TRoUblEsHooTINg
sections
table of contents
Problem:
I am having difficulty setting up Wired Equivalent Privacy (WEP) security on my Belkin Router�
solution:
1 Log into your Router�
Open your web browser and type in the IP address of the Router� (The
Router's default is 192�168�2�1�) Log into your Router by clicking on the
"Login" button in the top right-hand corner of the screen� You will be asked
to enter your password� If you never set a password, leave the "Password"
field blank and click "Submit"�
Click the "Wireless" tab on the left of your screen� Select the "Encryption"
or "Security" tab to get to the security settings page�
2 Select "128-bit WEP" from the drop-down menu�
3 After selecting your WEP encryption mode, you can type in your
hex WEP key manually, or you can type in a passphrase in the
"Passphrase" field and click "Generate" to create a WEP key from
the passphrase� Click "Apply Changes" to finish� You must now set
all of your clients to match these settings� A hex (hexadecimal) key is
a mixture of numbers and letters from A-F and 0-9� For 128-bit WEP,
you need to enter 26 hex keys�
150N Wireless Router
1 2 3 4 5 6
For example:
C3 03 0f af 4b b2 C3 d4 4b C3 d4 E7 E4 = 128-bit key
4
Click "Apply Changes" to finish� Encryption in the Wireless Router is
now set� Each of your computers on your wireless network will now
need to be configured with the same security settings�
WaRNINg: If you are configuring the Wireless Router or Access Point from
a computer with a wireless client, you will need to ensure that security
is turned on for this wireless client� If this is not done, you will lose your
wireless connection�
Note to Mac users: Original Apple AirPort products support 64-bit
encryption only� Apple AirPort 2 products can support 64-bit or 128-bit
encryption� Please check your Apple AirPort product to see which version
you are using� If you cannot configure your network with 128-bit encryption,
try 64-bit encryption�
