Owner's Manual
CARDIOMAX 560 RECUMBENT

Customer Service

1.888.340.0482
Keys Fitness
4009 Distribution Drive
Suite 250
Garland, TX 75041
www.keysfitness.com
315-00011
05/06 Rev D
560R
Model Name :560r
Serial Number :
Write down for future reference
Serial Number Decal Location
Please read the precautions and instructions
in this manual before using this equipment.
Please save this manual for future reference.
CAUTION!
