Summary of Contents for Beko WM 6111 W
- Page 1 Automatic washing machine WM 6111 W...
- Page 2 Please read this user manual first! Dear Customer, We hope that you get the best results from the product which has been manufactured in state-of-the-art plants and passed through a strict quality control procedure. Therefore, please read the entire user manual carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Your washing machine 5 Operating the product Overview ......4 Control panel....18 Technical specifications . -
Page 4: Your Washing Machine
Your washing machine Overview 1- Power cable 5- Adjustable feet 2- Top panel 6- Loading door 3- Control panel 7- Detergent drawer 4- Filter cap 8- Drain hose... -
Page 5: Technical Specifications
Technical specifications Models WM6111W Maximum dry laundry capacity (kg) Height (cm) Width (cm) Depth (cm) Net weight (±4 kg.) Electrical input (V/Hz) 230 V / 50Hz Total current (A) Total power (W) 2200 Spin speed (rpm max.) 1200 Stand-by mode power (W) 1.00 Off-mode power (W) 0.25... -
Page 6: Important Safety Instructions
Important safety instructions This section contains safety instructions injury from hot water will occur. that will help protect from risk of personal • Do not force open the locked loading injury or property damage. Failure to follow door. The loading door will be ready these instructions shall void any warranty. - Page 7 let them to tamper with the product. Use child lock to prevent children from intervening with the product. • Do not forget to close the loading door when leaving the room where the product is located. • Store all detergents and additives in a safe place away from the reach of the children.
-
Page 8: Installation
Installation Refer to the nearest Authorised Service Removing packaging Agent for installation of the product. To reinforcement make the product ready for use, review Tilt the machine backwards to remove the information in the user manual and the packaging reinforcement. Remove the make sure that the electricity, tap water packaging reinforcement by pulling the supply and water drainage systems are... -
Page 9: Connecting Water Supply
3. Attach the plastic covers supplied in the User Manual bag into the holes on the rear panel. (P) Keep the transportation safety bolts in a safe place to reuse when the washing Ensure that the cold and hot water machine needs to be moved again in connections are made correctly when the future. -
Page 10: Adjusting The Feet
• In case the hose is elevated after laying it on the floor level or close to the ground (less than 40 cm above the ground), water discharge becomes more difficult and the laundry may come out excessively wet. Therefore, follow the heights described in the figure. -
Page 11: First Use
fuse. Connect the green - yellow or green (earth) wire to the terminal in the plug • The specified voltage must be equal to marked ‘E’ or with the symbol f or your mains voltage. coloured green and yellow or green. •... -
Page 12: Disposing Of Packaging Material
Disposing of the old product anti-limescale into the main wash detergent compartment (compartment nr. Dispose of the old product in an II). If the anti-limescale is in tablet form, environmentally friendly manner. put only one tablet into compartment nr. Refer to your local dealer or solid waste II. -
Page 13: Preparation
Preparation Things to be done for energy saving Following information will help you use the product in an ecological and energy- Wash with sensitive, Washing water efficient manner. .short programmes temperature • Operate the product in the highest capacity allowed by the programme you have selected, but do not overload;... -
Page 14: Correct Load Capacity
and the washing programme desired. The machine automatically adjusts the amount of water according to the weight of the loaded laundry. Follow the information in the “Programme and consumption table”. When overloaded, machine’s washing performance will drop. Moreover, noise and vibration problems may occur. Laundry types and their average weights in •... -
Page 15: Using Detergent And Softener
Using detergent and softener • When washing dark coloured clothes and quilts, it is recommended to use Detergent Drawer liquid detergent. The detergent drawer is composed of three • Wash woolens with special detergent compartments: made specifically for woolens. - (I) for prewash Use only detergents manufactured - (II) for main wash specifically for washing machines. - Page 16 detergent between the laundry, close to the lower part of the drum in future washings. Use the tablet or gel detergent without selecting the prewash function. Using starch • Add liquid starch, powder starch or the dyestuff into the softener compartment as instructed on the package.
-
Page 17: Tips For Efficient Washing
Tips for efficient washing Clothes Light colours and Delicates/ Colors Dark colors whites Woolens/Silks (Recommended (Recommended (Recommended (Recommended temperature temperature temperature range temperature range range based range based based on soiling based on soiling level: on soiling level: on soiling level: level: 40-90C) cold-40C) cold-40C) -
Page 18: Operating The Product
Operating the product Control panel 1 - Programme Selection knob 2 - Spin Speed Adjustment button* 3 - Temperature Adjustment button* 4 - Start / Pause / Cancel button 5 - Auxiliary Function buttons 6 - On / Off button 7 - Programme Follow-up indicator 8 - Loading Door light* * Varies depending on the model of your machine. -
Page 19: Preparing The Machine
Preparing the machine water temperature may differ from the declared cycle temperature. Programme 1. Make sure that the hoses are duration may automatically be shortened connected tightly. during later stages of the programme if you 2. Plug in your machine. wash less amount (e.g. -
Page 20: Temperature Selection
programme. It gives the same result with laundry at the desired speed by using this the Cottons 60 °C programme by washing button. for a longer time at 40 °C, thus enabling In models not equipped with Spin Speed energy saving. Adjustment button, spin will be performed Special programmes at the recommended speed for the... -
Page 21: Programme Selection And Consumption Table
Programme selection and consumption table Programme Cottons 1.65 • • • • • • Cottons 60** 1.01 • • • • • • Cottons 60** 0.86 • • • • • • Cottons 40** 0.62 • • • • • •... -
Page 22: Auxiliary Function Selection
Auxiliary function selection In models equipped with Spin Speed Adjustment button, select the Spin Speed Select the desired auxiliary functions before and press Start / Pause / Cancel button if starting the programme. Furthermore, you you want to spin the laundry held in water. can also select or cancel auxiliary functions In models not equipped with Spin Speed that are suitable to the running programme... -
Page 23: Progress Of Programme
simultaneously after washing programme Even if you select a new program has started. 1. The 1st Auxiliary Function by changing the position of the light flashes continuously. Programme Selection knob while the To deactivate the Child Lock: machine is running or in Pause mode, Child lock must be deactivated to start a the programme selected first will new programme after the programme has... -
Page 24: Canceling The Programme
Canceling the programme Press and hold Start / Pause / Cancel button for 3 seconds to cancel the current programme. At the end of this period, machine can drain the water inside it or can take in and drain water up to 3 times to cool down the laundry. -
Page 25: Maintenance And Cleaning
Maintenance and cleaning inside of the bellow with a clean piece of Service life of the product extends and cloth after the programme has come to an frequently faced problems decrease if end. cleaned at regular intervals. Repeat Drum Cleaning process in every Cleaning the detergent drawer 2 months. -
Page 26: Draining Remaining Water And Cleaning The Pump Filter
the water in the machine cools down. 2. Open the filter cap. If the filter cap is composed of two pieces, press the tab on the filter cap downwards and pull the piece out towards yourself. 1. Close the taps. 2. - Page 27 is emptied, repeat the above procedure to drain the water in the machine completely. c. When draining of water is finished, close the end by the plug again and fix the hose in its place. d. Turn the pump filter to take it out. Discharging the water when the product does not have an emergency draining hose:...
-
Page 28: Troubleshooting
Troubleshooting Programme cannot be started or selected. • Washing machine has switched to self protection mode due to a supply problem (line voltage, water pressure, etc.). >>> Press and hold Start / Pause / Cancel button for 3 seconds to reset the machine to factory settings. (See "Canceling the programme") Water in the machine. - Page 29 Loading door cannot be opened. • Door lock is activated because of the water level in the machine. >>> Drain the water by running the Pump or Spin programme. • Machine is heating up the water or it is at the spinning cycle. >>> Wait until the programme completes.
- Page 30 Machine does not switch to spinning step. • There might be an imbalance of laundry in the machine. >>> Automatic unbalanced load detection system might be activated due to the unbalanced distribution of the laundry in the drum. Machine does not switch to spinning step when the laundry is not evenly distributed in the drum to prevent any damage to the machine and to its surrounding environment.
- Page 31 Colour of the clothes faded. • Excessive laundry was loaded in. >>> Do not load the machine in excess. • Detergent in use is damp. >>> Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures. •...
- Page 32 Detergent residue in the detergent drawer. • Detergent is put in wet drawer. >>> Dry the detergent drawer before putting in detergent. • Detergent has gotten damp. >>> Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures. •...
- Page 33 Foam is overflowing from the detergent drawer. • Too much detergent is used. >>> Mix 1 tablespoonful softener and ½ l water and pour into the main wash compartment of the detergent drawer. Put detergent into the machine suitable for the programmes and maximum loads indicated in the “Programme and consumption table”.
-
Page 34: Guarantee
Republic of Ireland. items. • The guarantee is applicable only to • The labour costs of a Beko approved new products and is not transferable if repairer to carry out the repair. the product is resold. • Beko disclaims any liability for What is not covered? incidental or consequential damages. -
Page 35: Service
Should you experience any difficulty in require attention under guarantee. obtaining service please contact the Beko Customer Help-Line. You should also complete the details Tel: 0845 600 4911 below;...
