Summary of Contents for Kingston Technology Locker+
- Page 1 ® DataTraveler Locker+ User Manual ® Document No. 48008071-001.A02 DataTraveler Locker+ Page 1 of 22...
-
Page 2: Table Of Contents
Table of Contents About This Manual ........................3 System Requirements ......................3 Recommendations ........................3 Setup (Windows Environment)....................4 Device Initialization (Windows Environment) ............... 5 Device Usage (Windows Environment) ................. 9 Device Options (Windows Environment)................10 Setup (Mac Environment) ..................... 12 Device Initialization (Mac Environment) ................ -
Page 3: About This Manual
About This Manual ® This user manual covers the DataTraveler Locker+ (referred to simply as DTL+ from this point forward) based on the factory image with no implemented customizations. System Requirements PC Platform PC Operating System Support • Pentium III Processor or equivalent (or •... -
Page 4: Setup (Windows Environment)
Setup (Windows Environment) 1. Insert the DTL+ into an available USB port on your notebook or desktop and wait for Windows to detect it. • Windows XP users will receive a ‘Found New Hardware’ notification as seen in Figure 2.1 Figure 2.1 –... -
Page 5: Device Initialization (Windows Environment)
Device Initialization (Windows Environment) 1. Select your language preference from the drop-down menu and click ‘Next’ ( Figure 3.1 Figure 3.1 – Language Selection 2. Review the license agreement and click ‘Next’ ( (Note: You must accept the Figure 3.2.) license agreement before continuing;... - Page 6 3. Create a password to protect your data on the DTL+. Enter it in the ‘Password’ field, then re-enter it in the ‘Password Confirmation’ field, as seen below in . The password Figure 3.3 you create must meet the following criteria before the initialization process will allow you to continue: 1.
- Page 7 4. Enter your contact information into the text boxes provided (see ) (Note: The Figure 3.4 information you enter in these fields may contain the password string you created in Step 3. However, these fields are optional and can be left blank, if so desired.) •...
- Page 8 The DTL+ will now format the secure data partition ( ) and notify you when it is Figure 3.5 complete ( Figure 3.6 Note: If operating under Windows XP in Non-Admin mode, the ‘Format’ routine can take up to a minute.* 6.
-
Page 9: Device Usage (Windows Environment)
Device Usage (Windows Environment) Once the DTL+ has been initialized, you can access the secure data partition and utilize the device options by logging into the device with your password. To do so, follow these steps: 1. Insert the DTL+ into a USB port on your notebook or desktop and enter your pass- word (see Figure 4.1... -
Page 10: Device Options (Windows Environment)
Device Options (Windows Environment) While you are logged into the device, there will be a ‘DTL+’ icon located in the right-hand corner of the Windows taskbar ( .) (Note: Windows 7 users will need to click on the Figure 5.1 up-arrow button in the taskbar in order to access the ‘DTL+’... - Page 11 Browse DTL+ • Allows you to browse the contents of the secure data partition while you are logged in Format DTL+* • Allows you to format the secure data partition (Warning: All data will be erased.) ( Figure 5.6 Online Support (Requires Internet access) •...
-
Page 12: Setup (Mac Environment)
Setup (Mac Environment) Insert the DTL+ into an available USB port on your notebook or desktop and wait for the Mac operating system to detect it. When it does, you will see a DTLplus volume appear on the desktop, as seen in Figure 6.1 1. -
Page 13: Device Initialization (Mac Environment)
Device Initialization (Mac Environment) 1. Select your language preference from the drop-down menu and click ‘Next’ ( Figure 7.1 Figure 7.1 – Language Selection 2. Review the license agreement and click ‘Next’ ( .) (Note: You must accept the Figure 7.2 license agreement before continuing;... - Page 14 3. Create a password to protect your data on the DTL+. Enter it in the ‘Password’ field, then re-enter it in the ‘Password Confirmation’ field, as seen below in . The password Figure 7.3 you create must meet the following criteria before the initialization process will allow you to continue: 1.
- Page 15 4. Enter your contact information into the text boxes provided (see ) (Note: The Figure 7.4 information you enter in these fields may contain the password string you created in Step 3. However, these fields are optional and can be left blank, if so desired.) •...
- Page 16 The DTL+ will now format the secure data partition ( ) and notify you when it is Figure 7.5 complete ( Figure 7.6 6. Click ‘OK’ to continue. Figure 7.5 – Formatting DTLocker+ Figure 7.6 – Format Complete Initialization complete. ®...
-
Page 17: Device Usage (Mac Environment)
Device Usage (Mac Environment) Once the DTL+ has been initialized, you can access the secure data partition and utilize the device options by logging into the device with your password. To do so, follow these steps: 1. Insert the DTL+ into a USB port on your notebook or desktop and enter your pass- word (see Figure 8.1... -
Page 18: Device Options (Mac Environment)
Device Options (Mac Environment) While you are logged into the device, there will be a ‘DTLplus_Launcher’ icon located in the Mac OS X Dock as seen in below: Figure 9.1 Figure 9.1 – DTL+ Icon In Mac OS X Dock Holding down the ‘control’... - Page 19 Browse DTL+ • Allows you to browse the contents of the secure data partition while you are logged in Format DTL+ • Allows you to format the secure data partition (Warning: All data will be erased.) ( Figure 9.6 Online Support (Requires Internet access) •...
-
Page 20: Help And Troubleshooting
Help and Troubleshooting Device Lockout The DTL+ includes a security feature that prevents unauthorized access to the data partition once a maximum number of consecutive failed login attempts (MaxNoA for short) has been made; the default “out-of-box” configuration has a pre-configured value of 10 (no. of attempts.) The ‘lock-out’... -
Page 21: Forgot Password
Forgot Password If you forget your password, you can click on the ‘Forgot Password’ link that appears in the device login window when DTLplus_Launcher is executed (see Figure 10.3 This option will allow you to create a new password, but in order to protect the privacy of your data, the DTL+ will be formatted. -
Page 22: Drive Letter Conflict (Windows Operating Systems)
Drive Letter Conflict (Windows Operating Systems) As mentioned in the ‘System Requirements’ section of this manual (on page 3), the DTL+ requires two consecutive drive letters AFTER the last physical disk that appears before the ‘gap’ in drive letter assignments (see .) This does NOT pertain to network shares Figure 10.5 because they are specific to user-profiles and not the system hardware profile itself, thus...
