American Standard Lifetime 7236L Specification Sheet

LIFETIME™ 6' X 36"
Comfortable bathing design with form-fitted backrest
and molded-in armrests.
❏ Model# 7236L (specify color)
• Acrylic with fiberglass reinforcement
• Lifetime Overflow Drain for maximum
water depth
• 2.1 HP self-draining pump/motor
• Ten flow adjustable jets including:
Two adjustable Ideal Flow Comfort Jets™
Eight adjustable Comfort Jets™
• Three silent air volume controls
• Side-mounted On/Off control
• Complete factory installed and tested
whirlpool system
• Self leveling feet
• Designed with undermount installation option
❏
Model# 7236LC (specify color)
• Same as above with the EverClean™ whirlpool
system. The EverClean™ antimicrobial system
incorporates AlphaSan®, a patented
antimicrobial agent manufactured right into the
circulation system components, which
suppresses the growth of unsightly algae,
fungus, mold and mildew.
❏
Model# 7236L.002 Bathing Pool Only
Nominal Dimensions:
72" x 36" x 21-1/4"
(1829 x 914 x 540mm)
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
SEE REVERSE FOR ROUGHING-IN DIMENSIONS
AND PRODUCT SPECIFICATIONS
AlphaSan® is a registered trademark of Milliken & Co.
© 2007 American Standard Inc.
WHIRLPOOLS BY AMERICAN STANDARD
Components Required:
❏ Bath Filler*: (specify finish)
❏ Bath Drain: 1599.205.XXX (specify color)
OR 1599.500.020 (white only)
Custom Accessories Available:
❏ Six Foot Apron: 9271.019.XXX (specify color)
❏ E-Z-Install™ Whirlpool Heater - EZHEAT-100
❏ Tile Bead Kit: TILE-BEAD
* See American Standard Faucet Selector
For color/finish availability and other faucet choices, please
see the Product Selector and Pricing Guide.
NOTE: E-Z-Install™ Whirlpool Heater is designed to
maintain water temperature during operation. It will not heat
cold water to desired bathing temperature.
HD-3
LIFETIME™ 6' X 36"
HIGH GLOSS ACRYLIC
Revised 7/07
