Summary of Contents for Monitor Audio airstream WS100
- Page 1 U S E R M A N U A L...
-
Page 2: Table Of Contents
There are no losses and no phase errors in the signal path, ensuring that the full 60 watts of power from the system is used to maximum effect. A further crucial element in the WS100 chemistry is Monitor Audio’s use of SKAA™ wireless transmission. SKAA uses proprietary HPX compression that delivers CD-quality sound comparable to uncompressed audio systems. Operating in the 2.4GHz band, it protects the audio signal from other networks with a patented Walking Frequency Diversity™... -
Page 3: SetUp
SetUp The set up of the WS100’s is very straight forward and easy to do thanks to the SKAA wireless technology. Follow the simple steps below to start enjoying outstanding quality music: 1. Place the speakers in the desired location. 2. -
Page 4: UsingTheWs100
UsingtheWS100 After 30 minutes of continuous music playback the dongle will be automatically added to the receiver’s (speaker’s) Green List (see below). The SKAA LED on the back will turn bright green to indicate this. The WS100 can store up to 4. Alternatively, press the SKAA Button on the rear of the right hand speaker for 3 seconds, release it and the transmitter that is currently being used will be added to the Green List. -
Page 5: AuxiliaryInput
Standby The WS100’s can be put into stand-by mode by pressing the p button on the remote or by pressing the volume + button and the volume - button simultaneously and hold for 3 seconds on the right hand speaker. They will also enter stand-by mode when the PC is turned off or no music is played for 15 minutes. -
Page 6: Specifications
Specifications WS100 (pair) Frequency Response 80Hz - 25kHz Maximum SPL 99.5dB Power Output (RMS) Bass: 2 x 20 watts; Tweeter: 2 x 10 watts 2 x 3” (75mm) C-CAM® Cone Bass Driver Drive Unit Complement 2 x 3/4” (19mm) C-CAM® Gold Dome Tweeter System Configuration Sealed box Auxiliary Input Impedance/ Sensitivity... -
Page 7: TroubleShooting
TroubleShooting ISSUE SYMPTOM POSSIBLE SOLUTION If it is red, the speakers need turning on by pressing one of the volume buttons or pressing the p on the remote. If it was previously white and is now red, then the speakers may have gone into stand by mode because no audio has been played for 30 minutes. - Page 8 Monitor Audio Ltd. 24 Brook Road Rayleigh Essex, SS6 7XJ England Tel: +44 (0)1268 740580 Fax: +44 (0)1268 740589 Email: info@monitoraudio.co.uk Web: www.monitoraudio.com/airstream Designed in the United Kingdom Version1.2012...
