Copyright
This publication, including all photographs, illustrations and software, is protected un-
der international copyright laws, with all rights reserved. Neither this manual, nor any
of the material contained herein, may be reproduced without written consent of the au-
thor.
Version
1.0a
Disclaimer
The information in this document is subject to change without notice. The manufac-
turer makes no representations or warranties with respect to the contents hereof and
specifically disclaims any implied warranties of merchantability or fitness for any par-
ticular purpose. The manufacturer reserves the right to revise this publication and to
make changes from time to time in the content hereof without obligation of the manu-
facturer to notify any person of such revision or changes.
Trademark Recognition
Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corp.
MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered trademarks of Intel
Corporation.
Other product names used in this manual are the properties of their respective owners
and are acknowledged.
Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digi-
tal device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not in-
stalled and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not oc-
cur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
−
Reorient or relocate the receiving antenna.
−
Increase the separation between the equipment and the receiver.
−
Connect the equipment onto an outlet on a circuit different from that to which
the receiver is connected.
−
Consult the dealer or an experienced radio/TV technician for help.
Shielded interconnect cables and a shielded AC power cable must be employed with
this equipment to ensure compliance with the pertinent RF emission limits governing
this device. Changes or modifications not expressly approved by the system's manu-
facturer could void the user's authority to operate the equipment.
Preface

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L7VTA2 and is the answer not in the manual?

Questions and answers

Related Manuals for ECS L7VTA2

Summary of Contents for ECS L7VTA2

  • Page 1 Preface Copyright This publication, including all photographs, illustrations and software, is protected un- der international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the au- thor.
  • Page 2 Declaration of Conformity This device complies with part 15 of the FCC rules. Operation is subject to the follow- ing conditions: − This device may not cause harmful interference, and − This device must accept any interference received, including interference that may cause undesired operation.

  • Page 3: Table Of Contents

    Preface CHAPTER 1 Introducing the Mainboard Introduction ....................1 Checklist .....................1 Standard Items ....................1 Features .....................2 Choosing a Computer Case ...............4 Mainboard Components ................5 CHAPTER 2 Installing the Mainboard Safety Precautions..................7 Quick Guide ....................7 Installing the Mainboard in a Case..............8 Checking Jumper Settings ................8 Setting Jumpers ....................
  • Page 4 Standard CMOS Features ................28 Advanced BIOS Setup................... 30 Advanced Chipset Setup................32 Integrated Peripherals ..................37 Power Management Setup ................42 PNP/PCI Configurations................46 PC Health Status.................... 47 Frequency/Voltage Control................48 Load Fail-Safe Defaults................. 49 Load Optimized Defaults................49 Set Supervisor/User Password...............

  • Page 5: Introducing The Mainboard

    AC97 link compatible sound system and full System Management Bus (SMBus) interface. The L7VTA2 is equipped with advanced full set of I/O ports, such as dual channel IDE interfaces, a floppy controller, two high-speed serial port, an EPP/ECP capable bi-directional parallel port connector, four USB (Universal...

  • Page 6: Features

    Each slot supports up to 1 GB with a total maximum ca- pacity of 3 GB Graphics The L7VTA2 includes an AGP slot that provides eight times the bandwidth of the original AGP specification. The AGP 3.0 (8xAGP) offers a significant increase in performance along with feature enhancements to AGP2.0.
  • Page 7 (share), the line-in jack (share), center/bass (share), and MIC jack to output 6 channels audio. Expansion L7VTA2 has five 32-bit PCI slots, an AGP slot (supports 1.5V Options AGP card only) and CNR (Communications and Networking Riser; optional) slot.

  • Page 8: Choosing A Computer Case

    There are many types of computer cases on the market. The mainboard com- plies with the specifications for the ATX system case. Some features on the mainboard are implemented by cabling connectors on the mainboard to indi- cators and switches on the system case. Ensure that your case supports all the features required.
  • Page 10 Table of Mainboard Components Label Component 1394A_J2 IEEE 1394A header AGP1 Accelerated Graphics Port (supports 1.5V AGP card only) ATX1 Standard 20-pin ATX power connector AUDIO1 Front audio connector AUXIN1 Extra line-in connector BAT1 Three volt realtime clock battery CASFAN1 Case fan connector CDIN1 CD-in connector...

  • Page 11: Installing The Mainboard

    Installing the Mainboard Follow these safety precautions when installing the mainboard: • Wear a grounding strap attached to a grounded device to avoid damage from static electricity. • Discharge static electricity by touching the metal case of a safely grounded object before working on the mainboard. •...

  • Page 12: Installing The Mainboard In A Case

    Refer to the following illustration and instructions for installing the mainboard in a case: This illustration shows an ex- 2. Secure the mainboard with ample of a mainboard being screws where appropriate. installed in a tower-type case: Note: Do not overtighten the screws as this can stress the main- board.

  • Page 13: Checking Jumper Settings

    Checking Jumper Settings The following illustration shows the location of the mainboard jumpers. Pin 1 is labeled. Jumper Settings Jumper Type Description Setting (default) 3-pin Clear CMOS 1-2: Normal 2-3: Clear CMOS JP8 & JP9 3-pin CPU Frequency See table on following select jumper page for settings.

  • Page 14: Connecting Case Components

    JP9 & JP8 – CPU Frequency Select Jumper This jumper enables you to set the CPU frequency. CPU Frequency Short 1-2 Short 1-2 100MHz Short 2-3 Short 1-2 133MHz Short 1-2 Short 2-3 Not Applicable Short 2-3 Short 2-3 166MHz Connecting Case Components After you have installed the mainboard into a case, you can begin connecting the mainboard components.
  • Page 15 CPUFAN1/CASFAN1: FAN Power Connectors Signal Name Function System Ground +12V Power +12V Sense Sensor SPEAKER1: Internal speaker Signal Name Signal Ground CHS1: Chassis Intrusion Detect (optional) This connector allows the user to detect unauthorized intrusion to the case. It will alert the user with a warning message when the case is turned on. Signal Name Function Intruder...

  • Page 16: Front Panel Connector

    Front Panel Connector The front panel connector (PANEL1) provides a standard set of switch and LED connectors commonly found on ATX or micro-ATX cases. Refer to the table below for information: PANEL1 Signal Function Signal Function Hard disk LED MSG LED [dual color HD_LED_P FP PWR/SLP (positive)

  • Page 17: Installing Hardware

    Installing the Processor Caution: When installing a CPU heatsink and cooling fan make sure that you DO NOT scratch the mainboard or any of the surface-mount resistors with the clip of the cooling fan. If the clip of the cooling fan scrapes across the mainboard, you may cause serious damage to the mainboard or its components.

  • Page 18: Cpu Installation Procedure

    CPU Installation Procedure The following illustration shows CPU installation components: Note: The pin-1 corner is marked with an arrow Follow these instructions to install the CPU: Pull the CPU socket locking lever away from the socket to unhook it and raise the locking lever to the upright position.

  • Page 19: Installing Memory Modules

    Connect the CPU Cooling Fan power cable connector to the CPUFAN connector. • To achieve better airflow rates and heat dissipation, we suggest that Notes: you use a high quality fan with 4800 rpm at least. • CPU fan and heatsink installation procedures may vary with the type of CPU fan/heatsink supplied.

  • Page 20: Installing A Hard Disk Drive/Cd-Rom

    Align the memory module with the slot. The DIMM slots are keyed with notches and the DIMMs are keyed with cutouts so that they can only be in- stalled correctly. Check that the cutouts on the DIMM module edge connector match the notches in the DIMM slot.

  • Page 21: Installing A Hard Disk Drive

    other device is set to SLAVE. The documentation of your IDE device explains how to do this. About UltraDMA This mainboard supports UltraDMA 66/100/133. UDMA is a technology that accelerates the performance of devices in the IDE channel. To maximize per- formance, install IDE devices that support UDMA and use 80-pin IDE cables that support UDMA 66/100/133.

  • Page 22: Installing A Floppy Diskette Drive

    Plug an IDE cable connector into the CD-ROM/DVD drive IDE connector (B). It doesn't matter which connector on the cable you use. Plug a power cable from the case power supply into the power connector on the CD-ROM/DVD drive (C). Use the audio cable provided with the CD-ROM/DVD drive to connect to the mainboard CD-in connector CDIN1 (D).

  • Page 23: Installing Add-On Cards

    When you first start up your system, go immediately to the Setup Utility to configure the floppy diskette drives that you have installed. Installing Add-on Cards The slots in this mainboard are designed to hold expansion cards and connect them to the system bus. Expansion slots are a means of adding or enhancing the mainboard’s features and capabilities.
  • Page 24 Follow these instructions to install an add-on card: Remove a blanking plate from the system case corresponding to the slot you are going to use. Install the edge connector of the add-on card into the expansion slot. Ensure that the edge con- nector is correctly seated in the slot.

  • Page 25: Connecting Optional Devices

    Connecting Optional Devices Refer to the following for information on connecting the mainboard’s optional devices: AUDIO1: Front Panel Audio header This header allows the user to install auxiliary front-oriented microphone and line-out ports for easier access. Signal Name Function AUD_MIC Front Panel Microphone input signal AUD_GND Ground used by Analog Audio Circuits...
  • Page 26 AUXIN1: Extra line-in connector This connector is an additional line-in audio connector. It allows you to attach a line-in cable when your rear line-in jack is set as line out port for 4-channel function. Signal Name Function AUX_L AUX In left channel Ground Ground AUX_R...

  • Page 27: Connecting I/O Devices

    1394A_J2: IEEE 1394A header (optional) Use this header to connect to any IEEE 1394A interface. Signal Name Signal Name Cable-power TPA- TPA+ TPB- Chassis GND TPB+ The backplane of the mainboard has the following I/O ports: PS/2 Mouse Use the upper PS/2 port to connect a PS/2 point- ing device.

  • Page 28: External Connector Color Coding

    External Connector Color Coding Many connectors now use standard colors as shown in the table below. Connector Color Audio line-in Light blue Audio line-out Lime Digital monitor/flat panel White IEEE 1394 Grey Microphone Pink MIDI/game Gold Parallel Burgundy PS/2-compatible keyboard Purple PS/2-compatible mouse Green...

  • Page 29: Using Bios

    Using BIOS The computer uses the latest Award BIOS with support for Windows Plug and Play. The CMOS chip on the mainboard contains the ROM setup instructions for configuring the mainboard BIOS. The BIOS (Basic Input and Output System) Setup Utility displays the system's configuration status and provides you with options to set system parameters.

  • Page 30: Starting Setup

    Starting Setup The BIOS is immediately activated when you first turn on the computer. The BIOS reads system configuration in CMOS RAM and begins the process of checking out the system and configuring it through the power-on self test (POST). When these preliminaries are finished, the BIOS seeks an operating system on one of the data storage devices (hard drive, floppy drive, etc.).

  • Page 31: Updating The Bios

    BIOS Navigation Keys The BIOS navigation keys are listed below: Function Exits the current menu ←↑↓→ Scrolls through the items on a menu +/–/PU/PD Modifies the selected field's values Saves the current configuration and exits setup Displays a screen that describes all key functions Loads previously saved values to CMOS Loads a minimum configuration for troubleshooting.

  • Page 32: Using Bios

    When the installation is complete, remove the floppy diskette from the diskette drive and restart your computer. If your mainboard has a Flash BIOS jumper, reset the jumper to protect the newly installed BIOS from being overwritten. When you start the Setup Utility, the main menu appears. The main menu of the Setup Utility displays a list of the options that are available.
  • Page 33 ever you make changes to the Windows Date and Time Properties utility. IDE Devices (None) Your computer has two IDE channels (Primary and Secondary) and each channel can be installed with one or two devices (Master and Slave). Use these items to configure each device on the IDE channel. Press <Enter>...

  • Page 34: Advanced Bios Setup

    Drive A/Drive B (1.44M, 3.5 in./None) These items define the characteristics of any diskette drive attached to the system. You can connect one or two diskette drives. Floppy 3 Mode Support (Disabled) Floppy 3 mode refers to a 3.5-inch diskette with a capacity of 1.2 MB. Floppy 3 mode is sometimes used in Japan.
  • Page 35 External Cache (Enabled) Most processors that can be installed in this system use external level 2 (L2) cache memory to improve performance. Leave this item at the default value for better performance. CPU L2 Cache ECC Checking (Enabled) This item enables or disables ECC (Error Correction Code) error checking on the CPU cache memory.

  • Page 36: Advanced Chipset Setup

    Typematic Rate Setting (Disabled) If this item is enabled, you can use the following two items to set the typematic rate and the typematic delay settings for your keyboard. • Typematic Rate (Chars/Sec): Use this item to define how many characters per second are generated by a held-down key.
  • Page 37 Phoenix – AwardBIOS CMOS Setup Utility Advanced Chipset Setup Item Help DRAM Clock/Drive Control [Press Enter] AGP & P2P Bridge Control [Press Enter] Menu Level CPU & PCI Bus Control [Press Enter] Memory Hole [Disabled] System BIOS Cacheable [Disabled] Video RAM Cacheable [Disabled] BIOS Write Protect [Disabled]...
  • Page 38 DRAM Timing (Auto by SPD) Set this By SPD to enable the system to automatically set the SDRAM timing by SPD (Serial Presence Detect). SPD is an EEPROM chip on the DIMM module that stores information about the memory chips it contains, including size, speed, voltage, row and column addresses, and manufacturer.
  • Page 39 Press <Esc> to return to the Advanced Chipset Features screen. AGP & P2P Bridge Control Scroll to this item and press <Enter> to view the following screen: Phoenix – AwardBIOS CMOS Setup Utility AGP & P2P Bridge Control Item Help AGP Aperture Size [125 MB] AGP Mode...
  • Page 40 AGP Master 1 WS Read (Disabled) This implements a single delay when reading to the AGP Bus. By default, two- wait states are used by the system, allowing for greater stability. Press <Esc> to return to the Advanced Chipset Features screen. CPU &...

  • Page 41: Integrated Peripherals

    Integrated Peripherals These options display items that define the operation of peripheral compo- nents on the system's input/output ports. Phoenix – AwardBIOS CMOS Setup Utility Integrated Peripherals Item Help VIA OnChip IDE Device [Press Enter] VIA OnChip PCI Device [Press Enter] Menu Level VIA Super I/O Device [Press Enter]...
  • Page 42 field to Disabled if the interface does not support prefetching. IDE Primary/Secondary Master/Slave PIO (Auto) Each IDE channel supports a master device and a slave device. These four items let you assign which kind of PIO (Programmed Input/Output) is used by IDE devices.
  • Page 43 network add-in card with a remote boot ROM installed. Press <Esc> to return to the Integrated Peripherals screen. SuperIO Device Scroll to this item and press <Enter> to view the following screen: Phoenix – AwardBIOS CMOS Setup Utility SuperIO Device Item Help Onboard FDC Controller [Enabled]...
  • Page 44 Onboard Parallel Port (378/IRQ7) This option is used to assign the I/O address and interrupt request (IRQ) for the onboard parallel port. Parallel Port Mode (ECP) Enables you to set the data transfer protocol for your parallel port. There are four options: SPP (Standard Parallel Port), EPP (Enhanced Parallel Port), ECP (Extended Capabilities Port) and ECP+EPP.
  • Page 45 ables BIOS to automatically detect the optimal number of block read and writes per sector that the drive can support and improves the speed of access to IDE devices. PWRON After PWR-Fail (Off) This item enables your computer to automatically restart or return to its last operating status after power returns from a power failure.

  • Page 46: Power Management Setup

    Power Management Setup The Power Management Setup Menu option is used to change the values of the chipset registers for system power management. Power Management Timeouts The power-saving modes can be controlled by timeouts. If the system is inac- tive for a time, the timeouts begin counting. If the inactivity continues so that the timeout period elapses, the system enters a power-saving mode.
  • Page 47 the exception of a refresh current to the system memory. Power Management Option (User Define) This item acts like a master switch for the power-saving modes and hard disk timeouts. If this item is set to Max Saving, power-saving modes occur after a short timeout.
  • Page 48 IRQ/Event Activity Detect Scroll to this item and press <Enter> to view the following screen: Phoenix – AwardBIOS CMOS Setup Utility IRQ/Event Activity Detect Item Help PS2KB WakeUp from S3/S4/S5 [Disabled] PS2KB Wakeup Select [Hot key] Menu Level PS2MS Wakeup from S3/S4/S5 [Disabled] USB Resume from S3 [Disabled]...
  • Page 49 PCI Master (OFF) When set to Off, any PCI device set as the Master will not power on the sys- tem. PowerOn by PCI Card (Enabled) Use this item to enable PCI activity to wakeup the system from a power sav- ing mode.

  • Page 50: Pnp/Pci Configurations

    PNP/PCI Configurations This section describes configuring the PCI bus system. PCI (Peripheral Com- ponent Interconnect) is a system, which allows I/O devices to operate at speeds nearing CPU’s when they communicate with own special components. All the options describes in this section are important and technical and it is strongly recommended that only experienced users should make any changes to the default settings.

  • Page 51: Pc Health Status

    Base to set the start address of the memory you want to reserve for the ISA expansion card. Use the second item Reserved Memory Length to set the amount of reserved memory. Press <Esc> to close the Memory Resources sub-menu. PCI/VGA Palette Snoop (Disabled) This item is designed to overcome some problems that can be caused by some non-standard VGA cards.

  • Page 52: Frequency/Voltage Control

    Frequency/Voltage Control This item enables you to set the clock speed and system bus for your system. The clock speed and system bus are determined by the kind of processor you have installed in your system. Phoenix – AwardBIOS CMOS Setup Utility Frequency/Voltage Control Item Help Auto Detect DIMM/PCI Clk...

  • Page 53: Load Fail-Safe Defaults

    Load Fail-Safe Defaults This option opens a dialog box that lets you install fail-safe defaults for all ap- propriate items in the Setup Utility: Press <Y> and then <Enter> to install the defaults. Press <N> and then <En- ter> to not install the defaults. The fail-safe defaults place no great demands on the system and are generally stable.

  • Page 54: Save & Exit Setup

    Save & Exit Setup Highlight this item and press <Enter> to save the changes that you have made in the Setup Utility and exit the Setup Utility. When the Save and Exit dialog box appears, press <Y> to save and exit, or press <N> to return to the main menu: Exit Without Saving Highlight this item and press <Enter>...

  • Page 55: Using The Mainboard Software

    Using the Mainboard Software The support software CD-ROM that is included in the mainboard package contains all the drivers and utility programs needed to properly run the bun- dled products. Below you can find a brief description of each software program, and the location for your mainboard version.

  • Page 56: Running Setup

    Setup Tab Setup Click the Setup button to run the software installation program. Select from the menu which software you want to install. Browse The Browse CD button is the standard Windows command that allows you to open Windows Explorer and show the contents of the support CD.

  • Page 57: Manual Installation

    Note: The following screens are examples only. The screens and driver lists will be different according to the mainboard you are installing. The mainboard identification is located in the upper left-hand corner. Click Next. The following screen appears: Check the box next to the items you want to install. The default options are recommended.

  • Page 58: Utility Software Reference

    Insert the CD in the CD-ROM drive and locate the PATH.DOC file in the root directory. This file contains the information needed to locate the drivers for your mainboard. Look for the chipset and mainboard model; then browse to the directory and path to begin installing the drivers.
  • Page 59 MediaRing Talk – Telephony Software To install the MediaRing Talk voice modem software for the built-in modem, go directory \UTILITY\MEDIARING TALK, then MRTALK- SETUP72.EXE to install the application software. Super Voice – Fax/Modem Software To install the Super Voice voice, fax, data communication application for use with the built-in fax/modem, go the directory \UTILITY\SUPER_VOICE, then run PICSHELL.EXE to install the application software.
