NEC MultiSync LCD1560VM User Manual page 8

NOTE: This LCD monitor is designed for use with a flexible arm. Please use the attached screws (4pcs) when mounting.
To meet the safety requirements the monitor must be mounted to an arm which guaranties the necessary stability
under consideration of the weight of the monitor. The LCD monitor shall only be used with an approved arm (e.g.
GS mark).
4 SCREWS
(MAX depth: 8.6 mm)
If use other screw,
check depth of hole.
Figure R.4
Replace screws
75 mm
Weight of LCD assembly: 3.5kg (MAX)
English-7
Thickness of bracket (arm)
2.0 ~ 3.2 mm
Tighten all screws
75 mm
