Ei Electronics Ei175 Ionisation Specification

MAINS POWERED 230V~
For the deaf and hard of hearing
Model Ei 175 Ionisation
Complete smoke alarm system
•
• Includes high intensity strobe, ionisation smoke
alarm and vibration pad
Rechargeable battery back up
•
Test button
•
Continuous monitoring of wiring
•
Interconnectable to other Ei alarms
•
• Auxiliary sockets
• Low power cell warning
Complies with BS415:1990 electrical safety
•
5 year guarantee
•

Product Description

The Ei175 is a complete smoke alarm system designed
for the deaf and hard of hearing. The system includes
the Ei173 control panel, Ei174 vibrating pad and
Ei100CD ionisation smoke alarm.
The Ei173 control panel includes a high intensity Xenon
strobe, a sealed lead-acid rechargeable battery for
standby use in the event of mains failure and all the
required circuitry to connect to the Ei100CD smoke alarm
and Ei174 vibrating pad
The Ei173 control panel also incorporates a Test button
and circuitry to continuously monitor the system wiring
The Ei174 vibrating pad is designed to be placed under
the mattress or pillow to waken people who fail to
respond to the strobe alarm
Up to 11 other smoke/heat alarms (Ei100C/105C/103C)
can be interconnected to the master smoke alarm
Ei100CD. The smoke alarms are all powered from the
control panel and in the event of mains failure the
rechargeable battery in the panel will power the entire
system, including the smoke alarms, for one week.
Operation
The green indicator will illuminate to show mains power
•
is present
• The red indicator will flash once every second to show
that the mains supply is off and the system is running
on battery backup power
The red indicator will go off as the battery becomes
•
depleted (with mains off)
• The slide switch on the control panel disconnects mains
and battery power from the control panel and
extinguishes both LED indicators
The "Test" button will check the strobe, vibration pad
•
and panel
• When the Ei100CD ionisation smoke alarm is activated,
the Ei173 control panel will flash the strobe at 1Hz and
activate the vibrating pad
The interconnect wiring from the smoke alarm to the
•
control panel is monitored so that if the smoke alarm is
not connected or if it is open/short circuit, then the
strobe will flash and the vibrating pad will turn on
• An auxiliary socket allows the connection of an extra
strobe or vibrating pad
