Lumex 6132A Assembly & Operation Instructions

A Graham-Field Brand
Warning: This product should not be used without proper instruction from a healthcare professional.
Warning: Lumex assumes no responsibility for any damage or injury caused by improper installation,
assembly or use of this product.
Warning: If components are damaged or missing, contact your dealer immediately. DO NOT use
substitute parts.
armrest
tube
armrest
Assembly instructions (see above pictures)
1. Install armrest tube in iron sheets.
2. Insert carriage bolts, plain washers, and knobs;
tighten until secure.
Warning: Ensure that all components are securely fastened as described above before use.
Three year limited warranty. For additional warranty information, please contact your Lumex dealer.
6132A: UNIVERSAL FOREARM WALKER ATTACHMENT
ASSEMBLY & OPERATION INSTRUCTIONS
carriage bolt,
plain washer, and knob
iron sheet
carriage bolt,
plain washer, and knob
iron sheet
carriage
3. Install armrest assembly on upright.
4. Insert carriage bolts, eight-square washers, and
knobs; tighten until secure.
5. Install walker attachment
on walker as shown in
picture at right.
WARRANTY
Graham-Field Health Products
Atlanta, Georgia 30360
printed in China
armrest
assembly
bolt
eight-square washer
and knob
upright
walker attachment
(top section only shown)
©Graham-Field Health Products, 05/04
