Owner's Manual
Single-Phase 5kVA-6kVA
Intelligent True On-Line UPS Systems (Rackmount/Tower)
• Includes UPS system with internal battery system (5&6kVA), detachable PDU and detachable
parallel PDU modules (6kVA) • Rackmount and tower adaptable
SmartOnline™
Not suitable for mobile applications.
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2011 Tripp Lite. All rights reserved. SmartOnline is a trademark of Tripp Lite.
1
2
3
4
9
12
13
14
27
28
28

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SmartOnline 5kVA and is the answer not in the manual?

Questions and answers

Summary of Contents for Tripp Lite SmartOnline 5kVA

  • Page 1: Table Of Contents

    Optional Connection Manual Bypass Operation Operation Internal Battery Replacement Storage and Service Warranty and Warranty Registration 1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support Copyright © 2011 Tripp Lite. All rights reserved. SmartOnline is a trademark of Tripp Lite.
  • Page 2: Important Safety Warnings

    Battery Warnings • Connect only Tripp Lite battery modules (of the correct type and voltage) to your UPS power module’s external battery connector. • Batteries can present a risk of electrical shock and burn from high short-circuit current. Observe proper precautions. Do not dispose of the batteries in a fire.
  • Page 3: Mounting

    2-Post Mounting (Optional) To mount your 5kVA or 6kVA UPS in a 2-post rack, you must purchase a Tripp Lite 2-Post Rackmount Installation Kit (model: 2POSTRMKITHD, sold separately) for each power module and battery pack installed. See the Installation Kit’s owner’s manual for complete mounting instructions.
  • Page 4: Features

    Mounting Tower Mounting Mount all modules in an upright, tower position using included base stands. The user must determine the fitness of hardware and procedures before mounting. The UPS system is shipped with two sets of plastic feet and extensions that can be used to tower mount the 4U UPS and a 3U battery module (7U total).
  • Page 5 Features (Rear Panel) See “Features” section for feature descriptions SU5000RT4UHV—5kVA UPS System ACC. SLOT RS-232 PARALLEL RS-232 BREAKER 20A AC INPUT OUTPUT 2 OUTPUT 1 200-240Vac 200-240Vac SU6000RT4UHV—6kVA UPS System with NEMA PDU ACC. SLOT RS-232 PARALLEL RS-232 NORMAL PASS SU6000RT4UHVHW—6kVA UPS System with Hardwire PDU ACC.
  • Page 6 Features (Rear Panel) (continued) See “Features” section for feature descriptions SU6000RT4UHVG—6kVA UPS System with IEC PDU RS-232 PARALLEL RS-232 NORMAL PASS SU12KRT4UHW—12kVA UPS System and Parallel PDU Modules Note: See the manual included with the Parallel PDU for 12kVA installation, configuration and setup instructions. RS-232 PARALLEL RS-232...
  • Page 7 Features (Rear Panel) (continued) See “Features” sectiion for feature descriptions SU6000RT4UTFHW—6kVA UPS with Hardwire PDU and 6kVA Isolation Step Down Transformer (SU6000XFMR2U) ACC. SLOT RS-232 PARALLEL RS-232 NORMAL PASS SU6000RT4UTF—6kVA UPS with NEMA PDU and 6KVA Isolation Transformer ACC. SLOT RS-232 PARALLEL RS-232...
  • Page 8 AC Input Cord: Connects directly to wall receptacle providing 200-240V AC utility power. External Battery Connector: Use this to connect one or more Tripp Lite battery modules to the power module. Remove the cover for access. The power module will not start without a connection to a charged battery module. Refer to the battery module Owner’s Manual for connection instructions and safety warnings.
  • Page 9: Connection

    Connection Note: The output voltage is set at 208~(default) by the manufacturer. If you need to change the output voltage of the UPS, refer to “Output Voltage Selection” in the “Operation” section. You should select the correct output voltage before connecting your equipment to the UPS.
  • Page 10 Connection (continued) Terminal Strip Connection—IEC PDU Module (SU6000RT4UHVG) Maximum Rated Model Input Voltage Typical Wire Size Input Current SUPDMB6KIEC 200~240V (L-N) 8 mm2 Unscrew 3 screws to remove the terminal strip cover and slide out as seen in diagram 1. Connect the L1, L2 and Ground wires (Hardwire-In, Receptacle-Out) according to markings on the connectors as seen in diagram 2.
  • Page 11 Connection (continued) Connect the 2 sets of L1, L2 and Ground wires (1 Input, 1 Output) according to markings on the connectors as seen in diagram 2. Be sure to connect one set of wires to the input terminals and the other set to the output terminals. Slide in and reattach the terminal strip cover with the 3 screws from Step 1.
  • Page 12: Optional Connection

    USB position. Enabling this module disables the RS-232 port. The RS-232 port is also disabled with the installation of an optional SNMP/Web card (Tripp Lite part # SNMPWEBCARD). The SNMP/Web card can be used simultaneously with the USB communication module.
  • Page 13: Manual Bypass Operation

    Hot-Swap Power Module Replacement* WARNING! For qualified service personnel only. Failure to follow the bypass procedure completely will not adequately power down the UPS, resulting in the continued risk of death or injury from pontential contact with high voltage. The UPS and detachable PDU are extremely heavy.
  • Page 14: Operation

    Operation LED Display Information Bypass Mode: AC input voltage in a Economy Mode: AC input voltage in a ONLINE Mode: AC input voltage in range of: -20 to +15% of the rating range between -10 and +10% of rating normal range: 156-280V. voltage;...
  • Page 15 Operation (continued) Startup Self-Test When you turn the UPS ON, it will enter Diagnostic Mode and perform a brief self-test lasting about 15 seconds. The results of the self-test are shown on the LCD screen in the sequence below. STARTED WITH COLD AC INPUT START*...
  • Page 16: Normal Operation

    Operation (continued) Normal Operation During normal operation, the first line of your LCD Display shows which operating mode your UPS is in: Online Mode, Economy Mode, Frequency Conversion Mode, Battery Mode, Bypass Mode or Parallel Mode (12kVA model only). Online Mode: The UPS provides AC power while utility power is available and switches to On Battery Mode instantly (zero transfer time) if AC power is interrupted.
  • Page 17: Ups Setup Menu

    Operation (continued) Normal Operation Display Information Parallel Mode (12kVA model only): PARALLEL MODE 00.00KW / 000%   NOTE: When two units are connected in parallel, the PARALLEL: MASTER “Master UPS” will display “PARALLEL: MASTER” in 00.00KVA / 000% this second screen. The display on the “Secondary ...
  • Page 18 Operation (continued) Changing the Password To change the password, scroll DOWN from the SETUP MENU screen to the BASIS SETTING screen. From here, press ON for the CHANGE PASSWORD screen. From this screen press ON and follow the previously described actions to set your password. When set, press ON to move to the SAVING screen.
  • Page 19 Operation (continued) Start Settings The UPS can start up through the battery without AC power. The DEFAULT is ENABLE. When the UPS switches to battery it can AUTO RESTART to work in an On-Line Mode when AC power is restored. DEFAULT is ENABLE. From the SETUP MENU screen, scroll DOWN to the START SETTING screen.
  • Page 20: Battery Settings

    Operation (continued) Battery Settings used to set the time period for discharge tests. From the SETUP MENU screen, scroll DOWN until you reach the Discharge Test: BATTERY SETTING screen. Press ON for the DISCHARGE TEST screen. Here, press ON. Now you can scroll DOWN or UP between NO TEST, 30, 60, 90 days and QUICK TEST.
  • Page 21 Operation (continued) Output Settings Note: Any Output Setting changes require a UPS power cycle. used to set the UPS’ output voltage rating. From the SETUP MENU screen, scroll DOWN until you reach the Output Voltage: OUTPUT SETTING screen. Press ON to reach an OUTPUT VOLTAGE screen and ON again. You can now scroll DOWN or UP between 5 voltage values: 200/208/220/230/240V.
  • Page 22 Operation (continued) Output Settings used to set the UPS’s ability to work in the energy saving Economy Mode. When input voltage is in a + or - range of ECO Mode: 10% of the overall voltage rating, the UPS will transfer into an Economy Mode to improve the efficiency of the UPS. From the SETUP MENU screen, scroll DOWN until you reach the OUTPUT SETTING screen.
  • Page 23 Operation (continued) UPS Alarm Log UPS ALARM LOG READ FROM MEMORY 1 65535 HH:MM:SS DOWN DOWN NO HISTORY      To ENTER  2 65535 HH:MM:SS NO HISTORY   3 65535 HH:MM:SS NO HISTORY   4 65535 HH:MM:SS NO HISTORY ...
  • Page 24 Operation (continued) Self Diagnosis Information When starting with AC power, you will see the following sequence display: DIAGNOSTIC MODE FREQ OUT = 50Hz  DIAGNOSTIC MODE INPUT 000V / 00Hz  DIAGNOSTIC MODE RECTIFIER OK  DIAGNOSTIC MODE CHARGER OK ...
  • Page 25 Operation (continued) UPS Fault Shutdown Messages CONDITION LCD DISPLAY MESSAGES +BUS >450V + DC BUS HIGH SHUTDOWN Load <100%: +BUS < 320V; Load >100%: +BUS + DC BUS LOW SHUTDOWN <290V -BUS >450V - DC BUS HIGH SHUTDOWN Load <100%: -BUS <320V; Load >100%: -BUS <290V - DC BUS LOW SHUTDOWN BUS Voltage Over 500 BUS OVP FAIL SHUTDOWN...
  • Page 26: Shutdown Messages

    Operation (continued) Shutdown Messages Your UPS will shut down and the LCD will display a message if it detects one of the following conditions. Note: During all these conditions, the “Input,” “Output” and “Bypass” LEDs will be illuminated. SHUTDOWN LCD DISPLAY CONDITIONS MESSAGES Extended...
  • Page 27: Internal Battery Replacement

    Internal Battery Replacement Under normal conditions, the original batteries in your UPS will last many years. See Safety section before replacing batteries. The batteries are designed for hot-swap replacement (i.e. leaving the UPS ON), but some qualified service personnel may wish to completely turn the UPS OFF and disconnect equipment before proceeding.
  • Page 28: Storage And Service
