- Page 1 RADIO CASSETTE RECORDER WITH CD Freezz 20 RRCD 4301 PLL...
- Page 2 ________________________________________________________________ Sicherheit und Pflege Radio-Betrieb DEUTSCH Auf einen Blick CD-Betrieb Stromversorgung Cassetten-Betrieb Einstellungen Informationen Allgemeine Funktionen 1165 Service Care and safety Radio mode ENGLISH Overview CD mode Power supply Tape mode Settings Information General functions Service Sécurité et entretien Fonction radio FRANÇAIS Vue d’ensemble Fonction lecteur CD...
-
Page 3: Care And Safety
CARE AND SAFETY ______________________________ ENGLISH To ensure that this device provides you with long-term satisfaction and enjoyment, please observe the following instructions. This device is designed for the recording and playback of audio signals. Any other use is expressly prohibited. Protect the device, the CDs and cassettes from rain, moisture (dripping or splashing water), sand and heat. - Page 4 OVERVIEW ___________________________________________ Controls ANETENNA re e z z 2 0 PHONES CLOSE TAPE DIRECTION General Switches the device on and off. ON/OFF Switches between the CD, radio and tape modes. CD•RADIO•TAPE Switches the Ultra Bass System on and off. Adjusts the volume. VOLUME + –...
- Page 5 OVERVIEW ____________________________________________ For storing radio stations. MEMORY/PROG PRESET UP/ To select stored radio stations (Presets); to select REPEAT preset positions. To switch to mono reception during poor stereo 1 BEAT CUT 2 reception (FM), at the back of the device. MONO/STEREO CD unit Opens and closes the CD compartment.
- Page 6 OVERVIEW ____________________________________________ The display The Ultra Bass System is activated. TUNER TAPE In radio mode: displays the station position and the 00 00:00 MEMORY INTRO RANDOM REPEAT frequency. 00 : 00 Indicates RADIO as the input source. TUNER Station position display. MEMORY Displays the waveband.
-
Page 7: Power Supply
POWER SUPPLY ___________________________________ Mains operation Note: Check that the mains voltage on the type plate (on the bottom of the device) corresponds to your local mains supply. If this is not the case, contact your specialist dealer. Insert the mains cable supplied (in the battery compartment) in the AC MAINS »AC MAINS «... -
Page 8: Additional Information For Units Sold In The Uk
“E”, earth symbol “ ”, coloured green, or green & yel- low. Replacement mains lead sets can be obtained from your local dealer, or by contacting Grundig Consumer Relations (01788 570088) Moulded 3-pin lead set, suitable for UK use: Ref: Leadset UK 8290-991-224... -
Page 9: Setting And Storing Radio Stations
SETTINGS ______________________________________________ Setting and storing radio stations Automatic station search Press »ON/OFF« to switch on the device. Select RADIO as the input source with »CD•RADIO•TAPE«. Select the frequency band (FM or MW) by pressing the »BAND« but- TUNER ton. 92.3 –... -
Page 10: General Functions
GENERAL FUNCTIONS ________________________ Switching on and off Press »ON/OFF« to switch on the device. TUNER – The red operating display lights up. MEMORY – The last input source used is automatically selected. 100.6 Press »ON/OFF« to switch off the device. –... -
Page 11: Radio Mode
RADIO MODE _______________________________________ Antennas Pull out the telescopic »ANTENNA« for FM (VHF) reception. Note: If the FM signal is too strong, it is advisable to push in the telescopic antenna. The Radio Recorder has a built-in rod antenna for MW reception. Turn the radio recorder about its own axis to point the antenna. -
Page 12: Selecting The Cd Input Source
CD MODE _________________________________________ The device is suitable for CD-DAs and CD-Rs. Only use CD-DA bearing the logo shown here. Always keep the CD compartment closed to prevent dust from collecting on the laser optics. Do not attach adhesive labels to CDs. Keep the surfaces of CDs clean. -
Page 13: Playing Back Tracks In Random Order
CD MODE _____________________________________________ Searching for a passage within a track During playback press and hold down »F-SKIP « or »R-SKIP « until you have found the required passage. – If »F-SKIP « or »R-SKIP « are let go, playback begins again. Note: During the search the volume is reduced. - Page 14 _____________________________________________ CD MODE Creating a track memory This function enables you to store up to 20 tracks on the current CD in a cer- tain order and then play them back in that sequence. The same track may be stored more than once. Selecting, storing and playing back tracks Place a CD in the CD compartment.
- Page 15 _____________________________________________ CD MODE Changing the track selection To replace a stored track press »PROG« several times until the desired memory position appears in the display. MEMORY P-08 »R-SKIP « or »F-SKIP « to select the new track number. Press »PROG« to save the new track. Deleting the track memory Press »PROG«.
-
Page 16: Tape Mode
TAPE MODE __________________________________________ Selecting Tape as the input source Select TAPE as the input source with » CD•RADIO•TAPE«. TAPE – Display: » TAPE«. Open the tape compartment with » « on the device. Place the tape into the compartment with the open side facing upwards with the full reel to the right (see »TAPE DIRECTION«). -
Page 17: Recording From The Radio
___________________________________________ TAPE MODE Recording from the radio Place a cassette with the protection tabs intact in the tape compartment and use » « or » « to find the correct position on the tape. Select RADIO as the input source with »CD•RADIO•TAPE« and select the desired radio station. -
Page 18: Cleaning The Tape Drive
INFORMATION _____________________________________ Cleaning the tape drive To guarantee good recording and playback quality, clean the parts shown (1, 2, 3) after every 50 hours of use, or once a month. Open the tape compartment, moisten a cotton swab with alcohol or a spe- cial head-cleaning fluid and clean the idler (3), the capstan (2) and the mag- netic heads (1). -
Page 19: Rectifying Minor Problems
_______________________________________ INFORMATION Rectifying minor problems If a fault occurs, first refer to this information before you take the device for repair. If you are unable to rectify the fault using the information given here, contact your local dealer or service specialist. Under no circumstances should you attempt to repair the radio recorder yourself, as this would invalidate the guarantee. -
Page 20: Grundig Service
Unser Kundenberatungszentrum steht Ihnen werktags Montags bis Freitags stets von 8.00 – 19.00 Uhr zur Verfügung. Haben Sie Fragen zur Umweltverträglichkeit unserer von 8.00 bis 19.00 Uhr Geräte, wenden Sie sich an die GRUNDIG Öko- Deutschland: 0180 / 530 21 22* Technologie, Österreich: 0800 / 700 600* Fax: 0911/703-9213. - Page 21 Grundig AG Beuthener Str. 41 • D-90471 Nürnberg • http://www.grundig.com 72011 402 2500 •...
