Main Combi 24 HE User Manual page 5

Supplied by HeatingSpares247.com
Is the Timer ON and calling for
heat ?
Typical
examples of
external timer
CH ON
NO
Ensure timer is set for Central
Heating ON (see any
instructions supplied with
timer).
CONTACT YOUR
INSTALLER OR
SERVICE ENGINEER.
If you don't know what you need to do to
get the boiler to light, or need help with
the system and controls, contact your
© Baxi Heating UK Ltd 2011
12
6
CH OFF
installer as soon as possible.
Is the Room Thermostat (if
YES
fitted) set high enough ?
NO
Turn Room Thermostat to
maximum setting (typical
example shown).
2.0 Troubleshooting
YES
15
15
5
