Copyright
This publication, including all photographs, illustrations and software, is protected un-
der international copyright laws, with all rights reserved. Neither this manual, nor any
of the material contained herein, may be reproduced without w ritten consent of the au-
thor.
Version 3.0
Disclaimer
The information in this document is subject to change without notice. The manufac-
turer makes no representations or warranties with respect to the contents hereof and
specifically disclaims any implied w arranties of merchantability or fitness for any par-
ticular purpose. The manufacturer reserves the right to revise this publication and to
make changes from time to time in the content hereof without obligation of the manu-
facturer to notify any person of such revision or changes.
Trademark Recognition
Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corp.
MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered trademarks of Intel
Corporation.
Other product names used in this manual are the properties of their respective owners
and are acknowledged.
Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digi -
tal device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not in-
stalled and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not oc-
cur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
−
Reorient or relocate the receiving antenna.
−
Increase the separation between the equipment and the receiver.
−
Connect the equipment onto an outlet on a circuit different from that to which
the receiver is connected.
−
Consult the dealer or an experienced radio/TV technician for help.
Shielded interconnect cables and a shielded AC power cable must be employed with
this equipment to ensure compliance with the pertinent RF emission limits governing
this device. Changes or modifications not expressly approved by the system's manu-
facturer could void the user's authority to operate the equipment.
Preface
Advertisement
Table of Contents
Related Manuals for ECS L7SOM
Summary of Contents for ECS L7SOM
- Page 1 Preface Copyright This publication, including all photographs, illustrations and software, is protected un- der international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without w ritten consent of the au- thor.
- Page 2 Declaration of Conformity This device complies with part 15 of the FCC rules. Operation is subject to the follow - ing conditions: − This device may not cause harmful interference, and − This device must accept any interference received, including interference that may cause undesired operation.
-
Page 3: Table Of Contents
Preface 錯誤! 尚未定義書籤。 Features and Packing List Translations CHAPTER 1 Introducing the Mainboard Introduction......................1 Check list.........................1 Standard Items ....................1 Features........................2 Choosing a Computer Case................4 Mainboard Components..................5 CHAPTER 2 Installing the Mainboard Safety Precautions....................7 Quick Guide......................7 Installing the Mainboard in a Case..............8 Checking Jumper Settings...................8 Setting Jumpers .................... - Page 4 Advanced Chipset Features Option..............33 Integrated Peripherals Option................35 Power Management Setup Option..............40 PNP/PCI Configuration Option............... 43 PC Health Status Option.................. 44 Frequency/Voltage Control................45 Load Fail-Safe Defaults Option ..............46 Load Optimized Defaults Option ..............46 Set Supervisor and User Passwords Options........... 46 Save &...
-
Page 5: Introducing The Mainboard
AMD Athlon processors supporting frontside bus (FSB) speeds up to 266 MHz. The L7SOM incorporates the SiS740 Northbridge and SiS961 (or SiS961B /SIS962) Southbridge chipsets which combine support for the new high- bandwidth Double Data Rate (DDR) 266 SDRAM, and the AC 97 audio codec. -
Page 6: Features
Processor The mainboard uses an AMD 462-pin Socket A that has the following features: • Supports 200/266 MHz frontside bus (FSB) • Accommodates AMD Athlon Duron, Athlon, and Athlon XP processors. Chipset The SiS740 Northbridge and SiS961 Southbridge chipsets are based on an innovative and scalable architecture with proven reliability and performance. - Page 7 A Communications Network Riser (CNR) slot • Two IDE connectors which support four IDE channels and a floppy disk drive interface The L7SOM supports Ultra DMA bus mastering with transfer rates of 33/66/100 MB/sec. If the mainboard incorporates the SiS961B or Note:...
-
Page 8: Choosing A Computer Case
capabilities. The mainboard has a built-in high performance, quality 2D/3D graphics accelerator. The graphics system supports the Ultra- AGP II ™ with 2GB/s bandwidth architecture and uses a shared memory scheme that allows up to 64MB of system memory to be used as video memory. BIOS This mainboard uses Award BIOS that enables users to con- Firm ware... - Page 10 Table of Mainboard Components Label Component ATX1 Power connector AUDIO1 Front-oriented microphone/line-out port header Three volt realtime clock battery CASEFAN1 Auxiliary case cooling fan CDIN1 Primary CD-in connector CDIN2 Secondary CD-in connector CNR1 Communications Networking Riser slot CPU1 Socket A for AMD Athlon processor CPUFAN1 Cooling fan for CPU DIMM1 ~ DIMM2...
-
Page 11: Installing The Mainboard
Installing the Mainboard Follow these safety precautions when installing the mainboard: • Wear a grounding strap attached to a grounded device to avoid damage from static electricity. • Discharge static electricity by touching the metal case of a safely grounded object before working on the mainboard. •... -
Page 12: Setting Jumpers
Refer to the following illustration and instructions for ins talling the mainboard in a case: This illustration shows an ex- 2. Secure the mainboard with ample of a mainboard being screws where appropriate. installed in a tower-type case: Note: Do not overtighten the screws as this can stress the main- board. -
Page 13: Checking Jumper Settings
Checking Jumper Settings The following illustration shows the location of the mainboard jumpers. Pin 1 is labeled. Jumper Settings Jumper Type Description Setting (default) 3-pin Clear CMOS 1-2: Normal 2-3: Clear 2-pin BIOS protection Open: Disable Short: Enable FID JP1 5-pin CPU ratio selec- Refer to the table on the next page. - Page 14 – sets the CPU ratio. Refer to the following table. Jumper FIDJP1 9-10 Ratio Short — — — — By CPU Open Open Open Open Open 10.5 Open Open Open Open Short Open Open Open Short Open Open Open Open Short Short 12.5...
-
Page 15: Connecting Case Components
After you have installed the mainboard into a case, you can begin connecting the mainboard components. Refer to the following: Connect the case power supply con- nector to ATX1. Connect the CPU cooling fan cable to CPUFAN1. Connect the case cooling fan connec- tor to CASEFAN1. -
Page 16: The Panel Connectors
The Panel Connectors The panel connectors provide a standard set of switch and LED connectors commonly found on ATX or micro-ATX cases. Refer to the table below for information: PANEL1 Device Pins Empty Empty ( P i n 1 0 ) (Pin 9) Power ON/OFF 6, 8... - Page 17 Warning: Overclocking components can adversely affect the reliability of the system and introduce errors into your system. Overclocking can per- manently damage the mainboard by generating excess heat in components that are run beyond the rated limits. This mainboard has a Socket 462 processor socket. When choosing a proc- essor, consider the performance requirements of the system.
- Page 18 Secure the two retention clips on either side of the fan/heatsink unit onto the Socket 462 base. F a n / h e a t s i n k u n i t s e c u r e d t o s o c k e t Connect the CPU Cooling Fan power cable connector to the CPUFAN connector.
-
Page 19: Installing Memory Modules
Installing Memory Modules This mainboard accommodates 184-pin 2.5V unbuffered Double Data Rate (DDR) SDRAM memory modules. You must install at least one module in any of the two slots. Each module can be installed with 32 MB to 1 GB of memory; total memory capacity is 2 GB. -
Page 20: Installing A Hard Disk Drive/Cd-Rom
Installing a Hard Disk Drive/CD-ROM This section describes how to install IDE devices such as a hard disk drive and a CD-ROM drive. About IDE Devices Your mainboard has a primary and secondary IDE channel interface (IDE1 and IDE2). An IDE ribbon cable supporting two IDE devices is bundled with the main- board. -
Page 21: Installing A Floppy Diskette Drive
When you first start up your system, the BIOS should automatically detect your hard disk drive. If it doesn’t, enter the Setup Utility and use the IDE Hard Disk Auto Detect feature to configure the hard disk drive that you have in- stalled. -
Page 22: Installing Add-On Cards
Install the FDD into the drive cage in your system case. Plug the FDD cable into FDD1 (A): Note: Ribbon cable connectors are usually keyed so that they can only be installed correctly on the device connector. If the connector is not keyed, make sure that you match the pin-1 side of the cable connector with the pin-1 side of the device connec-... - Page 23 Follow these instructions to install an add-on card: Remove a blanking plate from the system case corresponding to the slot you are going to use. Install the edge connector of the add-on card into the expansion slot. Ensure that the edge con- nector is correctly seated in the slot.
-
Page 24: Connecting Optional Devices
Connecting Optional Devices Refer to the following for information on connecting the mainboard’s optional devices: AUDIO 1: Front panel MIC/line-out This header allows the user to install auxiliary front-oriented microphone and line-out ports for easier access. Signal Name Signal Name AUD_MIC AUD_GND MIC_BIAS... - Page 25 USB2/USB3: Front panel USB ports The mainboard has two USB ports installed on the rear edge I/O port array. Additionally, some computer cases have USB ports at the front of the case. If you have this kind of case, use auxiliary USB connectors USB2 and USB3 to connect the front-mounted ports to the mainboard.
- Page 26 SIR1: Serial infrared port The mainboard supports a Serial Infrared (SIR) data port. Infrared ports allow the wireless exchange of information between your computer and similarly equipped devices such as printers, laptops, Personal Digital Assistants (PDAs), and other computers. Signal Name Not assigned (No Pin) Ground...
-
Page 27: Connecting I/O Devices
The backplane of the mainboard has the following I/O ports: Parallel port (LPT1) Game port PS/2 port mouse ports PS/2 Serial port Microphone COM 1 port keyboard Line-in Line-out PS/2 Mouse Use the upper PS/2 port to connect a PS/2 point- ing device. -
Page 28: External Connector Color Coding
External Connector Color Coding Many connectors now use standard colors as shown in the table below. Connector Color Analog VGA Blue Audio line-in Light blue Audio line-out Lime Digital monitor/flat panel White IEEE 1394 Grey Microphone Pink MIDI/game Gold Parallel Burgundy PS/2-compatible keyboard Purple... -
Page 29: Using Bios
Using BIOS The computer uses the latest Award BIOS with support for Windows Plug and Play. The CMOS chip on the mainboard contains the ROM setup instructions for configuring the mainboard BIOS. The BIOS (Basic Input and Output System) Setup Utility displays the system's configuration status and provides you with options to set system parameters. -
Page 30: Entering The Setup Utility
Entering the Setup Utility When you power on the system, BIOS enters the Power-On Self Test (POST) routines. POST is a series of built-in diagnostics performed by the BIOS. After the POST routines are completed, the following message appears: Press DEL to enter SETUP Pressing the delete key accesses the Award BIOS Setup Utility: CMOS Setup Utility –... -
Page 31: Using Bios
If your mainboard has an item called Firmware Write Protect in Advanced BIOS features, disable it. (Firmware Write Protect prevents BIOS from being overwritten.) 10. Create a bootable system disk. (Refer to Windows online help for info r- mation on creating a bootable system disk.) 11. -
Page 32: Standard Cmos Features
Standard CMOS Features This option displays basic information about your system. CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software Standard CMOS Features Date (mm:dd:yy) Tue, July 11 2000 Item Help Time (hh:mm:ss) 12 : 8 : 59 Menu Level IDE Primary Master IDE Primary Slave... - Page 33 IDE HDD Auto-Detection Press <Enter> while this item is highlighted to prompt the Setup Utility to automatically detect and configure an IDE device on the IDE channel. If you are setting up a new hard disk drive that supports LBA mode, more Note: than one line will appear in the parameter box.
-
Page 34: Advanced Bios Setup Option
Advanced BIOS Setup Option This option displays advanced i nformation about your system. CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software Advanced BIOS Features Anti-Virus Protection [Disabled ] Item Help CPU Internal Cache [Enabled] External Cache [Enabled] Menu Level Processor Number Feature [Enabled]... - Page 35 Quick Power On Self Test (Enabled) Enable this item to shorten the power on testing (POST) and have your sys- tem start up faster. You might like to enable this item after you are confident that your system hardware is operating smoothly. First/Second/Third Boot Device (Floppy/HDD-0/CD-ROM) Use these three items to select the priority and order of the devices that your system searches for an operating system at start-up time.
- Page 36 OS Select For DRAM > 64 MB (Non-OS2) This item is only required if you have installed more than 64 MB of memory and you are running the OS/2 operating system. Otherwise, leave this item at the default. HDD S.M.A.R.T Capability (Disabled) The S.M.A.R.T.
-
Page 37: Advanced Chipset Features Option
Advanced Chipset Features Option This option displays a table of items that define critical timing parameters of the mainboard. You should leave the items on this page at their default values unless you are very familiar with the technical specifications of your system hardware. - Page 38 DDR SDRAM CAS Latency (2.5T) These items set the timing and wait states for DDR SDRAM memory. We recommend that you leave these items at the default value. CPU/DRAM CLK Synch CTL (AUTO) This option allows you set the CPU/DRAM synchronization. The valid options are AUTO, Synchronous, and Asynchronous.
-
Page 39: Integrated Peripherals Option
speed. If your graphics display card does not support this feature, you need to disable this item. AGP Data Transfer Rates (Support 4X) Determines the data transfer rate of AGP data at either 4X or 2X depending on your Advanced Graphics Card. AGP Aperture Size (128MB) This item defines the size of the aperture if you use an AGP graphics adapter. - Page 40 SIS OnChip IDE Device Scroll to this item and press <Enter> to view the following screen: CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software SIS OnChip IDE Device Item Help Internal PCI/IDE [Both] Primary Master [Auto] Menu Level Primary Slave [Auto] Secondary Master...
- Page 41 SIS OnChip PCI Device Scroll to this item and press <Enter> to view the following screen: CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software SIS OnChip PCI Device Item Help SIS-7012/7018 AC97Audio [Enabled ] SIS-7013 S/W Modem [Auto] Menu Level System Share Memory Size...
- Page 42 Onboard FDC Controller (Enabled) This option enables the onboard floppy disk drive controller. Onboard Serial Port 1 (3F8/IRQ4) This option is used to assign the I/O address and interrupt request (IRQ) for onboard serial port 1 (COM1). UART Mode Select (Normal) This field is available if the Onboard Serial Port 2 field is set to any option but Disabled.
- Page 43 Midi Port IRQ (10) This item sets the interrupt reques t for the Midi function. Press <Esc> to return to the Integrated Peripherals screen. USB Controller (Enabled) Enable this item if you plan to use the Universal Serial Bus ports on this main- board.
-
Page 44: Power Management Setup Option
USB1 ACCESS INTERFACE (Embedded BUS) This option determines whether the USB1 access interface is the embedded bus or the PCI bus. USB2 ACCESS INTERFACE (Embedded BUS) This option determines whether the USB0 access interface is the embedded bus or a PCI bus. Audio ACCESS INTERFACE (Embedded BUS) This option determines whether the audio access interface is the embedded bus or a PCI bus. - Page 45 ACPI Function (Enabled) This mainboard supports ACPI (Advanced Configuration and Power man- agement Interface). Use this item to enable or disable the ACPI feature. ACPI is a power management specification that makes hardware status in- Note: formation available to the operating system. ACPI enables a PC to turn its peripherals on and off for improved power management.
- Page 46 Power Button Override (Instant-Off) Under ACPI (Advanced Configuration and Power management Interface) you can create a software power down. In a software power down, the system can be resumed by Wake Up Alarms. This item lets you install a software power down that is controlled by the normal power button on your system.
-
Page 47: Pnp/Pci Configuration Option
USB Resume from S3 (Disabled) Use this item to enable USB port activity to wakeup the system from a power saving mode. KB Power ON Password (Enter) Allows you to set the KB Power ON password. Power Up by Alarm (Disabled) When set to Enabled, the following three fields become available: Month Alarm, Day of Month Alarm, and Time Alarm Upon arrival of the alarm time, it will instruct the system to wake up. -
Page 48: Pc Health Status Option
In the IRQ Resources submenu, if you assign an IRQ Legacy ISA, then that Interrupt Request Line is reserved for a legacy ISA expansion card. Press <Esc> to close the IRQ Resources submenu. PCI/VGA Palette Snoop (Disabled) This item is designed to overcome problems that can be caused by some non- standard VGA cards. -
Page 49: Frequency/Voltage Control
Frequency/Voltage Control This item enables you to set the clock speed and system bus for your system. The clock speed and system bus are determined by the kind of processor you have installed in your system. CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software Frequency/Voltage Control Auto Detect DIMM/PCI Clk [Enabled ]... -
Page 50: Load Fail-Safe Defaults Option
Load Fail-Safe Defaults Option This option opens a dialog box that lets you install fail-safe defaults for all ap- propriate items in the Setup Utility: Press <Y> and then <Enter> to install the defaults. Press <N> and then <En- ter> to not install the defaults. The fail-safe defaults place no great demands on the system and are generally stable. -
Page 51: Save & Exit Setup Option
Save & Exit Setup Option Highlight this item and press <Enter> to save the changes that you have made in the Setup Utility and exit the Setup Utility. When the Save and Exit dialog box appears, press <Y> to save and exit, or press <N> to return to the main menu: Exit Without Saving Highlight this item and press <Enter>... -
Page 52: Using The Mainboard Software
Using the Mainboard Software The support software CD-ROM that is included in the mainboard package contains all the drivers and utility programs needed to properly run the bun- dled products. Below you can find a brief description of each software program, and the location for your mainboard version. -
Page 53: Running Setup
Setup Tab Click the button to run the software installation program. Setup Setup Select from the menu which software you want to install. button is the standard Windows command that Browse CD B r o w s e allows you to open Windows Explorer and show the contents of the support CD. - Page 54 The following screens are examples only. The screens and driver lists will Note: be different according to the mainboard you are installing. The mainboard identification is located in the upper left-hand corner. Click . The following screen appears: Next Check the items you want to install. The default options are recom- mended.
-
Page 55: Manual Installation
Insert the CD in the CD-ROM drive and locate the PATH.DOC file in the root directory. This file contains the information needed to locate the drivers for your mainboard. Look for the chipset and mainboard model; then browse to the directory and path to begin installing the drivers. -
Page 56: Mediaring Talk - Telephony Software
MediaRing Talk – Telephony Software To install the MediaRing Talk voice modem software for the built-in modem, run MRTALK-SETUP72.EXE from the following directory: \UTILITY\MEDIARING TALK Super Voice – Fax/Modem Software To install the Super Voice voice, fax, data communication application for use with the built-in fax/modem, run PICSHELL.EXE from the following directory: \UTILITY\SUPER VOICE WinFlash Utility...
