Chauvet CH-219 User Manual

Troubleshooting
If the unit is not functional - check main power supply is 'on' and check fuses.
If the unit is functional but lamp does not light - lamp may require replacing.
If the unit lights but will not move - check mode selector switch.
If after trying this solution you still have a problem contact CHAUVET.
Caution
Do not obstruct the air vents.
Do not touch unit or lamps while hot.
No user serviceable parts inside. Please refer to CHAUVET for service.
Power Connections
The unit is supplied with a power plug appropriate to its voltage and destination. Should any other connec-
tions be required they must be carried out with the following configuration.
Earth = Green/Yellow cable
Neutral = Blue cable
Live = Brown cable
In the USA& Europe, it is required that all plugs are 3-pin type i.e. with Earth/Ground connection.
In the UK, it is required that all mains plugs are fitted with 5Afuses.
Technical Specifications
Power
120V~60Hz AC
Fuse 20mm Glass 2AFast Blow
1 x 12v 100W
Lamps
Part No EFP 12V 100W
Dimensions
235 x 200 x 120mm / 9.3 x 7.9 x 4.7in
Weight 3.2kg / 7.1lbs
User Informtion (Please complete for your records)
Date Purchased: / /
Dealer Stamp:
230V~50Hz AC
20mm Glass 1AFast Blow
1 x 12v 100W
Part No EFP 12V 100W
235 x 200 x 120mm / 9.3 x 7.9 x 4.7in
3.2kg / 7.1lbs
Serial No: ________________
Model: CH-219 Obsession
Obsession
CH-219
User Guide
Please read these instructions carefully before use
World-wide Headquarters:
3000 North 29th Ct., Hollywood, Florida, USA, FL 33020
Tel: +1-954-929-1115 Fax: +1-954-929-5560
www.ChauvetLighting.com
