Copyright
This publication, including all photographs, illustrations and software, is protected un-
der international copyright laws, with all rights reserved. Neither this manual, nor any
of the material contained herein, may be reproduced without w ritten consent of the au-
thor.
Version 1.0
Disclaimer
The information in this document is subject to change without notice. The manufac-
turer makes no representations or warranties with respect to the contents hereof and
specifically disclaims any implied warranties of merchantability or fitness for any par-
ticular purpose. The manufacturer reserves the right to revise this publication and to
make changes from time to time in the content hereof without obligation of the manu-
facturer to notify any person of suc h revision or changes.
Trademark Recognition
Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corp.
MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered trademarks of Intel
Corporation.
Other product names used in this manual are the properties of their respective owners
and are acknowledged.
Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digi -
tal device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not in-
stalled and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not oc-
cur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
−
Reorient or relocate the receiving antenna.
−
Increase the separation between the equipment and the receiver.
−
Connect the equipment onto an outlet on a circuit different from that to which
the receiver is connected.
−
Consult the dealer or an experienced radio/TV technician for help.
Shielded interconnect cables and a shielded AC power cable must be employed with
this equipment to ensure compliance with the pertinent RF emission limits governing
this device. Changes or modifications not expressly approved by the system's manu-
facturer could void the user's authority to operate the equipment.
Preface
Advertisement
Table of Contents
Related Manuals for ECS L4S5M2
Summary of Contents for ECS L4S5M2
- Page 1 Preface Copyright This publication, including all photographs, illustrations and software, is protected un- der international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without w ritten consent of the au- thor.
- Page 2 Declaration of Conformity This device complies with part 15 of the FCC rules. Operation is subject to the follow - ing conditions: − This device may not cause harmful interference, and − This device must accept any interference received, including interference that may cause undesired operation.
-
Page 3: Table Of Contents
Preface 錯誤! 尚未定義書籤。 Features and Packing List Translations CHAPTER 1 Introducing the Mainboard Introduction......................1 Checklist.........................1 Standard Items ....................1 Features........................2 Choosing a Computer Case................3 Mainboard Components..................4 CHAPTER 2 Installing the Mainboard Safety Precautions....................6 Quick Guide......................6 Installing the Mainboard in a Case..............7 Checking Jumper Settings...................7 Setting Jumpers .................... - Page 4 Advanced Chipset Features Option..............30 Integrated Peripherals Option................32 Power Management Setup Option..............36 PNP/PCI Configuration Option............... 40 PC Health Status Option.................. 41 Frequency/Voltage Control................41 Load Fail-Safe Defaults Option ..............42 Load Optimized Defaults Option ..............42 Set Password Option ..................42 Save &...
-
Page 5: Introducing The Mainboard
Introducing the Mainboard Congratulations on purchasing the L4S5M2 mainboard. The L4S5M2 main- board is a micro ATX mainboard that uses a 4-layer printed circuit board and measures 244 mm x 220 mm. The mainboard features an mPGA Socket 478 that accommodates Pentium 4 processors supporting system bus (FSB) speeds up to 400 MHz. -
Page 6: Features
Processor The L4S5M2 mainboard uses a micro PGA 478-pin socket that has the following features: • Supports 400 MHz system bus (FSB) • Accommodates Pentium 4 processors Chipset The SiS645 and SiS961 chipsets are based on an innovative and scalable architecture with proven reliability and perform- ance. -
Page 7: Choosing A Computer Case
Integrated I/O The mainboard has a full set of I/O ports and connectors: • Two PS/2 ports for mouse and keyboard • One serial port • One parallel port • One MIDI/game port • Two USB ports • One LAN port •... - Page 9 Table of Mainboard Components Label Component AGP1 Accelerated Graphics Port ATX1 Auxiliary power connector for Pentium 4 CPUs ATX2 Power connector AUDIO1 Front audio connector BAT1 Three volt realtime clock battery CASFAN1 Auxiliary case cooling fan CDIN1 Primary CD-in connector CDIN2 Secondary CD-in connector CNR1...
-
Page 10: Installing The Mainboard
Installing the Mainboard Follow these safety precautions when installing the mainboard: • Wear a grounding strap attached to a grounded device to avoid damage from static electricity. • Discharge static electricity by touching the metal case of a safely grounded object before working on the mainboard. •... -
Page 11: Installing The Mainboard In A Case
Refer to the following illustration and instructions for installing the mainboard in a case: This illustration shows an ex- 2. Secure the mainboard with ample of a mainboard being screws where appropriate. installed in a tower-type case: Note: Do not overtighten the screws as this can stress the main- board. -
Page 12: Checking Jumper Settings
Checking Jumper Settings The following illustration shows the location of the mainboard jumpers. Pin 1 is labeled. Jumper Settings Jumper Type Description Setting (default) 3-pin Clear CMOS 1-2: Normal 2-3: Clear CMOS 3-pin BIOS protect 1-2: Write protect disable 2-3: Write protect enable Jumper 1 –... -
Page 13: Connecting Case Components
to protect the BIOS from being flashed. For instruc- tions on updating the BIOS refer to Chapter 3. After you have installed the mainboard into a case, you can begin connecting the mainboard components. Refer to the following: Connect the Pentium 4 processor auxiliary case power supply connector to ATX1. -
Page 14: The Panel Connector
The Panel Connector The panel connector (PANEL1) provides a standard set of switch and LED connectors commonly found on ATX or micro-ATX cases. Refer to the table below for information: PANEL1 Device Pins Empty Empty (Pin 10) (Pin 9) Power ON/OFF 6, 8 Reset Switch 5, 7... - Page 15 settings in the system Setup Utility. We strongly recommend that you do not overclock processors or other components to run faster than their rated speed. Warning: Overclocking components can adversely affect the reliability of the system and introduce errors into your system. Overclocking can per- manently damage the mainboard by generating excess heat in components that are run beyond the rated limits.
- Page 16 Match the corner on the CPU marked with an arrow with pin-1 on the CPU socket (the corner with the pinhole noticeably missing). Insert the processor into the socket. Do not use force. Lower the heatsink over the CPU. Lower the CPU cooling fan onto the heatsink. Apply thermal grease to the top of the CPU.
-
Page 17: Installing Memory Modules
Installing Memory Modules For this mainboard, you must use 168-pin 3.3V unbuffered Dual In-line Mem- ory Modules (DIMMs). The memory bus can run at 66 MHz, 100 MHz or 133 MHz. If your processor operates over a 133 MHz FSB (frontside bus), you can install PC133 or PC100 memory modules that operate over a 133 or 100 MHz bus. -
Page 18: Installing A Hard Disk Drive/Cd-Rom
Install the DIMM module into the slot and press it firmly down until it seats correctly. The slot latches are levered upwards and latch on to the edges of the DIMM. Install any remaining DIMM modules. Installing a Hard Disk Drive/CD-ROM This section describes how to install IDE devices such as a hard disk drive and a CD-ROM drive. -
Page 19: Installing A Floppy Diskette Drive
When you first start up your system, the BIOS should automatically detect your hard disk drive. If it doesn’t, enter the Setup Utility and use the IDE Hard Disk Auto Detect feature to configure the hard disk drive that you have in- stalled. -
Page 20: Installing Add-On Cards
Plug the FDD cable into FLOPPY1 (A): Note: Ribbon cable connectors are usually keyed so that they can only be installed correctly on the device connector. If the connector is not keyed, make sure that you match the pin-1 side of the cable connector with the pin-1 side of the device connec- tor. - Page 21 Follow these instructions to install an add-on card: Remove a blanking plate from the system case corresponding to the slot you are going to use. Install the edge connector of the add-on card into the expansion slot. Ensure that the edge con- nector is correctly seated in the slot.
-
Page 22: Connecting Optional Devices
Connecting Optional Devices Refer to the following for information on connecting the mainboard’s optional devices: COM2: Onboard serial port connector Connect a serial port extension bracket to this header to add a second serial port to your system. Signal Name GROUND... - Page 23 AUDIO1: Front panel MIC/line-out This header allows the user to install auxiliary front-oriented microphone and line-out ports for easier access. Signal Name Signal Name AUD_MIC AUD_GND MIC_BIAS AUD_VCC AUD_F_R AUD_RET_R RESERVED AUD_F_L AUD_RET_L USB2/USB3: Front panel USB ports The mainboard has two USB ports installed on the rear edge I/O port array. Additionally, some computer cases have USB ports at the front of the case.
- Page 24 SIR1: Serial infrared port The mainboard supports a Serial Infrared (SIR) data port. Infrared ports allow the wireless exchange of information between your computer and similarly equipped devices such as printers, laptops, Personal Digital Assistants (PDAs), and other computers. Signal Name Not assigned (No Pin) Ground...
-
Page 25: Connecting I/O Devices
The backplane of the mainboard has the following I/O ports: Parallel port (LPT1) Game port PS/2 port mouse ports PS/2 Serial port Microphone keyboard COM 1 Line-in Line-out PS/2 Mouse Use the upper PS/2 port to connect a PS/2 pointing device. -
Page 26: External Connector Color Coding
External Connector Color Coding Many connectors now use standard colors as shown in the table below. Connector Color Audio line-in Light blue Audio line-out Lime Digital monitor/flat panel White Microphone Pink MIDI/game Gold Parallel Burgundy PS/2-compatible keyboard Purple PS/2-compatible mouse Green Serial Teal or Turquoise... -
Page 27: Using Bios
Using BIOS The computer uses the latest Award BIOS with support for Windows Plug and Play. The CMOS chip on the mainboard contains the ROM setup instructions for configuring the mainboard BIOS. The BIOS (Basic Input and Output System) Setup Utility displays the system's configuration status and provides you with options to set system parameters. -
Page 28: Entering The Setup Utility
Entering the Setup Utility When you power on the system, BIOS enters the Power-On Self Test (POST) routines. POST is a series of built-in diagnostics performed by the BIOS. After the POST routines are completed, the following message appears: Press DEL to enter SETUP Pressing the delete key accesses the BIOS Setup Utility: CMOS Setup Utility –... -
Page 29: Using Bios
If your mainboard has an item called Firmware Write Protect in Advanced BIOS features, disable it. (Firmware Write Protect prevents BIOS from being overwritten.) Create a bootable system disk. (Refer to Windows online help for info r- mation on creating a bootable system disk.) Download the Flash Utility and new BIOS file from the manufacturer's Web site. -
Page 30: Standard Cmos Features
Standard CMOS Features This option displays basic information about your system. CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software Standard CMOS Features Item Help Date (mm:dd:yy) Tue, July 11 2001 Time (hh:mm:ss) 12 : 8 : 59 Menu Level IDE Primary Master Change the day, month,... - Page 31 IDE HDD Auto-Detection Press <Enter> while this item is highlighted to prompt the Setup Utility to automatically detect and configure an IDE device on the IDE channel. Note: If you are setting up a new hard disk drive that supports LBA mode, more than one line will appear in the parameter box.
-
Page 32: Advanced Bios Setup Option
Advanced BIOS Setup Option This option defines advanced information about your system. CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software Advanced BIOS Features Item Help Anti-Virus Protection [Disab led ] CPU L1 & L2 Cache [Enabled] Menu Level Quick Power On Self Test [Enabled] First Boot Device... - Page 33 Swap Floppy Drive (Disabled) If y ou have two floppy diskette drives in your system, this item allows you to swap the assigned drive letters so that drive A becomes drive B, and drive B becomes drive A. Boot Up Floppy Seek (Disabled) If this item is enabled, it checks the size of the floppy disk drives at start-up time.
-
Page 34: Advanced Chipset Features Option
Report No FDD For WIN95 (Yes) If you are running a system with no floppy drive and using Windows 95, select Yes for this item to ensure compatibility with the Windows 95 logo certification. Otherwise, select No. Small Logo (EPA) Show (Disabled) Enables or disables the display of the EPA logo during boot. - Page 35 System Performance (Normal Mode) This is the DRAM auto configuration option, which can be set to Safe Mode, Normal Mode, Fast Mode or Ultra Mode. CAS Latency Setting (3T) Enables you to select the CAS latency time in HCLKs of 2, 2.5, or 3. The value is set at the factory depending on the DRAM installed.
-
Page 36: Integrated Peripherals Option
Integrated Peripherals Option These options display items that define the operation of peripheral compo- nents on the system's input/output ports. CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software Integrated Peripherals Item Help SIS OnChip IDE Device [Press Enter] SIS OnChip PCI Device [Press Enter] Menu Level... - Page 37 IDE devices. Choose Auto to let the system auto detect which PIO mode is best, or select a PIO mode from 0-4. IDE Primary/Secondary Master/Slave UltraDMA (Auto) Each IDE channel supports a master device and a slave device. This main- board supports UltraDMA technology, which provides faster access to IDE devices.
- Page 38 Onboard SuperIO Device Scroll to this item and press <Enter> to view the following screen: CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software Onboard SuperIO Device Item Help Onboard FDC Controller [Enabled ] Onboard Serial Port 1 [3F8/IRQ4] Menu Level Onboard Serial Port 2...
- Page 39 UR2 Duplex Mode (Half) This field is available when UART 2 Mode is set to either ASKIR or IrDA. This item enables you to determine the infrared function of the onboard infrared chip. The options are Full and Half (default). Full-duplex means that you can transmit and send information simultaneously.
-
Page 40: Power Management Setup Option
IDE HDD Block Mode (Enabled) Enable this field if your IDE hard drive supports block mode. Block mode en- ables BIOS to automatically detect the optimal number of block read and writes per sector that the drive can support. It also improves the speed of ac- cess to IDE devices. - Page 41 CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software Power Management Setup Item Help ACPI function [Enabled ] ACPI Suspend Type [S1(POS)] Menu Level Video Off Option [Suspend --> Off] Video Off Method [DPMS Supported] MODEM Use IRQ [Auto] Hot Key Function as [Power Off]...
- Page 42 Hot Key Function As (Power Off) This option allows you to set the Hot Key functionality to one of the following states: Disable (turn off Hot Key functionality), Power Off, Suspend. Hot Key Power On Function (Disabled) When enabled, allows you to power on the system using hot keys. USB S3 Wakeup Function (Disabled) If you are using a USB keyboard, and the ACPI suspend type is set to S3, you can enable this item to allow a keystroke to wake up the system from power...
- Page 43 PM Wake Up Events Scroll to this item and press <Enter> to view the following screen: CMOS Setup Utility – Copyright (C) 1984 – 2000 Award Software PM Wake Up Events Item Help IRQ [3-7, 9-15], NMI [Enabled ] IRQ 8 Break suspend [Disabled] Menu Level Ring/WOL/WOM PowerUp Contl...
-
Page 44: Pnp/Pci Configuration Option
PNP/PCI Configuration Option These options configure how PnP (Plug and Play) and PCI expansion cards oper- ate in your system. Both the ISA and PCI buses on the Mainboard use system IRQs (Interrupt ReQuests) and DMAs (Direct Memory Access). You must set up the IRQ and DMA assignments correctly through the PnP/PCI Configurations Setup utility for the mainboard to work properly. -
Page 45: Pc Health Status Option
PC Health Status Option On mainboards that support hardware monitoring, this item lets you monitor the parameters for critical voltages, critical temperatures, and fan speeds. CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software PC Health Status Item Help Shutdown Temperature [Disabled ] CPU Core Voltage... -
Page 46: Load Fail-Safe Defaults Option
CPU Clock Ratio (0 X) Use the CPU Host/SDRAM/PCI Clock to set the frontside bus frequency for the installed processor (usually 133 MH z, 100 MHz or 66 MHz). Then use CPU Clock Ratio Jumpless to set a multiple. The multiple times the frontside bus must equal the core speed of the installed processor e.g., 3.5 (multiple) x 100 MHz (frontside bus) = 350 MHz (installed processor clock speed). -
Page 47: Save & Exit Setup Option
If you are installing a new password, type in the password. You cannot use more than eight characters or numbers. The Set Password item dif- ferentiates between upper and lower case characters. Press <Enter> after you have typed in the password. If you are deleting a password that is already installed press <Enter>... -
Page 48: Using The Mainboard Software
Using the Mainboard Software The support software CD-ROM that is included in the mainboard package contains all the drivers and utility programs needed to properly run the bun- dled products. Below you can find a brief description of each software program, and the location for your mainboard version. -
Page 49: Running Setup
Setup Tab Setup Click the Setup button to run the software installation program. Select from the menu which software you want to install. Browse The Browse CD button is the standard Windows command that allows you to open Windows Explorer and show the contents of the support CD. - Page 50 Note: The following screens are examples only. The screens and driver lists will be different according to the mainboard you are installing. The mainboard identification is located in the upper left-hand corner. Click Next. The following screen appears: Check the items you want to install. The default options are recom- mended.
-
Page 51: Manual Installation
Insert the CD in the CD-ROM drive and locate the PATH.DOC file in the root directory. This file contains the information needed to locate the drivers for your mainboard. Look for the chipset and mainboard model; then browse to the directory and path to begin installing the drivers. -
Page 52: Mediaring Talk - Telephony Software
MediaRing Talk – Telephony Software To install the MediaRing Talk voice modem software for the built-in modem, run MRTALK-SETUP72.EXE from the following directory: \UTILITY\MEDIARING TALK Super Voice – Fax/Modem Software To install the Super Voice voice, fax, data communication application for use with the built-in fax/modem, run PICSHELL.EXE from the following directory: \UTILITY\SUPER VOICE WinFlash Utility...
