Summary of Contents for Chauvet 4Bar
- Page 1 User Manual...
-
Page 2: Table Of Contents
Automatic Mode ..........................11 Master/Slave Mode ..........................11 Footswitch Operation ......................... 12 5. Technical Information ....................13 Product Maintenance ........................ 13 6. Technical Specifications ....................14 Returns ............................. 15 Contact Us ..........................15 Page 2 of 15 4BAR™ Tri User Manual Rev. 6... -
Page 3: Before You Begin
Failure to report damage to the carrier immediately may invalidate your claim. In addition, keep the box and contents for inspection. For other issues, such as missing components or parts, damage not related to shipping, or concealed damage, file a claim with CHAUVET® within 7 days of delivery. Convention Meaning Text 1–512... -
Page 4: Product At A Glance
This product is not intended for permanent installation. · Keep this User Manual for future use. If you sell the product to another user, be sure to give this document to the next owner. Page 4 of 15 4BAR™ Tri User Manual Rev. 6... -
Page 5: Introduction
LED Display Adjustment Knob Fuse Holder Microphone Back Panel View Clamp Hanging Bolts Pan Angle Adjustment Knobs (4) Footswitch Connection Tripod Insertion Point Tilt Angle Adjustment Knob Front View Dimensions 4BAR™ Tri User Manual Rev. 6 Page 5 of 15... -
Page 6: Setup
3. S ETUP AC Power The 4BAR™ Tri has an auto-ranging power supply and it can work with an input voltage range of 100~240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 7: Power Linking
Diagram Product Additional Products You can power link up to 8 4BAR™ Tri products on 120 VAC or up to 16 4BAR™ Tri products on 230 VAC. The power linking diagram shown above corresponds to the North American version of the product ONLY! If using the product in other markets, you must consult with the local CHAUVET®... -
Page 8: Mounting
Mounting Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes. Orientation The 4BAR™ Tri may be mounted in any position; however, make sure adequate ventilation is provided around the product. · Rigging Before deciding on a location, always make sure there is easy access to the product for maintenance and programming. -
Page 9: Operation
DMX mode uses. If you choose a starting address that is too high, you could restrict the access to some of the product’s channels. The 4BAR™ Tri uses up to 15 DMX channels in single DMX mode, which defines the highest configurable address to 498. -
Page 10: Dmx Channel Modes, Assignments, And Values
Green 4 Pod 4 000 ó 255 Blue 4 (0~100%) Blue 4 Channel Function Value Setting 3-CH 000 ó 255 0~100% 000 ó 255 0~100% Green 000 ó 255 0~100% Blue Page 10 of 15 4BAR™ Tri User Manual Rev. 6... -
Page 11: Standalone
Master/Slave The Master/Slave mode allows a single 4BAR™ Tri unit (the “master”) to control the actions of one or more 4BAR™ Tri units (the “slaves”) without the need of a DMX Mode controller. The master unit will be set to operate in either Automatic or Sound Active mode, while the slave units will be set to operate in Slave Mode. -
Page 12: Footswitch Operation
To use the footswitch: Power the product on. Connect the footswitch to the 4BAR™ Tri with the 4-pin connection cable with plug. Press pedal #1 (Preset) to activate control. When working, all the LEDs will light white, which is the first function of pedal #1. -
Page 13: Technical Information
When cleaning units with one or more movable mirrors, you should keep the contact with the mirror’s surface to a minimum to avoid scratching or damaging it. Always dry the external optics and transparent surfaces carefully after cleaning them. 4BAR™ Tri User Manual Rev. 6 Page 13 of 15... -
Page 14: Technical Specifications
Maximum External Temp. Cooling System 104° F (40° C) Convection I/O Connectors Connector Type Channel Range 3-pin XLR Sockets 3, 15 Ordering Product Name Item Code UPC Number 4BAR™ Tri 03030048 781462206413 Page 14 of 15 4BAR™ Tri User Manual Rev. 6... -
Page 15: Returns
U.S., United Kingdom, or Ireland. Outside the U.S., United Kingdom, or Ireland, contact your distributor and follow their instructions on how to return CHAUVET® products to them. Visit our website for contact details. Returns Call the corresponding CHAUVET® Technical Support office and request a Return Merchandise Authorization (RMA) number before shipping the product.
