NOTE: The scala rider G4 PowerSet package, contains two factory
paired G4 headsets. If you did not change the original pairing
settings, you can skip "step one" below:
Step One: Pair Driver 1 to Passenger 2 via Channel "A" as follows
a. Turn both headsets ON by pressing and holding the Mobile
Buttons until the Blue Light flashes three times.
b. Both headsets should now be flashing slowly in Blue.
c. Press and hold CHANNEL ("A") BUTTON on both headsets for at
least six seconds until the headset's BLUE or RED Light begins
flashing rapidly, indicating that they have entered the Intercom
Pairing mode. (See Intercom Channel Table for Pairing Light
indication for each CHANNEL)
d. Release the buttons and wait until both headsets display a
solid light for two seconds, indicating that the two headsets are
now paired for Intercom connections. (This may take up to two
minutes)
Step Two: Pair Driver 3 to Passenger 4 via Channel "A"
Repeat the above pairing procedure between Driver 3 and Passenger 4
Step Three: Pair Passenger 2 to Passenger 4 via Channel "B"
Repeat the above pairing procedure between Passenger 2 and Pas-
senger 4 using the Channel "B" button. (instead of Channel "A" button
as described in bullet c above).
Your 4-Way Conference Intercom Pairing is now complete and ready
to use.
NOTE: If the Pairing process is not completed within two minutes the
headsets will return to Standby mode.
18 scala rider G4 PowerSet
® ™
Making 4-Way Intercom calls
Once you have successfully paired the four headsets as described
above, and all units are in standby mode, proceed as follows to start a
4-way Conference Intercom call:
a. Passenger 2 should press Button "B" to initiate a call with
Passenger 4. Wait until audio is heard on both headsets and
proceed to the next step.
b. Driver 1 should press Button "A" to initiate a call with
Passenger 2.
c. Driver 3 should press Button "A" to initiate a call with
Passenger 4.
Now the 4-way intercom conference mode is established.
NOTE: If one of the headsets should disconnect or drop off from the 4-way
call and fails to reconnect, repeat the three steps above.
9.11 USING THE G4 FOR INTERCOM WITH OTHER
SCALA RIDER HEADSETS
INTERCOM PAIRING / CONNECTION
CHANNEL BUTTON
CHANNEL "A" CHANNEL "A" BUTTON
CHANNEL "B" CHANNEL "B" BUTTON
PAIRING MODE LED
INDICATORS
Rapid RED flashing
Rapid BLUE flashing
