure
If you live in the UK or Ireland, contact CHAUVET® Europe Ltd.(see below). If you live in any other country, DO NOT contact CHAUVET®. Instead, contact your distributor of record. Refer to our Web site for contact details of distributors outside the US, United Kingdom, or Ireland. -
Page 16: Dmx Primer
DMX Primer The DMX protocol (USITT DMX512-A) is a networking protocol that enables a Introduction universal DMX controller device to control the features of multiple DMX compatible fixtures, whether PAR cans, wash lights, moving heads, followspots, foggers, or proprietary fixture controllers, etc. As any other networking protocol, the USITT DMX512-A describes the physical medium, the signals, and the functions they control. - Page 17 The DMX fixture configuration consists in determining how many channels DMX Configuration each fixture will need as well as assigning the corresponding DMX channels to each fixture in order to size correctly the DMX controller. Personalities A DMX personality describes what channel or channels control which fixture parameters.
- Page 18 DMX Data Cabling You must use DMX compliant data cables to link two or more DMX compatible fixtures. You may purchase CHAUVET® certified DMX cables directly from a dealer/distributor or construct your own cable. USITT recommends limiting the total length of the DMX cable (from the first fixture/controller to the last fixture) to 300~455 m (985~1,500 ft).
- Page 19 (DMX Connectivity cont.) Test all DMX cables with an ohmmeter to verify their correct polarity and to make sure that there are no short-circuits between any of the pins, or between any pin and ground. If the common wire (shield) touched the chassis ground, a ground loop could form, which may cause the fixture to perform erratically.
-
Page 20: Technical Specifications
6. T ECHNICAL PECIFICATIONS Dimensions and Length Width Height Weight Weight 202 mm 236 mm 178 mm 2.3 kg Note: Dimensions in inches rounded to the nearest decimal digit. Power Power Supply Type Range Voltage Selection Switching (internal) 100~240 V, 50/60 Hz Auto-ranging Parameter 230 V, 50 Hz...
