Machine Parts - Husqvarna Viking Rose 605 User Manual

Summary
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
1. Door
2. Thread take-up lever
3. Presser foot pressure dial
4. Thread guide
5. Buttonhole sensor socket
6. Light
7. Needle bar
8. Presser foot
9. Free arm
10. Bobbin cover
11. Base plate
12. Drop feed dial
13. Needle plate
14. Presser bar and Presser foot
ankle
15. Needle clamp screw
16. Thread tension discs
17. Thread tension dial
18. Thread guide for bobbin
winding
4
17.
19.
18. 20.
16.
15.
14.
13.
12.
19. Spool pin
20. Spool holders
21. Recess for additional spool pin
22. Quick-info
23. Thread cutter for bobbin
winding
24. Handwheel
25. Bobbin spindle, Bobbin stop
26. Infodisplay
27. Function selectors
28. Function selectors Embroidery
29. Stitch selectors
30. Embroidery card socket
31. Main power switch,
Connection to power supply
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
Instruction book Rose
