Plinius 8150 instruction manual. Page 1
CONGRATULATIONS on your decision to become the proud owner of the
PLINIUS 8150 fully Integrated Amplifier.
This manual has been prepared to help you understand the operation of your amplifier and
to provide some information about its design and the variety of ways it may be used.
We have designed and manufactured this amplifier to faithfully and accurately reproduce
music. This hand built instrument should give a lifetime of pleasure and with a little care
and a full understanding of the operating recommendation in this manual the Plinius 8150
should provide trouble free performance.
Every component used within the 8150 has been chosen for sonic excellence and the
potentiometers have been selected from Audiophile quality types.
Serial Number:
Date of Manufacture:
Final Test Certified by:
Phono stage set for:
Moving Magnet.
Moving Coil.
PLEASE TAKE TIME TO READ THIS MANUAL THOROUGHLY BEFORE
USING YOUR AMPLIFIER.

Advertisement

loading
Need help?

Need help?

Do you have a question about the PLINIUS 8150 and is the answer not in the manual?

Questions and answers

Related Manuals for Plinius PLINIUS 8150

Summary of Contents for Plinius PLINIUS 8150

  • Page 1 We have designed and manufactured this amplifier to faithfully and accurately reproduce music. This hand built instrument should give a lifetime of pleasure and with a little care and a full understanding of the operating recommendation in this manual the Plinius 8150 should provide trouble free performance.

  • Page 2: Table Of Contents

    Plinius 8150 instruction manual. Page 2 LIST OF CONTENTS Warnings and precautions. Page Amplifier Facilities and Features. FRONT PANEL. Amplifier Facilities and Features. REAR PANEL 5, 8 Installation and operation. Mains / Line power connection. 8, 9 Connections for operation.
  • Page 3 Plinius 8150 instruction manual. Page 3 WARNING The 8150 control amplifier can be operated in excess of 150 Watts into 8 Ohms. This amplifier is also capable of a very large peak current delivery. This 8150 control amplifier operates in Class AB and is therefore capable of generating a moderate temperature and requires careful placing to avoid any effect this heat may have on other equipment, furniture and fittings etc.

  • Page 4: Plinius 8150 Instruction Manual

    Plinius 8150 instruction manual. Page 4 AMPLIFIER FACILITIES AND FEATURES FRONT PANEL The front panel of the 8150 power amplifier incorporates a panel fitted with one switch, and three knobs. These control the day to day functions of the amplifier. These controls are from the left;...
  • Page 5 Two pairs of heavy duty, gold plated five way binding posts for each channel are supplied for bi-wiring or standard speaker connection. PRE OUT is provided to allow connection of another Power Amplifier/s, for bi-amping or multi speaker installations. Plinius 8150 instruction manual. Page 6...
  • Page 6 PROCESSOR LOOP allows connection of an external home theatre type processor. When connected to the 8150 the selection of PROCESSOR from the switch above the input sockets will divert the signal directly from the processor to the amplification stages by-passing the amplifiers volume control. This means that all control is managed by the processor and the amplifier becomes a slave unit.

  • Page 7: Installation And Operation

    PLINIUS The PLINIUS 8150 Control Amplifier should be left switched on at all times. If the 8150 is switched off between listening sessions you will never hear just how good it really sounds. In our experience a 48 hour warmup period is required during which the sound quality will change quite dramatically.

  • Page 8: Mains / Line Power Connection

    Plinius 8150 instruction manual. Page 8 REAR PANEL CONNECTIONS All input connections are clearly marked REAR PANEL LAYOUT TAPE CONNECTIONS AND DUBBING If two tape decks are fitted to the 8150 it is possible to dub in either direction. Selecting either Tape Input with the Record Selector automatically sends the tape playback signal to the other tape deck.

  • Page 9: Loudspeakers

    Plinius 8150 instruction manual. Page 9 MAINS / LINE FUSE. A Mains / Line fuse is fitted within the IEC Mains / Line socket on the rear of the amplifier. A small drawer at the bottom of this socket may be removed ( after the IEC plug is removed ) by levering it out with a flat blade screw driver.

  • Page 10: Remote Control Maintenance

    The Voltages present on the circuit board could be harmful. In the unlikely event that your PLINIUS 8150 should require any service please take it firstly to your Dealer in its original packaging. He will then determine if the unit should be returned to the factory.

  • Page 11: Specifications

    Plinius 8150 instruction manual. Page 11 Specifications: 150 Watts continuous power per channel into 8 ohms, both channels driven from 20Hz to 20kHz at less than 0.1% Total Harmonic Distortion from 0.25 Watts to rated output. 230 Watts continuous power per channel 20Hz to 20kHz into 4 ohms.

  • Page 12: Appendix 1

    Plinius 8150 instruction manual. Page 12 Tape loop muting at 5V RMS input. All operational, technical and descriptive material published here is subject to change at any time without notice. amplifiers are designed and manufactured by: PLINIUS AUDIBLE TECHNOLOGIES Ltd.
