American Standard 255.102 User Manual

INSTALLATION INSTRUCTIONS

Porcelain Enameled Steel Bathtubs
0255.102 New Salem Bathtub, RHO
0255.202 New Salem Bathtub, LHO
0263.102 New Solar AFR Bathtub, RHO
0263.202 New Solar AFR Bathtub, LHO
CAUTION: THIS NEW FIXTURE HAS A DURABLE FINISH; HOWEVER, EXTRA CARE SHOULD BE EXERCISED
!
DURING INSTALLATION WHEN ROUGH HANDLING AND THE DANGER OF DROPPED TOOLS
MAY CAUSE DAMAGE.
1
Check the tub thoroughly for
shipping damage, report any
apparent damage to the location
that furnished the tub and request
their advice on continuing with
the installation.
4
Locate the tub in position and mark
a joist so that a 2x4 stringer can be
nailed in place. The stringer will be
located under the flange against the
wall. Nail in place the 2x4 support.
Re-position the tub and check for
level, both front to back and left
to right.
CARE AND CLEANING
Clean with warm water, a soft cloth
and mild detergent. Never use
abrasive scouring powders,
cleansers or pads.
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2010
2
Protect this bathtub during
installation and construction by
using this corrugated container as
indicated. Cut along the dotted lines
and place the corrugated protector
over the top and front of the tub.
The center cut-out drops into the
center of the tub.
5
It may be necessary to shim the tub
to achieve a good level condition.
Only small shims should be used in
conjunction with the bathtub's own
support pad.
Note:There will be a small gap
between the apron panel and
the floor to allow for tile,
carpeting, etc. Caulking could
be used to seal this gap.
3
After measuring the dimensions of
the product, frame the construction
area.
6
Overflow and drain assembly,
faucet and the shower head
should be installed to the
manufacturers specifications.
Over-tightening the drain can
damage the tub.
STRINGER
791524-100
