Summary of Contents for Doro AUDIOLINE 20
- Page 1 Cordless telephone User guide...
-
Page 3: Table Of Contents
AUDIOLINE 20 TABLE OF CONTENTS AUDIOLINE 20 User guide TABLE OF CONTENTS Outlook ..... . 2 Settings ....14 Handset . -
Page 4: Outlook
OUTLOOK AUDIOLINE 20 HANDSET PQRS WXYZ 1 In use indicator 7 Speed memory M1 2 Earpice 8 Charge contacts 3 Display 9 Flash 4 Programming button/Volume control 10 Last number redial 5 Keypad 0-9, *, # 11 Memory button 6 Mute button... -
Page 5: Base Unit
AUDIOLINE 20 OUTLOOK BASE UNIT 1 Line cord outlet (on the backside) 5 In use LED 2 Power supply outlet (on the backside) 6 Charging LED 3 Antenna 7 Page button 4 Charging contacts... -
Page 6: Installation
INSTALLATION AUDIOLINE 20 UNPACKING In the box you should find the following items: Handset Power supply Base unit Line cord 3 NiMh batteries (re-chargeable types) User guide Belt clip LOCATING THE BASE UNIT Place the unit close to a telephone network socket and a 13 Amp mains socket. Do not locate in: direct sunlight, damp or high humidity locations. -
Page 7: Battery
From new, the batteries (supplied) must be charged for 15 hours without interruption. Use only DORO original batteries. The guarantee will be invalid if any problems arise as a result of the use of an incorrectly specified battery. CHARGING THE BATTERIES From new, the batteries (supplied) must be charged for 15 hours without interruption. -
Page 8: Battery Indicator
INSTALLATION AUDIOLINE 20 BATTERY INDICATION When the battery is empty, calls cannot be made or received. There is a bettey indictor in the handsets display. When the battery is nearly empty the indicator will the indicator look like this and a warning tone will be heard. -
Page 9: The Display
AUDIOLINE 20 HANDHAVANDE THE DISPLAY Battery status Ongoing call Mute Programming Memory Keypad lock Numeric/Alpha display Indicator Function Memory - Flashes when storing a memory number. - is on when dialling with the memory. Mute - Is on when the mute function is activated. -
Page 10: To Answer
AUDIOLINE 20 ANSWERING INCOMING CALLS When an external call is received, the base unit will ring first and then the handset. You can change the ring signal, see pages 14-15. According to the cordless connection between the handset and base unit can the ringsignal be deleay. -
Page 11: Last Number Redial
AUDIOLINE 20 LAST NUMBER REDIAL The last dialled number are stored automatically in the memory. The number can be re- dialled as required. Press button, the number you will be visible on the display. Press the Talk/End button, the phone will automatically dial the number. -
Page 12: Memory
AUDIOLINE 20 INDIRECT MEMORY Ten of your most frequently used telephone numbers can be stored in the direct memory, using the keypad digits 0-9 as the storage locations. STORE INDIRECT MEMORIES Press the programming button , and then the button. The display show "SEL LocAtion". -
Page 13: Mute Button
AUDIOLINE 20 MUTE If during a telephone conversation, you wish to talk privately to a third party without the caller overhearing: Press the button (the mute symbol will appear on the display). To resume the conversation, press the button again. -
Page 14: Additional Network Service
AUDIOLINE 20 ADDITIONAL NETWORK SERVICE... - Page 15 AUDIOLINE 20...
-
Page 16: Settings
SETTINGS AUDIOLINE 20 HANDSET KEYPAD SOUND From new, the handset keypad is programmed to emit a confirmation beep every time a key is pressed. This beep can be turned on or off as desired. Press the Press 1. the display show "Pro-tonE" and "on" or "oFF" depending on topically setting. -
Page 17: Ringsignal Level
AUDIOLINE 20 SETTINGS RING SIGNAL LEVEL You can change the ringer volume level in three levels: off, low and high. Press the Press digit 3 . The display show "Pro-ring" and the topically level (Hi, Lo or oFF). Select a level using digits 1 several times. -
Page 18: Direct Call/Baby Call
SETTINGS AUDIOLINE 20 DIRECT CALL/BABY CALL This feature enables the handset to be pre-programmed with an emergency number which can be dialled automatically by pressing any button (except the programming button). It is still possible to answer calls even if this feature is implemented. -
Page 19: Call Barrier
AUDIOLINE 20 OTHER CALL BARRIER The phone have a call barrier there you can "lock" the phone for different types of outgoing calls. You barrie the first digits in the number you which to barrie. Ex 00 for international calls. To activate or deactivate this function must you know the handset PIN- code (see page 16). -
Page 20: Other
OTHER AUDIOLINE 20 TROUBLE GUIDE THE TELEPHONE DOES NOT WORK Is the power adapter connected correctly? Is the line cord connected correctly? Are the batteries in the handset charged? Connect a different telephone to the same wall socket. If the other telephone does not work, contact your Network operator. -
Page 21: Erase The Unit
AUDIOLINE 20 OTHER MEMORY DIALLING DOES NOT WORK Store a new number and try again. RESET THE HANDSET The handset can be reset if required. If this operation is performed all factory settings will be restored. Handset PIN-code restored to 0000... -
Page 22: Warantee
OTHER AUDIOLINE 20 WARENTEE TECHNICAL DATA Standby time About 110 hour Talk time About 4 hour Range >300 meter. Indirect memories 10 pcs Power AC/DC adapter: 2 x 9V DC, 200 mA. Battery 3 x 1.2V NiMH type. Wiegth Handset : About156 g (Ink. batteries) -
Page 23: Declaration Of Conformity
Date of issue:2000-05-24 Copies of this document will be held on file for a period of 10 years after the last production. Supplier: DORO AB, Skiffervägen 80, SE-224 78 LUND, SWEDEN Product: AUDIOLINE 20 This product is intended for connection to analogue PSTN lines within Switzerland.
