American Standard Hampton 5' Drop-in Whirlpool 2425.018W Specifications

HAMPTON™ 5' DROP-IN WHIRLPOOL
2425.018W Whirlpool featuring System I
• Acrylic with fiberglass reinforcement
• Pre-leveled tub bottom
• Form-fitted backrest
• Dual, molded-in arm rests
• 1.5 HP single speed, self-draining pump/motor
• Factory-installed power cord with plug
• Eight multi-directional and flow-adjustable jets
including:
- Two Ideal-flow jets
- Four body massage jets
- Two recessed back-rest jets
• Deck-mounted air switch On/Off
• Two silent air volume controls
• Quick Connect Safe-T-Heater connection
system
• Factory installed and tested whirlpool system
Whirlpool Massage featuring System I
2425.018WC StayClean™ Whirlpool Massage
featuring System I:
• Same as above except with the StayClean™
whirlpool system featuring Antimicrobial
AlphaSan®
Nominal Dimensions:
60" x 32" x 21-1/2" (1524 x 813 x 546mm)
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
NOTE: Roughing-in dimensions and product
specifications shown on reverse side of page.
3/03
To Be Specified - Required:
Color:
Bath Faucet: (specify finish)
Bath Drain: 1583.470 (specify finish)
To Be Specified - Optional:
Safe-T-Heater*: 9075.120
Bath Caddie: 9533.100 (in Chrome only)
Jet Trim Ring Kit: 9860.200-two per kit (specify finish)
For color/finish availability and other faucet choices,
please see the Product Selector and Pricing Guide.
* NOTE: the Safe-T-Heater is designed to maintain water
temperature during operation. It will not heat cold water to
desired bathing temperature.
© 2003 American Standard Inc.
HAMPTON™ 5' DROP-IN
WHIRLPOOL
HIGH GLOSS ACRYLIC
BV-20
