- Page 1 RANGEMASTER REFRIGERATED WINE STORAGE UNIT Installation Operation Maintenance Instructions Refrigerated Wine Storage Unit with Sentry System™ Refrigeration Monitor RWS38 RWS60DX RDZ60 Note: This appliance is intended to be used exclusively for the storage of wine.
-
Page 2: Table Of Contents
Installing your wine storage unit........3 Selecting the location..........3 Cabinet Clearances ............3 Leveling legs ..............3 Electrical Connection...........4 Using Your Sentry System™ Control RWS38 & RWS60DX ..............5 Using Your Sentry System™ Control RDZ60.....6 Dimensions for RWS38 ..........7 Recommended Rough in Opening Dimensions for RWS38 ..............7... -
Page 3: Unpacking Your Wine Storage Unit
It is important to register your product as soon as possible after taking delivery of your wine storage unit. You can reg- WARNING- Hazards or unsafe practices which could ister online at www.rangemaster.co.uk. result in personal injury. The following information will be required when registering your unit. -
Page 4: Installing Your Wine Storage Unit
flow into and exit from the refrigerator condenser. For this reason it is important this area to not be obstructed and be kept clean. Rangemaster does not recom- mend the use of custom made grilles as air flow may be... -
Page 5: Electrical Connection
ELECTRICAL CONNECTION Electrical Connection 13A must be used and fitted with a 13A fuse “ASTA” ap- Use nominal 230 VAC, 50 Hz only. proved to BS 1363. If you replace the fuse, the cover must be refitted. If the cover is lost, the plug must not be used until a replacement has been obtained from your supplier. -
Page 6: Using Your Sentry System™ Control Rws38 & Rws60Dx
USING YOUR Sentry System™ CONTROL, MODELS RWS38 & RWS60DX Sentry System™ Warmer °F/C Power Failure - Flashing Amber High/Low Temp - Red Press ON/OFF - Reset Figure 3 Colder Light Alarms OFF - Steady Amber Press and Hold Door Ajar Alarm Start Your Appliance If the door has been left open for over five (5) minutes, the... -
Page 7: Using Your Sentry System™ Control Rdz60
USING YOUR Sentry System™ CONTROL MODEL RDZ60 Lower Upper Sentry System ™ OFF Door Ajar Warmer ˚F/C Figure 4 Power Failure <SET> Hi / Low Temp Upper Colder Light Hi / Low Temp Lower Press ON/OFF to Reset Press and Hold mode, the lights will be on whether or not the door is open. -
Page 8: Dimensions For Rws38
Max noise level 48 db(A) 538mm 76 to 102mm ROUGH IN OPENING DIMENSIONS, FOR RWS38 Electrical Requirements: 230 volts, 1.7 amps running maximum. A three pin earthed recep- tacle is required. Power outlet can be located in the back wall be- hind unit. -
Page 9: Dimensions For Rws60Dx
DIMENSIONS FOR RWS60DX INSTALLER: Please leave these instructions with the user. 1179mm DATA BADGE LOCATION: Front left-hand side of the refrigerator compartment. COUNTRY OF DESTINATION: GB/IE 651mm Ratings 648mm 607mm Electrical-voltage/frequency 220-240 V / 50Hz 599mm Energy efficiency class on a scale of A (more efficient) to G (less efficient) Climate class (SN=10-32°C,... -
Page 10: Dimensions For Rdz60
DIMENSIONS FOR RDZ60 1168mm INSTALLER: Please leave these instructions with the user. DATA BADGE LOCATION: Front left-hand side of the refrigerator compartment. COUNTRY OF DESTINATION: GB/IE 651mm Ratings Electrical-voltage/frequency 220-240 V / 50Hz 607mm 636mm Energy efficiency class on a scale of A (more efficient) to G (less efficient) Climate class (SN=10-32°C,... -
Page 11: Features For Model Rws38
FEATURES FOR MODEL RWS38 Insert Wine Bottles Front Bottles (Necks Facing Rear) The six (6) roll-out shelves each hold four (4) bottles. See Rear Bottles (Necks Facing Front) Figure 5 for typical wine bottle spacing. Tall bottles should not be loaded on the bottom rack because they may prevent the door from closing. -
Page 12: Features For Model Rws60Dx
FEATURES FOR MODEL RWS60DX Insert Wine Bottles The six (6) roll-out shelves each hold eight (8) bottles. See Front Bottles (Necks Facing Rear) Figure 8 for typical wine bottle spacing. Tall bottles should Rear Bottles (Necks Facing Front) not be loaded on the bottom rack because they may prevent the door from closing. -
Page 13: Features For Model Rdz60
FEATURES FOR MODEL RDZ60 Independent Storage Compartments Both compartments can be set for either temperature range, Front Bottles (Necks Facing Rear) red or white, but for a more efficient energy usage and func- Rear Bottles (Necks Facing Front) tionality of the unit, it is better to use the top compartment for reds (warmer) and the bottom compartment for whites (cooler). -
Page 14: Care And Cleaning
CARE AND CLEANING Condenser The condenser underneath the cabinet does not require frequent cleaning; however, satisfactory cooling depends on adequate ventilation over this heat exchanger. It is recom- mended to annually clean the condenser by vacuuming and brushing. To access the condenser, the unit must be pulled out from the installation, and the lower machine compart- ment access cover removed. -
Page 15: Replacing The Light Tubes
The upper compartment light tube is located behind the display The RWS38 uses one, 6 watt light tube and the RWS60DX housing. The lower compartment light tube is located on and RDZ60 use two, 6 watt light tubes to illuminate the the underside of the divider that separates the compart- interior of the wine storage unit. -
Page 16: Aligning The Door
CARE AND CLEANING Door alignment The door should be parallel to the sides and top of the refrigerator. If alignment is necessary the door may be adjusted by loosening the 2 screws which secure the hinge adapter brackets to the door and adjusting the door side to side. -
Page 17: Energy Saving Tips
ENERGY SAVING TIPS Energy Saving Tips The following suggestions will minimize the cost of oper- ating your refrigeration appliance. 1. Do not install your appliance next to a hot appliance, (cooker, dishwasher, etc.). heating air duct, or other heat sources. 2. -
Page 18: Troubleshooting Guide
Allow 24 hours for tem- perature to stabilize. No interior light inside cabinet. • Failed LED interior light assembly. • Contact a qualified Rangemaster service technician. Light will not go out when door is • Door not activating light switch. -
Page 19: Obtaining Service
Please note: If you request an engineer to visit and the fault • Has not been repaired by unauthorized persons, i.e. is not the responsibility of Rangemaster, our service provider other than organizations authorised to act on behalf of reserves the right to make a charge. - Page 20 Clarence Street, Royal Leamington Spa, Warwickshire, CV31 2AD, England. Tel: +44 (0) 1926 457400 Fax: +44 (0) 1926 450526 E-mail: consumers@rangemaster.co.uk 41011814 Rev F www.rangemaster.co.uk 6/3/13 All specifications and product designs subject to change without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, replacements or compensation for previously purchased products.
