Table of Contents

Warranty .................................................................................................................................................2
Warnings.................................................................................................................................................3
Grounding Instructions.............................................................................................................................4
115V Operation .......................................................................................................................................4
230V Operation .......................................................................................................................................5
Table of Contents ....................................................................................................................................6
Specifications ..........................................................................................................................................6
Contents of the Shipping Container .........................................................................................................7
Tools Included for Assembly....................................................................................................................7
Tools Required for Assembly ...................................................................................................................7
Unpacking and Cleanup...........................................................................................................................7
Installation and Leveling ..........................................................................................................................8
Motor Cover Assembly ............................................................................................................................8
Extension Wing Assembly .......................................................................................................................8
Hand Wheel Assembly ............................................................................................................................9
Blade Guard Assembly .......................................................................................................................9-10
Installing Blade ......................................................................................................................................10
Aligning Blade Guard and Splitter ..........................................................................................................10
Table Insert Adjustment .........................................................................................................................11
Mounting Rails & Extension Table .........................................................................................................11
Miter Gauge Operation ..........................................................................................................................11
Blade Raising & Tilting Mechanism........................................................................................................11
Adjusting 45 and 90 Positive Stops.....................................................................................................12
Wear Adjustment in Raising Mechanism................................................................................................12
Wear Adjustment in Tilting Mechanism..................................................................................................13
Electrical Connections ...........................................................................................................................13
Changing Belts ......................................................................................................................................13
Troubleshooting.....................................................................................................................................14
Cabinet & Table Assembly Parts Breakdown .........................................................................................15
Cabinet & Table Assembly Parts List ................................................................................................16-17
Motor & Trunnion Assembly Parts Breakdown .......................................................................................18
Motor & Trunnion Assembly Parts List ..............................................................................................19-20
Electrical Schematic ..............................................................................................................................21

Specifications

Stock Number................................................................................................................................ 708435
Blade Diameter.................................................................................................................................... 10"
Arbor Diameter ................................................................................................................................... 5/8"
Maximum Depth of Cut.................................................................................................................... 3-1/8"
Maximum Rip to Right of Blade ........................................................................................................... 30"
Maximum Rip to Left of Blade ............................................................................................................. 12"
Maximum Thickness at 45 Cut ....................................................................................................... 2-1/8"
Table in Front of Saw Blade at Maximum Cut................................................................................ 11-1/4"
Maximum Width of Dado .................................................................................................................13/16"
Dust Chute Diameter ............................................................................................................................. 4"
Table Height .................................................................................................................................. 34-1/2"
Table Size (with extension)....................................................................................................27"D x 30"W
Table Size (without extension) ...............................................................................................27"D x 20"W
Spindle Speed .......................................................................................................................... 3400 RPM
Motor Size .................................................................................. 1-3/4 HP, 1Ph, 115/230V Prewired 115V
Net Weight (approx.) .................................................................................................................... 277 lbs.
Shipping Weight (approx.) ............................................................................................................ 317 lbs.
The specifications in this manual are given as general information and are not binding. JET Equipment & Tools reserves
the right to effect, at any timeand without prior notice, changes or alterations to parts, fittings, and accessory equipment
deemed necessary for any reason whatsoever.
6
JWCS-10A
