Alto MISTRAL400 User Manual

Stereo power amplifier
Hide thumbs

Advertisement

Quick Links

Download this manual
User's Manual
MISTRAL400
STEREO POWER
AMPLIFIER
R
LTO
www.altoproaudio.com
Version 1.1 MAY 2005
English

Advertisement

loading
Need help?

Need help?

Do you have a question about the MISTRAL400 and is the answer not in the manual?

Questions and answers

Related Manuals for Alto MISTRAL400

Summary of Contents for Alto MISTRAL400

  • Page 1 User's Manual MISTRAL400 STEREO POWER AMPLIFIER www.altoproaudio.com Version 1.1 MAY 2005 English...
  • Page 2 SAFETY RELATED SYMBOLS Never cut off the internal or external protective grounding wire or disconnect the wiring of protective grounding terminal. CAUTION RISK OF ELECTRIC SHOCK Operating Conditions DO NOT OPEN This apparatus shall not be exposed to dripping or spl- The symbol is used to indicate that some hazard- ashing and that no objects filled with liquids, such as ous live terminals are involved within this apparatus,...
  • Page 3 LTO MISTRAL400 Stereo Power Amplifier is the result of many hours of listening and tests involving common people, area experts, musicians and technicians.The result of this effort is the sophisticated circuit design featuring high power and superb quality together with superiorreliability and stability to provide the highest possible audio performance.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS 1. INTRODUCTION............................4 2. FEATURES .............................4 3. CONTROL ELEMENTS ..........................5 3.1 The Front Panel 3.2 The Rear Panel 4. APPLICATION ............................7 4.1 Stereo Mode 4.2 Bridge Mode 5. TECHNICAL SPECIFICATIONS ....................

  • Page 5: Introduction

    1. INTRODUCTION MISTRAL400 is a line of high power, low profile, professional Power Amplifiers with advanced features and great reliability. They deliver tremendous power in only one rack space, providing high level performance under the most demanding conditions. The amplifier frame contains all solid-state circuitry, using complementary silicon output devices.

  • Page 6: Control Elements

    CONTROL ELEMENTS 3.1 Front Panel Power Switch Turn the unit power on or off. Clip LED When the signal distortion reaches or surpasses 0.5%, the LED lights up. This means the output level of signal source is too high and it is time to reduce input level until clip LED turning off. Output Limiter LED While the unit is limiting the output signal, the LED lighting up.
  • Page 7 Fuse Holder / Voltage Selector This is a dual voltage unit. Before you attempt to connect and operate the unit, please make sure that your Local voltage matches the voltage on the fuse holder cover. Caution: The fuse protecting the AC supplies circuits of this unit. The fuse can only be changed by a qua- lified technician, in the event of a fault or changing the supply voltage.

  • Page 8: Bridge Mode

    4. APPLICATION Total two optional modes: Please see following diagram for connecting the power amplifier into your audio system. 4.1 Stereo Mode In this mode, Channel 1 and Channel 2 operate independently ( just as traditional stereo amplifier). The signal input into channel 1 can be output from channel 1 only, similarly, the signal input into channel 2 can be output from channel 2 only.
  • Page 9 4.2 Bridge Mode In this mode, the signal input into channel 1 will be output from the bridged end, on other hand, the output level control of channel 2 should be turn down to smallest (turn the volume control at counterclockwise). Only the volume control of channel 1 is used to control the volume of whole system.

  • Page 10: Technical Specifications

    5. TECHNICAL SPECIFICATIONS MODEL MISTRAL400 Output Power 20Hz 20KHz@0.1%THD, Stereo Mode 8 ohms per channel(EIAJ) 4 ohms per channel(EIAJ) 100W Bridge Mono Mode 8 ohms, 1KHz, 0.1%THD 180W Distortion (SMPTE-IM) <0.05% Frequency Response 20Hz-20KHz+0.1/ -3dB Damping Factor, 1 kHz and below >300 at 8ohms...

  • Page 11: Warranty

    6. WARRANTY 1. WARRANTY REGISTRATION CARD To obtain Warranty Service, the buyer should first fill out and return the enclosed Warranty Registration Card within 10 days of the Purchase Date. All the information presented in this Warranty Registration Card gives the manufacturer a better understanding of the sales status, so as to purport a more effective and efficient after-sales warranty service.
  • Page 12 No. 1, Lane 17, Sec. 2, Han Shi West Road, Taichung 40151, Taiwan http://www.altoproaudio.com Tel: 886-4-22313737 email: alto@altoproaudio.com Fax: 886-4-22346757 All rights reserved to ALTO. All features and content might be changed without prior notice. Any photocopy, translation, or reproduction of part of this manual without written permission is forbidden. Copyright 2005 SEIKAKU GROUP NF02036-1.1...
