- Page 1 AR400 SERIES ROUTER QUICK INSTALL GUIDE...
- Page 2 AR400 Series Router Quick Install Guide Document Number C613-04032-01 REV E. Copyright © 2003 Allied Telesyn International, Corp. 19800 North Creek Parkway, Suite 200, Bothell, WA 98011, USA. All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesyn.
-
Page 3: Models Covered By This Guide
Quick Install Guide updates can be found at www.alliedtelesyn.co.nz/support/ar400/ Package Contents The following items are included with each AR400 Series router. Contact your sales representative if any items are damaged or missing. One AR400 Series router. One AC power cord. -
Page 4: Selecting A Site
AR400 Series Router Selecting a Site The router can be installed in a standard 19-inch rack, or on a level surface such as a desktop or bench. When installing the router, choose a site that: Allows adequate airflow around the router and its vents. - Page 5 Check the supply voltage and the router’s rated voltage. AR400 Series routers are fitted with a universal mains power supply that will function over the range 100-240 VAC and 50–60Hz. The specific power supply requirements for a particular model are clearly displayed on the rear or underside of the router.
- Page 6 AR400 Series Router • The power cable is securely plugged in • The power supply is operational If the LEDs light incorrectly, refer to the AR Router Hardware Reference for troubleshooting information. Figure 2: Front and rear panels of an AR450S, showing the AC power inlet, power switch, console ports and Ethernet ports, and their associated LEDs.
-
Page 7: Configuring The Router
Quick Install Guide Configuring the Router AR400 Series routers can be configured via the Command Line Interface (CLI) or Graphical User Interface (GUI). Using the CLI to configure a router: Initiate router start-up. Using the terminal cable supplied, connect a VT100-compatible terminal, or the COM port of a PC running a terminal emulation program such as Windows Terminal, to the Console RS-232 (ASYN0) port on the router’s... - Page 8 AR400 Series Router See the AR400 Series Router Software Reference for more information on router start-up and configuration procedures (including a list of message definitions). Using the GUI to configure a router: This section describes how to access the GUI via VLAN1, when the PC and the router are in the same subnet, in order to configure the router.
-
Page 9: Connecting The Data Cables
Quick Install Guide Enable IP. At the CLI, enter the command: enable ip Assign an IP address to VLAN1. Assign the VLAN1 interface an IP address in the subnet that the PC uses, using the command: add ip interface=vlan1 ip=ipaddress mask=mask Browse to the GUI. -
Page 10: Leds And What They Mean
WAN device (such as a modem). With AR410 and AR410S routers, you can instead use a PIC for your WAN connection. LEDs and What They Mean LEDs indicate the router’s operational status and port activity. AR400 Series System LEDs State Function Power... -
Page 11: Documentation And Tools Cd-Rom
The AR400 Series Router Safety and Statutory Information booklet, which provides safety and statutory information. This Quick Install Guide. The AR400 Series User Guide, which provides an introduction to the router and its operational features and characteristics. The AR Router Hardware Reference, which provides detailed information on the hardware features of AR routers.
