Summary of Contents for Chauvet 4BAR Flex

  • Page 1 User Manual...

  • Page 2: Table Of Contents

    ABLE OF ONTENTS 1. Before You Begin................3 What Is Included ................... 3 Unpacking Instructions .................. 3 Claims ........................3 Text Conventions ..................3 Icons ......................3 Document Information ................... 3 Product at a Glance ..................4 Safety Notes ....................4 2.

  • Page 3: Before You Begin

    CHAUVET®. Failure to do so in a timely manner may invalidate your claim with the carrier. In addition, keep the container and all the packing material for inspection.

  • Page 4: Product At A Glance

    Product at a Use on Dimmer Auto Programs   Glance Outdoor Use Auto-ranging Power Supply   Sound Activated Replaceable Fuse   User Serviceable   Master/Slave Duty Cycle   Safety Notes Please read the following Safety Notes carefully before working with the product. The Notes include important safety information about installation, usage, and maintenance.

  • Page 5: Introduction

    2. I NTRODUCTION Product Overview Tripod Adjustment Knob Light Adjustment Knob (x 4) LED Display Power In DMX Out Fuse Holder DMX In Power Outputs for Additional Fixtures 4BAR™ Flex User Manual (Rev. 4) Page 5 of 16...

  • Page 6: Product Dimensions

    Product Dimensions Page 6 of 16 4BAR™ Flex User Manual (Rev. 4)

  • Page 7: Setup

    3. S ETUP AC Power The 4BAR™ Flex has an auto-ranging power supply and it can work with an input voltage range of 100~240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s Technical Specifications.

  • Page 8: Power Linking

    The power linking diagram shown above corresponds to the North American version of the product ONLY! If using the product in other markets, you must consult with the local CHAUVET® distributor as power linking connectors and requirements may differ in your country or region.

  • Page 9: Mounting

    Mounting Before mounting the product, read and follow the safety recommendations indicated in Safety Notes. Orientation The 4BAR™ Flex may be mounted in any position; however, make sure adequate ventilation is provided around the product. Rigging • Before deciding on a location for the product, always make sure there is easy access to the product for maintenance and programming purposes.

  • Page 10: Operation

    4. O PERATION Control Panel To access the control panel functions, use the four buttons located underneath the display. See the Product Overview to see the button locations on the control panel. Operation Button Function Press to find an operation mode or to back out of the current menu <MENU>...

  • Page 11: Dmx Channel Assignments And Values

    DMX Channel Assignments and Values 15-CH Channel Function Value Setting 000  009 RGB Color Mixing Mode 010  029 Auto Program 1 030  049 Auto Program 2 050  069 Auto Program 3 070  089 Auto Program 4 090 ...

  • Page 12: Configuration (Standalone)

    Configuration Set the product in one of the standalone modes to control without a DMX controller. Connect the product to a suitable power outlet. (Standalone) Turn the product on. Never connect a product that is operating in any standalone mode (either Automatic or Sound) to a DMX string connected to a DMX controller.

  • Page 13: Footswitch Operation

    Footswitch The included footswitch provides quick access to the preset colors, color change programs, and triggering via the onboard microphone on the 4BAR™ Flex: Operation Power on the fixture. Connect the footswitch to the 4BAR™ Flex via the 4-pin connection cable with plug. Press pedal #1 (Preset) to activate control.

  • Page 14: Technical Information

    5. T ECHNICAL NFORMATION Product Dust build-up reduces light output performance and can cause overheating. This can lead to reduction of the light source’s life and mechanical wear. To maintain optimum Maintenance performance and minimize wear, you should clean your lighting products at least twice a month.

  • Page 15: Contact Us

    If you live in the U.S., contact CHAUVET® World Headquarters (see below). • If you live in the UK or Ireland, contact CHAUVET® Europe Ltd. (see below). • If you live in any other country, DO NOT contact CHAUVET®. Instead, contact your distributor of record.

  • Page 16: Technical Specifications

    6. T ECHNICAL PECIFICATIONS Dimensions and Length Width Height Weight Weight 47.4 in (1,205 mm) 5.2 in (133 mm) 14.7 in (375 mm) 13.5 lbs (6 kg) Note: Dimensions in inches rounded to the nearest decimal digit. Power Power Supply Type Range Voltage Selection Switching (internal)
