ProForm 615 T Treadmill User Manual page 8

2. See the inset drawing. Cut the plastic tie near
the Upright Wire (87).
Attach a Wheel (96) to the Base (95) with a 3/8"
x 2" Bolt (8) and a 3/8" Nut (10). Do not over-
tighten the Nut; the Wheel must turn freely.
Press a Base Cap (89) into the Base (95).
3. Identify the Right Upright (85). Hold the Right
Upright near the Base (95) as shown.
See the inset drawing. Tie the wire tie in the
Right Upright (85) securely around the end of the
Upright Wire (87). Then, pull the other end of the
wire tie until the Upright Wire is routed through
the Right Upright.
2
Plastic Tie
8
96
10
3
87
Wire Tie
85
Wire
Tie
87
8
87
95
Cut
87
85
89
95
