MODEM-CN Connector
CD-IN Connector
Onboard AC97 CODEC Chip
AUX-IN Connector
Onboard Buzzer
AGP 4x Expansion Slot
CNR Expansion Slot
32-bit PCI Expansion Slot x6
Intel i815EP Chipset with ICH2 and
Pure Aluminum Heatsink
WOL Connector
WOM Connector
GPO Connector
Dr. LED Connector (User Optional)
Front Panel Audio Connector
Die Hard BIOS (Upgrade Optional for
AX3SP Pro Only)
Chassis Fan Connector
Front Panel Connector
nd
Supports 2
USB Port
JP14 CMOS Clear Jumper
JP30 Die Hard BIOS Select Jumper
JP15 & 16 Dr. Voice Language
Select Jumper
SPP/EPP/ECP Parallel Port
PS/2 Mouse
Connector
USB Port
PS/2 Keyboard
COM 1 Port
Connector
MIDI/Game Port
COM 2 Port
MIC-In
Line-In
Speaker Out
Resettable Fuse
JP28 KB/Mouse Wakeup
Select Jumper
Low ESR Capacitor
ATX Power Connector
AUX Fan Connector w/o
H/W Monitoring Function
370-pin CPU Socket with Voltage
and Frequency Auto-detection that
®
®
supports Intel
Pentium
III &
Celeron™ 300~1000+ CPU
CPU Fan Connector with
H/W Monitoring Function
168-pin DIMM Socket x3 that
supports PC100/1333
SDRAM up to 512MB
FDD Connector
ATA/100 IDE Connector x2
JP23 FSB Select Jumper
Advertisement
Table of Contents
Related Manuals for AOpen AX3SP
Summary of Contents for AOpen AX3SP
- Page 1 CPU Fan Connector with H/W Monitoring Function Front Panel Audio Connector 168-pin DIMM Socket x3 that Die Hard BIOS (Upgrade Optional for supports PC100/1333 AX3SP Pro Only) SDRAM up to 512MB Chassis Fan Connector Front Panel Connector FDD Connector Supports 2...
-
Page 2: Jp14 Clear Cmos
Floppy Disk Drive Cable x1 this function. 80-wire IDE Cable x1 Bonus Pack CD Disk x1 NORTON AntiVirus CD x1 AX3P/AX3SP Pro EIG x1 AX3SP/AX3SP Pro Online Manual x1 (AX3SP Pro Only) JP28 KB/Mouse Wake-up Enable Disable (Default) PART NO: 49.87A08.001... -
Page 3: Installing Cpu
3. Installing CPU 5. Setting CPU Voltage & Frequency Setting CPU Core Voltage CPU Pin 1 and cut edge This motherboard supports CPU VID function. The CPU core voltage will be automatically detected and the range is from 1.3V to 3.5V. It is not necessary to set CPU Core Voltage Pull up the CPU socket level and up to 90-degree angle. -
Page 4: Connecting Front Panel Cable
(Default) 7. Install DIMM Modules 9. Connecting Front Panel Cable This motherboard has three 168-pin DIMM sockets that allow you to install PC100 or PC133 memory up to 512MB. The AX3SP/AX3SP Pro supports non-ECC/ECC and SPWR Registered SDRAM. IDE LED ACPI &... -
Page 5: Front Panel Audio
12. Connecting CD / Modem /AUX-IN Connector 10. Connecting ATX Power Connector The ATX power supply uses 20-pin connector shown below. Make sure you plug in the AUX-IN The CD-IN connector is used to connect CD Audio (Green) cable from CDROM or DVD drive to onboard sound. right direction. -
Page 6: Bios Upgrade
15. AOpen Bonus Pack CD 17. BIOS Upgrade AOpen Easy Flash is more user-friendly than traditional flash method. The BIOS binary You can use the autorun menu of Bonus CD disc. Choose the utility and driver and select file and flash routine are combined together and you simply run a single file to complete model name. -
Page 7: Part Number And Serial Number
IDE cable. The problem should be caused by the Check if the system can IDE cables or HDD itself. reboot successfully. Re-install Windows 95, Windows 98 or Windows NT. AX3SP Pro is model name of motherboard; R1.00 is BIOS version... - Page 8 Dear Customer, Test Report: We recommend to choose board/card/device from the Thanks for choosing AOpen products. To provide the best and fastest service to compatibility test reports for assembling your PC. our customer is our first priority. However, we receive numerous emails and http://www.aopen.com.tw/tech/report/default.htm...
