Specifi cations
TORQUE SPECIFICATIONS
Oil Pump
Mounting Screw
Oil Sentry
TM
Pressure Switch
Solenoid (starter)
Mounting Hardware
Nut, Positive (+) Brush Lead
Starter Assembly
Thru Bolt
Mounting Screw
Brush Holder Mounting Screw
Stator
Mounting Screw
Throttle/Choke Control Bracket
Fastener
Valve Cover
Fastener

CLEARANCE SPECIFICATIONS

Camshaft
End Play
Running Clearance
Bore I.D.
New
Max. Wear Limit
Bearing Surface O.D.
New
Max. Wear Limit
Cam Lobe Profi le (minimum dimension, measured from base circle
to top of lobe)
Exhaust
Intake
3 Values are in Metric units. Values in parentheses are English equivalents.
Lubricate threads with engine oil prior to assembly.
5
8
3,5
3
KohlerEngines.com
CV940 CV960
10.7 N·m (95 in. lb.) into new holes
6.7 N·m (60 in. lb.) into used holes
10.1 N·m (90 in. lb.)
4.0-6.0 N·m (35-53 in. lb.)
8.0-11.0 N·m (71-97 in. lb.)
5.6-9.0 N·m (49-79 in. lb.)
15.3 N·m (135 in. lb.)
2.5-3.3 N·m (22-29 in. lb.)
6.2 N·m (55 in. lb.)
9.9 N·m (88 in. lb.)
13.6 N·m (120 in. lb.)
CV940 CV960
0.3/1.3 mm (0.011/0.051 in.)
0.025/0.063 mm (0.0010/0.0025 in.)
20.000/20.025 mm (0.7874/0.7884 in.)
20.038 mm (0.7889 in.)
19.962/19.975 mm (0.7859/0.7864 in.)
19.959 mm (0.7858 in.)
35 mm (1.3779 in.)
34.1 mm 35 mm (1.3779 in.)
(1.3425 in.)
CV980 CV1000
CV980 CV1000
62 690 02 Rev. D
