GPS Motorcycle/Vehicle Tracker
USER MANUAL
(Model: MT113)
TOPTEN ELECTRONICS TECHNOLOGY LIMITED
Address: Room2007, Tower B, Gaoke Building, Tianhe North Road, Guangzhou, China.
Tel: (+86)20-38351400, 38351401 Fax: (+86)20-38351400
Website:http://www.t10.cn
Email:
sales@t10.cn
Version 1.0
(Date: Mar., 2011)
Advertisement
Table of Contents
Related Manuals for Topten MT113
Summary of Contents for Topten MT113
-
Page 1: User Manual
GPS Motorcycle/Vehicle Tracker USER MANUAL (Model: MT113) TOPTEN ELECTRONICS TECHNOLOGY LIMITED Address: Room2007, Tower B, Gaoke Building, Tianhe North Road, Guangzhou, China. Tel: (+86)20-38351400, 38351401 Fax: (+86)20-38351400 Website:http://www.t10.cn Email: sales@t10.cn Version 1.0 (Date: Mar., 2011) -
Page 2: Table Of Contents
MT113 GPS Motorcycle/Vehicle Tracker User Manual CONTENT Preface....................... 2 I. Features & Functions ..................3 II. How to Operate it ................... 4 Arm/Disarm by Phone Calling..............4 Arm/Disarm the System by SMS..............4 Check the location by Google Map’s URL............ 5 Authorize the Alarm-received Mobile ............ -
Page 3: Preface
MT113 GPS Motorcycle/Vehicle Tracker User Manual Preface MT113 GPS Motorcycle/vehicle tracker is the cost-effective solution for security & real-time tracking. It is specially used for motorcycle tracking because of its compact size and water-proof design. Read it Firstly: Please read this manual thoroughly before you use the device; please keep it for future reference. -
Page 4: Features & Functions
MT113 GPS Motorcycle/Vehicle Tracker User Manual I. Features & Functions 1. Track on command or by time interval via SMS/GPRS. 2. Arm/disarm by SMS or phone call. 3. Check the car’s real physical address (such as city name, street name..(need support of the TS01 or TS03 center);... -
Page 5: How To Operate It
MT113 GPS Motorcycle/Vehicle Tracker User Manual II. How to Operate it The default user password is 000000. If the user password is changed, user should send the SMS command with the new user password instead of 000000. XXX is the control code, all the letters must be capital letters or in small letters, command with mixed capital letter &... -
Page 6: Check The Location By Google Map's Url
MT113 GPS Motorcycle/Vehicle Tracker User Manual Check the location by Google Map’s URL SMS command: 000000MAP (or 000000map) Upon receiving the SMS command, the tracker will automatically send back the SMS including the Google map’s URL, user can use smart phone (GPRS data service is enabled) to open the URL link, the car’s location will be showed... -
Page 7: Check The Real Physical Address
MT113 GPS Motorcycle/Vehicle Tracker User Manual Check the Real Physical Address SMS command: 000000ADD (or 000000add) When user sends this SMS command to the tracker, the tracker will automatically send back the car’s real physical address (such as city name, street name) to your mobile by SMS. -
Page 8: Adjust The Sensitivity Of Motion Sensor
Once the original alarm is triggered, the MT113 tracker will be triggered also to send out alarm message. Page 7... -
Page 9: Other Sms Command List
MT113 GPS Motorcycle/Vehicle Tracker User Manual Other SMS Command List Note: ****** is user’s password and the default password is 000000. The tracker will only accept commands with the correct password. Functions SMS Command Example Track on Demand W******,000 W000000,000... - Page 10 MT113 GPS Motorcycle/Vehicle Tracker User Manual Remarks: When the tracker speeds higher than the preset value, it will send an SMS to the authorized phone number. XX is the preset value of speed and in 2 digits. =00 , to turn off this function =[01, 20] (unit: 10Km/h) In this example, when the tracker’s speed is over 80km/h, an SMS alarm will be sent out.
- Page 11 MT113 GPS Motorcycle/Vehicle Tracker User Manual W******,011,APN,Username, Set APN W000000,011,internet,web,gprs Password Remarks: If no APN username and password are required, just input APN only; APN defaulted as ‘internet’; APN + username + password should not over 49 characters. W000000,012, 220.121.7.89,8500...
- Page 12 MT113 GPS Motorcycle/Vehicle Tracker User Manual Remarks: Default time of the tracker is GMT, you can use this command to correct it to your local time. This command is for SMS display only. tracking only. T=0, to turn off this function.
-
Page 13: Alarm Types
MT113 GPS Motorcycle/Vehicle Tracker User Manual III. Alarm Types SOS Alarm In any condition, if the SOS button is pressed, it will trigger the SOS alarm. Shake Alarm In arming status, if the car/motorcycle is vibrated, it will trigger this alarm. -
Page 14: Installation
MT113 GPS Motorcycle/Vehicle Tracker User Manual IV. Installation Page 13... - Page 15 MT113 GPS Motorcycle/Vehicle Tracker User Manual Installation Steps: (1) Please read the manual carefully before installation. Please prepare a valid GSM SIM card with Caller ID Display & GPRS function; (2) Please use the screw driver to open the cover;...
-
Page 16: Specifications
MT113 GPS Motorcycle/Vehicle Tracker User Manual V . Specifications Working voltage: +5.3 ~+24VDC Power Consumption: Working current: 50mA; Peak current: 800mA; Inside Backup battery: Rechargeable 3.7V 800mAh Li-ion battery 80*58*22 Size of the main unit: (mm) Weight of the main unit: 90g Working temperature: -20 ~ 70℃... -
Page 17: Maintenance
MT113 GPS Motorcycle/Vehicle Tracker User Manual not in correct format; (3) The mailbox of the user’s mobile is full; (1) Please make sure there is no metal obstacles above the tracker. Please place the side with GPS antenna upside to the sky;...
