American Standard Virtuoso 7236.028WC Specification Sheet

VIRTUOSO™ WHIRLPOOL
❏ 7236.028WC Whirlpool featuring System II
• Acrylic with fiberglass reinforcement
• EverClean System
®
• Pre-leveled tub bottom
• Two person design with center drain and dual
lumbar ends
• Wave style grab bar
• 2.1 HP, two speed, self-draining pump/motor
with pulse feature
• Factory installed power cord and plug
• Ten multi-directional and flow-adjustable
jets including:
- Two Ideal-flow jets
- Six body massage jets
- Two recessed back-rest jets
• Deck-mounted electronic control with 20 minute
built-in timed safety shut off and Chrome Bezel
• Three silent air volume controls
• Quick Connect Safe-T-Heater
connection system
• Factory installed and tested whirlpool system
Nominal Dimensions:
1829 x 914 x 540mm
(72" x 36" x 21-1/4")
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
American Standard whirlpools and air baths with
EverClean incorporate a patented silver-ion
®
additive right into the circulation piping to protect
the pipes from mold, mildew, algae and fungus that
could cause deterioration or staining of the pipes.
SEE REVERSE FOR PRODUCT DIMENSIONS
AND SPECIFICATIONS
© 2008 AS America Inc.
To Be Specified - Required:
❏ Color:
❏ Bath Filler: (specify finish)
❏ Bath Drain: 1583.470 (specify finish)
To Be Specified - Optional:
❏ Safe-T-Heater*: 9075.120
❏ Symphony 6' Apron: 0727.200 (specify color)
❏ Universal Tile Bead Kit: 751755-100
❏ System II Control Bezel: 9861.100 (specify finish)
For color/finish availability and other faucet choices, please
see the Product Selector and Pricing Guide.
* NOTE: the Safe-T-Heater is designed to maintain water
temperature during operation. It will not heat cold water to
desired bathing temperature.
H41
VIRTUOSO™
WHIRLPOOL
HIGH GLOSS
Revised 2/08
