EMPIRE
EMPIRE
Comfort Systems
Installer:
Leave
appliance.
Consumer: Retain this manual for future
reference.
WARNING: If the information in these
instructions are not followed exactly, a fire or
explosion may result causing property damage,
personal injury or loss of life.
— Do not store or use gasoline or other flamma-
ble vapors and liquids in the vicinity of this or
any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
• If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
INSTALLATION INSTRUCTIONS
Exhaust
Blower
Burners
Fan
Hi
Humidifie
r
Power
Med
M an tis
Front
Rear
Low
™
this
manual
with
AND
OWNER'S MANUAL
HIGH-EFFICIENCY
FIREPLACE WITH
PV-28SV50-B(N,P)-1
PV-28SV50-B2H(N,P)-1
PV-28SV55-(C,G)(N,P)-1
PV-28SV55-(C,G)2H(N,P)-1
the
Attention: This appliance is NOT to be installed
in Canada.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
state or local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certified kit is used.
WARNING: If not installed, operated and main-
tained in accordance with the manufacturer's
instructions, this product could expose you to
substances in fuel or from fuel combustion which
can cause death or serious illness.
POWER-VENT
BAY WINDOW
MODELS
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Empire Comfort Systems PV-28SV50-BN-1
Summary of Contents for Empire Comfort Systems PV-28SV50-BN-1
-
Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS EMPIRE EMPIRE OWNER’S MANUAL Comfort Systems POWER-VENT HIGH-EFFICIENCY FIREPLACE WITH BAY WINDOW MODELS PV-28SV50-B(N,P)-1 PV-28SV50-B2H(N,P)-1 PV-28SV55-(C,G)(N,P)-1 PV-28SV55-(C,G)2H(N,P)-1 Exhaust Blower Burners Humidifie Power M an tis Front Rear ™ Installer: Leave this manual with appliance. Consumer: Retain this manual for future reference. -
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE Important Safety Information ............................3 Safety Information for Users of LP-Gas ......................... 4 Requirements for Massachusetts ............................. 5 Gas Supply ..................................6 Introduction ..................................7 Installation Instructions – General Safety Information ....................8 Specifications .................................. 8 Clearances for Direct Vent .............................. -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION THIS IS A HEATING APPLIANCE DO NOT OPERATE THIS APPLIANCE WITHOUT FRONT PANEL INSTALLED. • Due to high temperatures the appliance should be • Installation and repair should be done by a located out of traffic and away from furniture and QUALIFIED SERVICE PERSON. -
Page 4: Safety Information For Users Of Lp-Gas
SAFETY INFORMATION FOR USERS OF LP-GAS Propane (LP-Gas) is a flammable gas which can cause fires and bers of your household. Someday, there may not be a minute to explosions. In its natural state, propane is odorless and colorless. lose, everyone’s safety will depend on knowing exactly what to You may not know all the following safety precautions which can do. -
Page 5: Requirements For Massachusetts
REQUIREMENTS FOR MASSACHUSETTS For all side wall horizontally vented gas fueled equipment installed 3. SIGNAGE. A metal or plastic identification plate shall be in every dwelling, building or structure used in whole or in part permanently mounted to the exterior of the building at a for residential purposes, including those owned or operated by the minimum height of eight (8) feet above grade directly in line Commonwealth and where the side wall exhaust vent termination... -
Page 6: Gas Supply
GAS SUPPLY Installing a New Main Gas Cock Consult the current National Fuel Gas Code, ANSI Z223.1 CAN/ CGA-B149 (.1 or .2) installation code. Each appliance should have its own manual gas cock. A manual main gas cock should be located in the vicinity of Recommended Gas Pipe Diameter the unit. -
Page 7: Introduction
INTRODUCTION Introduction Qualified Installing Agency Always consult your local Building Department regarding Installation and replacement of gas piping, gas utilization regulations, codes or ordinances which apply to the installation of equipment or accessories and repair and servicing of equipment a direct vent wall furnace. shall be performed only by a qualified agency. -
Page 8: Installation Instructions - General Safety Information
INSTALLATION INSTRUCTIONS - GENERAL SAFETY INFORMATION This installation must conform with local codes or, in the Note: Under no circumstances should the appliance be absence of local codes with NFPA54. installed under conditions which would not allow for easy removal of the appliance to carry out routine 2. -
Page 9: Clearances For Direct Vent
CLEARANCES FOR DIRECT VENT Pick a location on a wall with a clear space in the room. The bottom of the exhaust vent terminal and the air intake shall In selecting a location for installation, it is necessary to be located at least 12” (305 mm) above grade and must be vented provide adequate accessibility clearances for servicing and outside. -
Page 10: Clearances For Single Flue
CLEARANCES FOR SINGLE FLUE The bottom of the exhaust vent terminal and the air intake shall Pick a location on a wall with a clear space in the room. be located at least 12” (305 mm) above grade and must be vented In selecting a location for installation, it is necessary to outside. -
Page 11: Specifications
SPECIFICATIONS Heater with Pedestal and Single Flue Adaptor Flue Outlet 1 1/2” PVC Pipe Air Inlet Electric Cord 3/8” Flare Connection (Inside) Single Flue Adaptor Model #PVVK-SH (required) Figure 3 24820-2-0709 Page 11... - Page 12 SPECIFICATIONS - (continued) Heater without pedestal Flue Outlet 1 1/2” PVC Pipe Air Inlet Electric Cord 3/8” Flare Connection (Inside) Single Flue Adaptor Model #PVVK-SH (required) Figure 4 Page 12 24820-2-0709...
- Page 13 SPECIFICATIONS - (continued) Fireplace Insert with Mantel Surround with Slim Top Panel Flue Outlet 1 1/2” PVC Pipe Air Inlet Electric Cord 3/8” Flare Connection (Inside) Single Flue Adaptor Model #PVVK-SH (Required) Surround Model #PVE-1 Top Cover Kit, Slim Model #PV2H Caution: Do not block louver in surround.
-
Page 14: Specifications
SPECIFICATIONS - (continued) Fireplace Insert with Mantel Surround with Short Top Panel Flue Outlet 1 1/2” PVC Pipe Air Inlet Electric Cord 3/8” Flare Connection (Inside) Single Flue Adaptor Model #PVVK-SH (Required) Surround Model #PVE-1 Top Cover Kit, Short Model #PV4H Caution: Do not block louver in surround. -
Page 15: Clearance To Combustibles
Note: The Mantis Power-Vent High-Efficiency Fireplace has been tested and approved for zero clearance to combustible materials. Empire Comfort Systems, Inc. recommends that clearances as listed above should be maintained to allow for removal of the product for servicing. 24820-2-0709... -
Page 16: Rough Framing Dimensions
ROUGH FRAMING DIMENSIONS 13 /34” MIN. CO-LINEAR 8 1/2” WHEN USING DIRECT VENTING PVVK-24H/PVVK-48H NOTE: DIMENSIONS FOR USE WITH SHORT TOP PV4H. THIS IS RECOMMENDED FOR UNIT SERVICEABILITY. 25 1/8” 28” NOTE: IF TRIM AROUND HEATER IS NECESSARY, THE SURROUND KIT PVE-1 MUST BE USED, AND SUBTRACT 1”... -
Page 17: Wall Clearances
WALL CLEARANCES Figure 14 24820-2-0709 Page 17... -
Page 18: Log Set Installation Instructions
LOG SET INSTALLATION INSTRUCTIONS Log Installation All Logs The gas log set (front left log, front right log, center log and rear The positioning of the logs is critical to the safe and clean log) is pre-set and installed in the factory. Only the top left log and operation of this heater. -
Page 19: Vent Examples For Single Flue
Note: All PVC vent run piping can be purchased at a local hardware store. Schedule 40 PVC pipe should be used and cemented. PVVK-CFA Flex Kit and PVVK-SH Horizontal Vent Adaptor Kit are available from Empire Comfort Systems, Inc. MIN. 2”... - Page 20 VENT EXAMPLES FOR SINGLE FLUE (cont.) 40’ Total = 40’ Figure 20 Venting for Existing Fireplace Installation 36’ 1’ (1) - 90° = 3’ Total = 40’ SINGLE FLUE ADAPTOR MODEL #PVVK-SH Figure 21 Single Flue - Venting with Shroud Installed Figure 19 Shroud Kit Model# PVSH Single Flue - Vertical Vent Run...
- Page 21 VENT EXAMPLES FOR SINGLE FLUE (cont.) Figure 22 Minimum Exterior Grade Dimension - Single Flue, Horizontal Venting Below Floor VENT CAP (SUPPLIED WITH VENT KIT) MODEL #PVVK-SV FLASHING ROOF PITCH Determining Minimum Vent Height Above the Roof ROOF PITCH H (Min.) Flat to 6/12 12” (305 mm) 6/12 to 7/12 15”...
-
Page 22: Pvvk-Cfa Flex Vent Kit
PVVK-CFA FLEX VENT KIT Available from Empire Comfort Systems, Inc. The flex vent kit is a flexible vent hose that is 42” in length. The flex vent kit will be used when installing a Mantis into an existing fireplace. The flex vent kit can be cut down, but can only be cut from one end. -
Page 23: Pvvk-Sh Horizontal Vent Adaptor Kit
PVVK-SH HORIZONTAL VENT ADAPTOR KIT Available from Empire Comfort Systems, Inc. INSTALL FOAM GASKET FLUE ADAPTOR Attach flue adaptor to back of heater with four (4) screws. Note: No PVC cement is needed to install flue adaptor kit. PLASTIC GASKET THREADED CONNECTOR Install plastic gasket and screw threaded connector to the flue adaptor. -
Page 24: Horizontal Examples For Colinear Direct Vent
PVCA Horizontal Colinear Direct Vent Adaptor, PVVTC Cap, installed every 3 feet. No “sags” in horizontal vent runs; water PVVK-CFA Flex Kit and PVVK-SH Horizontal Vent Adaptor Kit will settle in the pipe. are available from Empire Comfort Systems, Inc. MIN. 2” 3” MIN. 6” MIN. -
Page 25: Vertical Examples For Colinear Direct Vent
VERTICAL EXAMPLES FOR COLINEAR DIRECT VENT Special Note: The vent terminal (PTrap, Vent cap or two 90° elbows) and first 90° elbow off back of the heater, when within 6” (15.2 cm) off back of the heater, do not contribute to the overall vent length measurement. For each 45° elbow installed in the horizontal run, the length of the horizontal run MUST be reduced by 1.5 feet (45 cm). This does not apply if the 45° elbows are installed on the vertical part of the vent system. Reduce the length of the horizontal run 3 feet (91.4 cm) for every 90° elbow. Note: Exhaust must be a minimum of 3” above air intake inlet. - Page 26 VERTICAL EXAMPLES FOR COLINEAR DIRECT VENT Note: Exhaust must be a minimum of 3” above air intake inlet. AIR INTAKE PTRAP, 2 90° ELBOWS (SUPPLIED BY INSTALLER) OR TERMINATION CAP 3” - 24” EXHAUST MODEL PVVTC. PTRAP TO FACE TERMINATION CAP AWAY FROM ROOF.
-
Page 27: Pvca Horizontal Colinear Direct Vent Adaptor
PVCA HORIZONTAL COLINEAR DIRECT VENT ADAPTOR Colinear adaptor to be used in conjunction with single flue horizontal vent kit PVVK-SH. The two attachments are used for colinear direct vent installation. Colinear adaptor COLINEAR ADAPTER Attach colinear adaptor to back of heater with two (2) 2. When adapter is connected, continue with your vent run. screws. -
Page 28: Pvvtc Termination Cap Vent Kit
PVVTC TERMINATION CAP VENT KIT Available from Empire Comfort Systems, Inc. Termination Cap PVC CEMENT Vertical exhaust cap used with 1 1/2” PVC pipe installation. Termination cap also used with colinear transition plate model PVCT. Refer to instruction manual for venting examples. Page 28... -
Page 29: Pvct Colinear Transition Vent Kit
PVCT COLINEAR TRANSITION VENT KIT Available from Empire Comfort Systems, Inc. Colinear Transition Plate Note: Exhaust must be a minimum of 3” above air intake inlet. EXHAUST PTRAP OR 2 90° ELBOWS OPTIONAL EXHAUST SUPPLIED BY INSTALLER MODEL PVVTC ORDER SEPARATE AIR INTAKE PTRAP OR 2 90° ELBOWS... -
Page 30: Direct Vent Installation Instructions
DIRECT VENT INSTALLATION INSTRUCTIONS PVVK-24H and PVVK-48H Vent Kit available from Empire Comfort Systems, Inc. Note: Do not glue intake or exhaust pipes to Direct Vent Adaptor for serviceability. MANTEL EXHAUST OPENING MUST BE POINTED DOWNWARD. SURROUND DO NOT GLUE Figure 34 THIS POINT Direct Vent System Building Exterior View DIRECT VENT KIT MODEL #PVVK-24H OR PVVK-48H FLUE CENTER... - Page 31 DIRECT VENT INSTALLATION INSTRUCTIONS (cont.) Installation on Rugs and Tile If this appliance is to be installed directly on carpeting, tile, or other combustible 1 1/4” material, other than wood flooring, the (3.2cm) appliance shall be installed on a metal or MIN.
-
Page 32: Pvvk-24H And Pvvk-48H Vent Kit
PVVK-24H AND PVVK-48H VENT KIT Available from Empire Comfort Systems, Inc. Step 1. Install foam gasket on back side of co-axial direct vent adaptor. Step 4. Install silicone around connection between co-axial adaptor and co-axial air-inlet duct. 4 1/2” MINIMUM VENT LENGTH Step 2. Attach co-axial direct vent adaptor and gasket (4 screws) to the rear of fireplace. - Page 33 PVVK-24H AND PVVK-48H VENT KIT (cont.) 45° ELBOW EXHAUST OPENING MUST BE POINTED DOWNWARD. Direct Vent System Building Exterior View 47.5” (1.2m) Horizontal Venting Maximum 47.5” (1.2 m) with 45° elbow. 45° elbow can be purchased from a local hardware store. 47.5” (1.2m) Maximum Horizontal Venting - 47 1/2” (1.2 m) Minimum Horizontal Venting - 4” (10.2 cm) Parts List Index Part Description Number Number R8887 Co-axial DV Adaptor R8862 Foam Gasket...
-
Page 34: Gas Connection Installation Instructions
GAS CONNECTION INSTALLATION INSTRUCTIONS GAS CONNECTION (Line Supply) A 3/8” Flair gas line connection is supplied in the heater GAS SUPPLY LINE TO HEATER Remove rubber grommet from back panel and pull out flex line through back panel. Connect gas supply line to flexible gas hose. Ensure that flexible gas hose is not kinked after fitting gas supply line. After gas supply line has been brought through from rear of heater, place rubber grommet supplied over gas line. -
Page 35: Operating Instructions Checklist
3. Installers who are not familiar with the installation of this 10. Check and verify that logs are place correctly as per appliance should contact Empire Comfort Systems, Inc. instructions on Page 18 of this manual. If logs are incorrectly... -
Page 36: Lighting Instructions
LIGHTING INSTRUCTIONS Main Electrical power supply must always be switched on to the heater. As the heater becomes warmer, the medium L.E.D the unit with the two burner switches in the off position (up) (Figure 43G) will come on. When the heater has reached its before lighting the heater. -
Page 37: Lighting Instructions
LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EX- PLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY, OR LOSS OF LIFE. A. BEFORE LIGHTING smell all around the appliance area B. -
Page 38: Fan Operation
FAN OPERATION The 3-speed main convection fan will automatically start approximately 3 to 5 minutes after the heater has warmed up. Note: The 3-speed main convection fan is automatically controlled and will operate on three preset speeds. Depending on your burner setting and the surrounding ambient temperature, the L.E.D lights (Page 36, Figure 43) for the fan will light up. -
Page 39: Gas Conversion Instructions
GAS CONVERSION INSTRUCTIONS Warning: Conversion must be done by a qualified service technician. Main burner orifices, front burner bushing, and gas conversion label are provided in conversion kit attached to manifold pipe. CONVERSION INSTRUCTIONS FROM (LP) PROPANE GAS TO NATURAL GAS Turn OFF gas supply and electrical power to fireplace. Remove lower front panel. Unscrew regulator stem from gas valve and reverse regulator stem to the natural gas position and screw stem back into gas valve. - Page 40 GAS CONVERSION INSTRUCTIONS Warning: Conversion must be done by a qualified service technician. Main burner orifice(s) and new gas conversion label are provided in conversion kit attached to manifold pipe. CONVERSION INSTRUCTIONS FROM NATURAL GAS TO (LP) PROPANE GAS Turn OFF gas supply and electrical power to fireplace. Remove lower front panel. Unscrew regulator stem from gas valve and reverse regulator stem to the propane gas position and screw stem back into gas valve. The propane gas arrow will be pointing at the gas valve in the propane gas position.
-
Page 41: Automatic Humidifier Operation
AUTOMATIC HUMIDIFIER OPERATION Most gas heaters dry out the air in the room. The Mantis has ingeniously solved this problem with an Automatic Humidifier. Gas contains moisture which is normally expelled out the flue or chimney after combustion. But the Mantis is so efficient by taking 92% of the heat out of the burnt gases that the moisture drops out and condenses in the back of the heater. -
Page 42: Optional Controllers
OPTIONAL CONTROLLERS TEMPERATURE CONTROLLERS FRBTP Battery Operated Remote w/ Programmable Thermostat FRBTC Battery Operated Remote w/ Thermostat Battery Operated Wireless Remote Wall Thermostat TMV2 Thermostat, 2 Stage T24V Thermostat, 24 Volt See your Mantis dealer for correct controller type. INSTRUCTIONS MUST BE LEFT WITH THE OWNER FOR FUTURE REFERENCE AFTER INSTALLATION Installation Instructions for FRBTP, FRBTC, and TRW Remote Controls FRBTP, FRBTC and TRW are all battery operated devices. -
Page 43: Optional Controllers
OPTIONAL CONTROLLERS R: 24 Volt Hot : Heat Relay Stage 1 (Front burner) : Heat Relay Stage 2 (Rear burner) C: 24 Volt Common WHITE, WHITE/ BLACK REMOTE WIRE HORNESS THERMOSTAT (TO BE REMOVED) JUNCTION W1 R BLOCK BLUE TRANSFORMER TO “T1”... -
Page 44: Wiring
WIRING The appliance, when installed, must be electrically grounded in CAUTION: Label all wires prior to disconnection when accordance with local codes or, in the absence of local codes, servicing controls. Wiring errors can cause improper and with the National Electrical Code, ANSI/NFPA 70 or Canadian dangerous operation. -
Page 45: General Information
GENERAL INFORMATION Paint Curing - First Firing Over Temperature Cut Out The first fire in your heater is part of the paint curing process. The Mantis Power-Vent High-Efficiency Fireplace is protected Your Mantis Power-Vent High-Efficiency Fireplace has been against overheating with a high temperature 80°C (176°F) cut off painted with the highest quality heat resistant silicon paint switch to protect the heat exchanger, plastic sump and flue fan. -
Page 46: Maintenance
General Glass Information FLAME SENSOR Only glass approved for use in Empire Comfort Systems, Inc. FRONT BURNER fireplace may be used for replacement. The glass replacement IGNITOR ASSEMBLY must be done by a licensed or qualified service person. -
Page 47: Unit Operating Faults
UNIT OPERATING FAULTS SERVICE AND INSTALLATION OF THE APPLIANCE flame color or configuration, intermittent operations, changes SHOULD BE CARRIED OUT BY AUTHORIZED PER- in heat output, carbon build up or sooting, bad odors, rattles or SONNEL ONLY. other sounds, start up failures and burner(s) switching themselves off. -
Page 48: Main Convection Fan
MAIN CONVECTION FAN Note: The main convection fan in the heater should be checked, If the main convection fan becomes clogged with lint and serviced and cleaned annually by a qualified service person to dust an over-temperature situation will occur through the ensure that your appliance is operating efficiently. -
Page 49: Pedestal Installation Instructions
PEDESTAL INSTALLATION INSTRUCTIONS Optional Pedestal Assembly Installation NOTE: To avoid accidents and damage to main heater body and Remove pedestal assembly from carton. Handle pedestal paint-work, it is recommended that main body of heat- with care to avoid paint damage. er should be located on top of pedestal assembly by 2 people. -
Page 50: Parts List
PARTS LIST PLEASE NOTE: When ordering parts, it is very important that part number and description of part coincide. INDEX NO. PART NO. DESCRIPTION 22868 REAR PANEL ASSEMBLY 21654 BRACKET, PIPE ASSEMBLY 22670 REAR HEAT SHIELD ASSEMBLY 21664 TOP COVER ASSEMBLY (INCLUDES #5) 22933 SLIM TOP ASSEMBLY R8854... -
Page 51: Parts List
PARTS LIST PLEASE NOTE: When ordering parts, it is very important that part number and description of part coincide. INDEX NO. PART NO. DESCRIPTION P295 FRONT ORIFICE, LPG R8793 HOLDER, ORIFICE R7572 JAMB NUT 22627 GAS LINE - REAR 26128 GAS LINE - FRONT M174 GASKET... -
Page 52: Parts View
PARTS VIEW Page 52 24820-2-0709... - Page 53 PARTS VIEW 24820-2-0709 Page 53...
-
Page 54: Warranty Terms
WARRANTY TERMS Purchase Date: Dealer Name/Phone: Installer - Place Serial Number Sticker Here and Leave this Manual with the Consumer. Limited Ten-Year Heat Exchanger Warranty Empire promises to the owner that if the heat exchanger (see parts list) fails because of defective workmanship or material within ten years from the date of purchase, Empire will repair, or at Empire’s option, replace the defective heat exchanger. -
Page 55: Master Parts Distributor List
For the current list, please click on the Master Parts button at www.empirecomfort.com. Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original Equipment repair parts for Heaters, Grills, and Fireplaces manufactured by Empire Comfort Systems Inc. Star-Fire Distributors... - Page 56 Empire Comfort Systems Inc. EMPIRE EMPIRE 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. Comfort Systems www.empirecomfort.com...
