Repair Kit
RotoFlex™ Pump
Part No. 234156
60 psi (4.1 bar) Maximum Working Pressure
Pressure Relief Procedure
o reduce the risk of serious bodily injury, includ-
T
ing electric shock and splashing fluid in eyes, fol-
low this procedure whenever you stop spraying:
1. Shut OFF air source.
2. Disconnect power source.
3. Turn gun air valve ON.
Pressurized Equipment Hazard
Fluid from gun, leaks or ruptured components can splash in the eyes or on skin and cause serious
injury.
•
Follow Pressure Relief Procedure when you stop spraying and before cleaning, checking or
servicing.
•
Wear protective clothing, gloves, and eyewear.
Electric Shock Hazard
To reduce the risk of electric shock:
•
Be sure sprayer is adequately grounded through electrical outlet.
•
Use only 3-wire, extension cords.
•
Make sure ground prongs are intact on sprayer and extension cords. Improper installation of
grounding plug will result in a risk of electrical shock, fire or explosion that could cause seri-
ous injury or death.
•
Turn off sprayer. Follow Pressure Relief Procedure and unplug unit, before removing any
parts.
Pinch Hazard
•
Do not operate with cover removed.
•
Keep clear of moving parts.
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
www.graco.com
Copyright 2003
Graco Inc. is registered to I.S. EN ISO 9001
ti3126a
WARNINGS
309793 A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Graco ROTOFLEX 309793 A
Summary of Contents for Graco ROTOFLEX 309793 A
-
Page 1: Pressure Relief Procedure
Pinch Hazard • Do not operate with cover removed. • Keep clear of moving parts. Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441 www.graco.com Copyright 2003 Graco Inc. is registered to I.S. EN ISO 9001 ti3126a WARNINGS 309793 A... - Page 2 RotoFlex Pump Repair Kit 1. Relieve Pressure, page 1. 2. Unplug sprayer from outlet. 3. Remove shroud (6 bolts). ti3025a 4. Remove hopper by loosening bottom fitting and then lift- ing hopper straight up, off unit. ti3118a 5. Remove material hose.
- Page 3 Reinstall RotoFlex Pump hose on plate. 1. Kink hose as shown, making sure dots located on hose fitting face each other. 2. Slide hose onto plate as shown below, mak- ing sure plate slides into slot between hex fitting on end of hose. 309793 A Reassembly 3.
- Page 4 RotoFlex Pump Repair Kit All written and visual data contained in this document reflects the latest product information available at the time of publication. Graco reserves the right to make changes at any time without notice. Sales Offices: Minneapolis, Detroit...
