CLEARANCE SPECIFICATIONS
Valves and Valve Lifters
Hydraulic Valve Lifter to Crankcase Running Clearance
Intake Valve Stem-to-Valve Guide Running Clearance
Exhaust Valve Stem-to-Valve Guide Running Clearance
Intake Valve Guide I.D.
New
Max. Wear Limit
Exhaust Valve Guide I.D.
New
Max. Wear Limit
Guide Reamer Size
Standard
0.25 mm O.S.
Nominal Valve Face Angle
Values are in Metric units. Values in parentheses are English equivalents.
3
62 690 02 Rev. D
3
KohlerEngines.com
CV940
CV960
0.012/0.050 mm (0.0004/0.0019 in.)
0.038/0.076 mm (0.0015/0.0030 in.)
0.050/0.088 mm (0.0020/0.0035 in.)
7.038/7.058 mm (0.2771/0.2779 in.)
7.135 mm (0.2809 in.)
7.038/7.058 mm (0.2771/0.2779 in.)
7.159 mm (0.2819 in.)
7.048 mm (0.2775 in.)
7.298 mm (0.2873 in.)
45°
Specifi cations
CV980
CV1000
11
