- Page 1 JUKI-6770 SERIES SOCKET479 PENTIUM-M/CELERON-M SBC with 10/100 Ethernet LAN User’s Manual Version 1.0 Jan 30, 2005 Copyright 2005 by IEI Technology Corp. All rights Reserved...
- Page 2 Trademarks JUKI-6770 is a registered trademark of IEI Technology ; IBM PC is a registered trademark of International Corp.
-
Page 3: Table Of Contents
Table of Contents 1. INTRODUCTION ..............4 PECIFICATIONS ..................5 ACKAGE ONTENTS ..................7 2. INSTALLATION ..............8 AYOUT ......................9 NPACKING RECAUTIONS ..............10 CMOS S LEAR ETUP ................10 OMPACT LASH ASTER LAVE ETTING ......11 LVDS V OLTAGE ETTING ............11 3. CONNECTION ................12 LOPPY RIVE ONNECTOR ............13... - Page 4 .......................24 DVANCED ....................25 PCIP P ......................37 .......................38 4.10 S ECURITY .....................40 4.11 C HIPSET ......................41 4.12 P OWER ......................43 4.13 E ........................46 APPENDIX A. WATCHDOG TIMER............48 APPENDIX B: DIGITAL I/O................50 APPENDIX C. RESOURCES MAP .............. 52...
-
Page 5: Introduction
1. Introduction Thanks for choosing JUKI-6770 PENTIUM-M Single Board Computer. The JUKI-6770 board is a PCISA form factor board equipped with high performance processor and multi-mode I/O. It is designed for system manufacturers, integrators, or VARs that want to provide all the performance, reliability, and quality at a reasonable price. -
Page 6: Specifications
Specifications Intel Pentium-M/Celeron-M Processor Supports 400/533(optional) MHz FSB Bus interface PCI/ISA Bus speed ISA: 8MHZ, PCI: 33MHz, DMA channels Interrupt levels Chipset INTEL 852GM (GMCH)/855GME(optional) Real-time clock INTEL 82801DB(ICH4) One 184-pin DIMM socket Support DDR 200/266/333(855GME) System memory SDRAM Maximum memory is up to 1GB Up to four PCI enhanced IDE hard drives Can handle data transfer up to 100MB/s ATA/100... - Page 7 Supports Serial Infrared(SIR) and Amplitude IrDA port Shift Keyed IR(ASKIR) interface Supports 5 USB2.0/1.1 ports for future USB port expansion Software programmable reset generated when CPU does not periodically trigger the timer Watch-dog timer The BIOS INT15 can be used to control the watchdog and generate the system reset i852GM integrated graphic engine...
-
Page 8: Package Contents
WARNING ! 1. Never run the processor without the heat sink (cooler)properly and firmly attached. Package Contents One JUKI-6770 Single Board Computer One ATA/100 IDE cable & One 44P IDE cable One RS-232 and Printer Cable & One RS232/422/485 Cable with bracket... -
Page 9: Installation
2. Installation This chapter describes how to install the JUKI-6770. At first, the layout of JUKI-6770 is shown, and the unpacking information that you should be careful is described. The jumpers and switches setting for the JUKI-6770's configuration are also included. -
Page 10: Layout
Layout PS. Those components about LAN2 and DVI are optional. -
Page 11: Unpacking Precautions
Ground yourself to remove any static charge before ü touching JUKI-6770 SBC. You can do it by using a grounded wrist strap at all times or by frequently touching any conducting materials that is connected to the ground. -
Page 12: Compactflash Master/Slave Mode Setting
CompactFlash Master/Slave Mode Setting JP2 : Master/Salve Mode Setting DESCRIPTION Master Slave LVDS Voltage Mode Setting JP3 : 3.3V/5V Mode Setting DESCRIPTION 3.3V... -
Page 13: Connection
3. Connection This chapter describes how to connect peripherals, switches and indicators to the JUKI-6770 board. Table of Connectors Label Function IDE1 Ultra ATA100 Primary (40 Pin) IDE2 Secondary IDE connectors (44 PIN ) FDD1 Floppy connector LPT1 Parallel port connector... -
Page 14: Floppy Disk Drive Connector
Floppy Disk Drive Connector The JUKI-6770 board is equipped with a 34-pin daisy- chain drive connector cable. FDD1 : FDC Connector DESCRIPTI DESCRIPTION GROUND REDUCE WRITE GROUND GROUND INDEX# GROUND MOTOR ENABLE A# GROUND DRIVE SELECT B# GROUND DRIVE SELECT A#... -
Page 15: Parallel Port
DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14 DATA 0 DATA 15 GROUND GROUND IOW# GROUND IOR# GROUND BALE – DEFAULT GROUND – DEFAULT INTERRUPT IOCS16#-DEFAULT HDC CS0# HDC CS1# HDD ACTIVE# GROUND IDE2 Interface Connector (2.0mm Pitch) DESCRIPTION DESCRIPTION RESET#... -
Page 16: Serial Ports
DATA 6 GROUND DATA 7 GROUND ACKNOWLEDGE GROUND BUSY GROUND PAPER EMPTY GROUND PRINTER SELECT GROUND Serial Ports JUKI-6770 offers high-speed NS16C550 compatible UART. COM1 : 10-pin header onboard COM2 : 14-pin header onboard Connector Ports Address Interrupt COM1 COM1... -
Page 17: Keyboard & Ps/2 Mouse Connector
(13) RS-422 RX+ (14) RS-422 RX- Keyboard & PS/2 Mouse Connector A 6-pin mini DIN connector is located on the mounting bracket for easy connection to a keyboard or a PS/2 mouse. The card comes with a PS/2 Y splitter cables for keyboard and mouse connection. -
Page 18: Ps-On Connector
DESCRIPTION ATX-ON 5VSB Power source from Backplane with ATX Connector (Through Power Button & +5VSB) USB Port Connector The JUKI-6770 provides 2 built-in USB2.0 ports for the future I/O bus expansion. USB2&USB3 PIN NO. DESCRIPTION PIN NO. DESCRIPTION GROUND DATA0-... -
Page 19: Fan Connectors (Fan1)
(AUDIO1). AUDIO1 DESCRIPTIO DESCRIPTIO SPEAK(L) SPEEAK(R) LINE_OUT(L) LINE_OUT(R LINEIN(L) LINEIN(R) CDIN1 : CD-IN DESCRIPTION CD LEFT SIGNAL GROUND GROUND CD RIGHT SIGNAL 3.12 External Power Connector (J3) The JUKI-6770 has an onboard external power connector J3. You... -
Page 20: Digital I/O Connector
This kind of response is highly needed for harsh and critical industrial operating environment. That’s why we design 4-bit digital inputs and 4-bit digital outputs on the JUKI-6770 Digital Input and Output, generally, are control signals. You can use these signals to control external devices that needs On/Off circuit or TTL devices. -
Page 21: Lvds1 Connector
VCC_LCD LVDSB_Y3+ VCC_LCD 3.16 Compact Flash Storage Card Socket (J1) The JUKI-6770 configures Compact Flash Storage Card in IDE Mode. This type II Socket is compatible with IBM Micro Drive. J1 : Compact Flash Storage Card Socket pin assignment PIN NO. -
Page 22: Backlight Inverter Connector
CS1# CS3# GROUND IOR# IOW# IRQ15 MASTER/SLAVE RESET# IORDY ACTIVE# PDIAG# PULL DOWN GROUND 3.17 Backlight inverter Connector CN1: backlight inverter connector DESCRIPTION GROUND BKL_POWER GROUND... -
Page 23: Ami Bios Setup
4. AMI BIOS SETUP Introduction This manual discusses A MI's Setup program built into the ROM BIOS. The Setup program allows users to modify the basic system configuration. This special information is then stored in battery-backed RAM so that it retains the Setup information when the power is turned off. -
Page 24: Using Setup
Using Setup In general, you use the arrow keys to highlight items, press <Enter> to select, use the PageUp and PageDown keys to change entries, press <F1> for help and press <Esc> to quit. The following table provides more detail about how to navigate in the Setup program using the keyboard. -
Page 25: Bios Menu Bar
making any changes to the chipset defaults. These defaults have been carefully chosen by both AMI and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. BIOS MENU BAR The menu bar on top of the screen has the following main items: Main... -
Page 26: Advanced
appears giving you an overview of the basic system information. AMI BIOS This item displays the auto-detected BIOS information. Processor This item displays the auto-detected CPU specification. System Memory This item displays the auto-detected system memory. System Time [xx:xx:xx] This item allows you to set the system time. -
Page 27: Cpu Configuration
4.7.1 CPU Configuration The items in this menu show the CPU-related information auto- detected by BIOS. -
Page 28: Ide Configuration
Intel® SpeedStep™ tech. [Automatic] This item allows you to Select disable the processor Hyper- Threading Technology. Configuration options: [Maximum Speed] [Minimum Speed] [Automatic] [Disabled] 4.7.2 IDE Configuration The items in this menu allow you to set or change the configurations for the IDE devices installed in the system. - Page 29 Onboard PCI IDE Controller¡G[Both] Configuration options: [Disable] [Primary] [Secondary] [Both] Primary and Secondary IDE Master/Slave The values opposite the dimmed items (Device, Vendor, Size, LBA Mode, Block Mode, PIO Mode, Async DMA, Ultra DMA, and SMART monitoring) are auto-detected by BIOS and are not user- configurable.
-
Page 30: Floppy Configuration
Block (Multi-sector Transfer) [Auto] Enables or disables data multi-sectors transfers. When set to Auto, the data transfer from and to the device occurs multiple sectors at a time if the device supports multi-sector transfer feature. When set to Disabled, the data transfer from and to the device occurs one sector at a time. -
Page 31: Superio Configuration
Sets the type of floppy drive installed. Configuration options: [Disabled][360K, 5.25 in.][1.2M , 5.25 in.][720K , 3.5 in.] [1.44M, 3.5 in.] [2.88M,3.5in.] Floppy Device Swap ¡G Disabled] Configuration options: [Disabled][Enabled] 4.7.4 SuperIO Configuration... - Page 32 On Board Floppy Controller [Enabled] Allows you to enable or disable the floppy disk controller. Configuration options: [Disabled] [ Enabled] Serial Port1 Address [3F8/IRQ4] Allows you to select the Serial Port1 base address. Configuration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4] [2E8/IRQ3] Serial Port2 Address [2F8/IRQ3] Allows you to select the Serial Port2 base address.
-
Page 33: Hardware Health Configuration
Configuration options: [Normal] [Bi-directional] [EPP] [ECP] Parallel Port IRQ [IRQ7] Configuration options: [IRQ5] [IRQ7] Digital I/O Function [Enabled] Configuration options: [Disabled] [Enabled] 4.7.5 Hardware Health Configuration H/W Health Function [Enabled] Configuration options: [Disabled] [Enabled] 4.7.6 ACPI Configuration Allows you to change the settings for the Advanced Power... -
Page 34: Advanced Acpi Configuration
Management (APM). Select an item then press Enter to display the configuration options. ACPI Aware O/S [Yes] Configuration options: [No] [Yes] General ACPI Configuration Allows you to select the ACPI state to be used for system suspend. Configuration options: [S1 (POS) Only] 4.7.7 Advanced ACPI Configuration... -
Page 35: Remote Access Configuration
ACPI APIC support [Enabled] Configuration options: [Disabled] [Enabled] Apic ACPI SCI IRQ [Disabled] Configuration options: [Disabled] [Enabled] BIOS ¡Ð ¡Ð ¡Ö AML ACPI table [En abled] Configuration options: [Disabled] [Enabled] Headless mode [Disabled] Configuration options: [Disabled] [Enabled] 4.7.8 Remote Access Configuration... - Page 36 Configure Remote Access. Remote Access [Disabled] Configuration options: [Disabled] [Enabled] Serial port number [COM1] Configuration options: [COM1] [COM2] Serial port Mode [115200 8,n,1] Configuration options: [115200 8,n,1] [57600 8,n,1] [38400 8,n,1] [19200 8,n,1] [09600 8,n,1] Flow Control [None] Configuration options: [None] [Hardware] [Software] Redirection After BIOS POST [Always] Configuration options: [Disabled] [Boot Loader] [Always] Terminal Type [ANSI]...
-
Page 37: Usb Configuration
4.7.9 USB Configuration The items in this menu allows you to change the USB-related features. Select an item then press Enter to display the configuration options. USB Function [5 USB Ports] Allows you to set the number of USB ports to activate. Configuration options: [Disabled] [2 USB Ports] [4 USB Ports] [5 USB Ports] Legacy USB Support [Enable]... -
Page 38: Pcipnp
PCIPnP The PCI PnP menu items allow you to change the advanced settings for PCI/PnP devices. The menu includes setting IRQ and DMA channel memory size block for legacy ISA devices. Plug & Play O/S [NO] When set to [No], BIOS configures all the devices in the system. When set to [Yes] and if you installed a Plug &... -
Page 39: Boot
Configuration options: [No] [Yes] Palette Snooping [Disabled] When set to [Enabled], the palette snooping feature informs the PCI devices that an ISA graphics device is installed in the system so that the latter can function correctly. Setting to [Disabled] deactivates this feature. Configuration options: [Disabled] [Enabled] PCI IDE Bus Master [Disabled] Allows BIOS to use PCI bus mastering when reading/writing to... - Page 40 menu. 4.9.1 Boot Settings Configuration Quiet Boot [Disabled] This allows you to enable or disable the full screen logo display feature. Configuration options: [Disabled] [Enabled] Boot From LAN Support [Disabled] Configuration options: [Disabled] [Enabled] Add On ROM Display Mode [Force BIOS] Sets the display mode for option ROM.
-
Page 41: Security
when error occurs. Configuration options: [Disabled] [Enabled] Hit ‘DEL’ Message Display [Enabled] When set to Enabled, the system displays the message ‘Press DEL to run Setup’ during POST. Configuration options: [Disabled] [Enabled] Interrupt 19 Capture [Disabled] When set to [Enabled], this function allows the option ROMs to trap Interrupt 19. -
Page 42: Chipset
Change Supervisor Password Select this item to set or change the supervisor password. The Supervisor Password item on top of the screen shows the default Not Installed. After you have set a password, this item shows Installed. Change User Password Select this item to set or change the user password. -
Page 43: Northbridge Configuration
4.11.1 NorthBridge Configuration Configure DRAM Timing by SPD [Enabled] When this item is enabled, the DRAM timing parameters are set according to the DRAM SPD (Serial Presence Detect). When disabled, you can manually set the DRAM timing parameters through the DRAM sub-items. Configuration options: [Disabled] [Enabled] Memory Hole [Disabled] Configuration options: [Disabled] [15MB-16MB]... -
Page 44: Power
Graphics Aperture Size [64MB] Allows you to select the size of mapped memory for AGP graphic data. Configuration options: [64MB] [128MB] [256MB] Boot Display Device [CRT+LFP] Allows you to display CRT, LFP, EFP mode device. Configuration options: [CRT] [EFP] [LFP] [CRT+EFP] [CRT+LFP] Flat Panel Type [800x600 LVDS] Allows you to secect panel type mode device. - Page 45 Power Management/APM [Enabled] Allows you to enable or disable the Advanced Power Management (APM) feature. Configuration options: [Disabled] [Enabled] Power Type Select [ATX] Allows you to select the power type mode. Configuration options: [ATX] [AT] Video Power Down Mode [Suspend] Allows you to select the video power down mode.
- Page 46 goes on suspend. Configuration options:[Disabled] [1 Min] [2 Min] [4 Min] [8 Min] [10 Min] [20 Min] [30 Min] [40 Min] [50 Min] [60 Min] Throttle Slow Clock Ratio [50%] Allows you to select the duty cycle in throttle mode. Configuration options: [87.5%] [75.0%] [62.5%] [50%] [37.5%] [25%] [12.5%] Keyboard &...
-
Page 47: Exit
4.13 Exit The Exit menu items allow you to load the optimal or failsafe default values for the BIOS items, and save or discard your changes to the BIOS items. Save Changes and Exit Once you are finished making your selections, choose this option from the Exit menu to ensure the values you selected are saved to the CMOS RAM. - Page 48 a confirmation appears. Select [Yes] to discard any changes and load the previously saved values. Load Optimal Defaults This option allows you to load optimal default values for each of the parameters on the Setup menus. F9 key can be used for this operation.
-
Page 49: Appendix A. Watchdog Timer
Appendix A. WatchDog Timer The WatchDog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash. This condition may have occurred by external EMI or a software bug. When the CPU stops working correctly, hardware on the board will either perform a hardware reset (cold boot) or a Non-Maskable Interrupt (NMI) to bring the system back to a known state. -
Page 50: Example Program
Note: when exiting a program it is necessary to disable the WatchDog Timer, otherwise the system will reset. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ; ADD YOUR APPLICATION PROGRAM HERE EXIT_AP, 1 ;is your application over? W_LOOP... -
Page 51: Appendix B: Digital I/O
This kind of response is highly needed for harsh and critical industrial operating environment. That’s why we design 4-bit digital inputs and 4-bit digital outputs on the JUKI-6770. Digital Input and Output, generally, are control signals. You can use these signals to control external devices that needs On/Off circuit or TTL devices. - Page 52 Digital Output is 1001b...
-
Page 53: Appendix C. Resources Map
Appendix C. Resources Map 1 st MB Memory Address Map Memory address Description 00000-9FFFF SYSTEM MEMORY A0000-BFFFF VGA BUFFER C0000-CFFFF VGA BIOS E0000-FFFFF SYSTEM BIOS 100000 EXTEND MEMORY IRQ Mapping Chart IRQ0 System Timer IRQ8 RTC clock IRQ1 Keyboard IRQ9 SCI IRQ user by ACPI bus IRQ2 IRQ Controller...
