American Standard Hampton 5' x 32" 2425.XXXW-LHO Installation Instructions

HAMPTON 5' x 32"™
INTEGRAL APRON WITH
REMOVABLE ACCESS PANEL
HIGH GLOSS ACRYLIC
SHOWN LESS ALL FITTINGS
12
(305mm)
10-1/4
(260mm)
3/4
(19mm)
FINISHED
WALL
SEE FITTING
SPECS FOR
DIMENSIONS
9
(229 mm)
32
(813mm)
CUTOUT IN FLOOR FOR DRAIN
C/L OF
3
SUPPLIES
(76mm)
C/L OF DRAIN
OPTIONAL TO
FINISHED FLOOR
1" WATER
USUALLY BETWEEN
RETENTION
65 & 78
FLANGE
(1651 & 1981mm)
(3 SIDES)
C/L OF
OVERFLOW
3-1/2
(89mm)
TOP OF
DECK
21-1/2
(546mm)
ROUGH
FLOOR
BATH
SUPPORT
MATERIAL
1-1/2 O.D.TAILPIECE
Left-hand version shown
GENERAL SPECIFICATIONS FOR 2425 WHIRLPOOL
INSTALLED SIZE 60 x 32 x 21-1/2 (1524 x 813 x 546mm)
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
WHIRLPOOL MIN. OPERATING VOL.
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
3
CUBE (FT )
WHIRLPOOL ELECTRICAL SPECIFICATIONS
PUMP
General Installation Information
Bath may only be installed in a recess type installation.
Locate studs as required. insure rough dimensions are proper, plumb and square. For whirlpools, access to pump/motor may be made
through access opening in apron panel. The following procedure must be used for all installations: leveling support stringer should be as
indicated. this bath is not self-supporting and must be supported along it's entire bottom. Support with mortar or grout. Position
bathtub/whirlpool within the recess, check level, front to back, side to side, and shim as necessary. To secure the tub to wood studs use
drywall screws w/washers or roofing nails immediately above the flange of the tub.To secure the tub to steel studs use 4" drywall screws and
flatwashers.
See page 2 for complete installation information.
Caution: Take extra care when driving nails or screws to avoid damaging the tub. The tile or similar finished floor will be butted against
the bottom of the tub apron, also holding the tub in place.
FOR AFTER-SALES SERVICE CALL 1 (800) 442-1902 WEEKDAYS.
753456-100 REV. A
2425.XXXW-LHO
2425.XXXW-RHO WHIRLPOOL

INSTALLATION INSTRUCTIONS

60
(1524mm)
WATER
RETENTION
FLANGE
(8) JETS (3 SIDES)
(406mm)
PUMP
ACCESS TO PUMP/MOTOR
(2) AIR VALVES
THROUGH REMOVABLE
FRONT ACCESS PANEL
C/L OF
SHOWER ARM
FINISHED
WALL
SAFE-T-HEATER
REMOVABLE
C/L OF
BLANK
VALVES
C/L OF
12
SPOUT
(305mm)
OPT.
4 TILING
LEVELING STRINGER
(102 mm)
NOT FOR SUPPORT
FLANGE
UNDERSIDE
OF DECK
21-1/4
(540mm)
REF.
DIM
1-1/2 N.P.T.M.
THREADS 2-3/4
(70mm)
4-5/8
(117mm)
115 Lbs. (52 Kg.)
574 Lbs. (258 Kg.)
55 Gal. (208 L.)
45 Gal. (171 L.)
16-1/4 x 38-1/4 (413 x 972mm)
26-1/4 x 52-1/2 (667 x 1334mm)
15 (381mm)
43 Lbs./Sq.Ft. (208 Kgs./Sq.m)
20.8
35.3
1.6 HP, 9.7 AMPS,120V.

THANK YOU...

for selecting an American Standard bath. Your new bath is shipped to
you after careful inspection. the whirlpool version is completely
assembled with pump, motor, and system piping. All you need to finish
the installation are your selected fittings and electrical connections for
a whirlpool. To insure maximum performance and pleasure from this
16
product, please follow the instructions and cautions.
List of Optional Components (not included):
ON/OFF
• Safe-T-Heater 9075.120*
SWITCH
List of Required Components (not included):
• Drain 1583.470*
* see your American Standard Dealer
List of Required Tools and Supplies:
Tools
• Level
• Tape Measure
• Pipe Wrench
• Slip Joint Pliers
• Screw Driver
• Standard
Woodworking Tools
• Personal Safety
Equipment
• Caulking Gun
General Installation Information
Carefully uncrate and inspect your new bath for any shipping damage.
If such damage is found, report it to your vendor immediately. After
inspection and during installation, protect the bath from construction
damage. Before installation, and before enclosing with wallboard,
tile, etc., water test the unit and check for leaks. Do not make
modifications to the whirlpool system or remove pump from factory
mounting. This could adversely affect the safety and performance of
the whirlpool and void the warranty. Do not handle or move the
whirlpool by the pump, motor, or piping system. Fittings (bath filler,
shower arm, etc.) are not provided with the bath and must be ordered
separately. Framing and enclosing materials are provided by others.
IMPORTANT: Water test unit before installation and
enclosure!
• Bath Filler*
Supplies
• Nails
• Putty
• Caulking (waterproof)
• 1 x 3 or 2 x 2
Stringers
• Drop Cloth
• 15 amp GFI
Outlet
• Cement, Plaster,
Grout
© American Standard Inc. 2003
All product names listed herein are trademarks
of American Standard Inc. unless otherwise noted.
