Enlarged version
835
Recumbent
OWNER'S MANUAL
QUESTIONS?
Call Our Toll Free
Keys Fitness Helpline
1-888-340-0482
1-888-340-0482
Monday-Friday
8:30-5:30 Central Time
CAUTION!
Keys Fitness Products, L.P.
Please read the precautions and
Keys Fitness Products, L.P.
P.O. Box 551239
instructions in this manual before
4009 Distribution Dr.
using this equipment. Please save this
Dallas, Texas 75355-1239
Suite 250
manual for future reference.
Garland, Texas 75041

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 835R and is the answer not in the manual?

Questions and answers

Meg
January 23, 2025

Pedaling the bike is not registering on the monitor. Heart rate seems to work but everything else is 0

0
1 comments:
Mr. Anderson
February 10, 2025

The monitor on the Keys Fitness 835R bike may not be registering pedaling activity due to one of the following reasons:

1. Computer Cable Connection – The computer cable in the console tube may not be properly connected to the main frame or the console. Ensure that all computer cable connections are secure.
2. Pulse Wires Connection – If the pulse wires in the front handlebar are not properly connected, it may affect the functionality of the monitor.
3. Wear Items – Certain components like pedal sensors or wiring may have worn out due to regular use, affecting data transmission.

Checking and securing these connections should help restore the monitor’s functionality.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for Keys Fitness 835R

Summary of Contents for Keys Fitness 835R

  • Page 1 Keys Fitness Helpline 1-888-340-0482 1-888-340-0482 Monday-Friday 8:30-5:30 Central Time CAUTION! Keys Fitness Products, L.P. Please read the precautions and Keys Fitness Products, L.P. P.O. Box 551239 instructions in this manual before 4009 Distribution Dr. using this equipment. Please save this...

  • Page 2: Limited Warranty

    Please contact a Keys Fitness customer service representative for specifics on wear items. This Limited Warranty becomes VALID ONLY if the product is purchased through a Keys Fitness authorized dealer unless otherwise authorized by Keys Fitness in writing.

  • Page 3: Before You Start

    This is especially important for persons over the age of 35 and/or persons with pre-existing health problems. Keys Fitness Products LP assumes no responsibility for personal injury or proper- ty damage sustained by or through the use of this product.

  • Page 4: Assembly Parts

    ASSEMBLY PARTS PART CONSOLE FRONT HANDLEBAR REAR HANDLEBAR CONSOLE TUBE SEAT CUSHIONS SEAT CARRIAGE FRAME FOOT TUBES PEDALS FOOT CAPS WHEELS CARRIAGE TUBE SUPPORT TUBE END CAP PART NO. 9, 10 30, 31...
  • Page 5 Assembly of CardioMax 835 Recumbent Bike REMOVE ALL SECURITY TAPE AND WRAPPING BEFORE BEGINNING. 1. Attach foot tubes (4) to the frame by using the carriage bolts (44), flat washers (50) and cap nuts ( 45) provided. Make sure the foot tube with wheels is assembled onto the front of the unit.
  • Page 6 3. Attach pedals (30, 31). Axles of pedals are branded “L” and “R.” The pedal marked “R” goes on the right hand side of the bike and the one marked “L” on the left hand side. Tighten the left pedal by turning counter-clockwise and the right pedal by turning clockwise.
  • Page 7 5. Connect the computer cable at the top of the console tube (2) to the console (5). Both computer cable connections have white ends. Feed the pulse wires from the console (5) down into the console tube (2) and out the rear hole in the handlebar area.
  • Page 8 7. Load your console with the batteries provided. Batteries are 4 8. You have completed the assembly of your new CardioMax bike. “AA” size.
  • Page 9 835 RECUMBENT PARTS LIST PART PART FRAME 45 M8 CAP NUT CONSOLE TUBE 46 M6 LOCKNUT SEAT CARRIAGE 47 6mm HEX NUT FOOT TUBE 48 M10 CAP NUT CONSOLE 49 M8 LOCKNUT PULLEY 50 M8 IDX18.8mm OD14 MAG BRAKE FLAT WASHER SENSOR 51 M20X32X2mm WASHER SEAT CUSHION...
  • Page 10 CM835 Display Instructions BUTTON FUNCTIONS MODE Press to select between functions: TIME, DISTANCE, CALORIES, and PULSE for target presetting. Press to preset the target values of TIME, DISTANCE, CALORIES, and PULSE. RESET Press to reset a function window to zero. To clear out the readings in all of the console windows, you must press and hold the Reset button for 3 seconds.

  • Page 11: Monitoring Your Heart Rate

    To set the countdown function for Time, Calories, or Distance: Press the Mode key until the correct screen has been chosen. Press the Set key until the desired reading appears in the window you are setting. If the countdown mode is set for the Time, Calories, or Distance before your workout begins, then the console will alert you when you have reached your goal with an audible beeping.

  • Page 12: Target Heart Rate Zone

    Check your pulse recovery rate – If your pulse is over 100 bpm five minutes after you stop exercising, or if it’s higher than normal the morning after exercising, your exertion may have been too strenuous for your current fitness level. Rest and reduce the intensity next time.
