USER'S MANUAL
Model No. PFTL59511.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts
are damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
CALL TOLL-FREE:
1-888-533-1333
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.proformservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 615 T Treadmill and is the answer not in the manual?

Questions and answers

Related Manuals for ProForm 615 T Treadmill

Summary of Contents for ProForm 615 T Treadmill

  • Page 1 USER’S MANUAL Model No. PFTL59511.0 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CONTACT THE STORE; please contact Customer Care.

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decals may not be shown at actual size. PROFORM is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    4. The treadmill is intended for home use only. PROFORM dealer, call the telephone number Do not use the treadmill in any commercial, on the front cover of this manual, or see your rental, or institutional setting.
  • Page 4 20. The heart rate monitor is not a medical 24. Do not change the incline of the treadmill by device. Various factors, including the user’s placing objects under the treadmill. movement, may affect the accuracy of heart rate readings. The heart rate monitor is 25.

  • Page 5: Before You Begin

    Thank you for selecting the revolutionary PROFORM reading this manual, please see the front cover of this ® 615 T treadmill. The 615 T treadmill offers an impres- manual. To help us assist you, please note the product sive selection of features designed to make your model number and serial number before contacting us.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • To hire an authorized service technician to • To identify small parts, see page 6. assemble the treadmill, call 1-800-445-2480. • Assembly requires the following tools: • Assembly requires two persons. • the included hex key • Place all parts in a cleared area and remove the packing materials.
  • Page 8 2. See the inset drawing. Cut the plastic tie near the Upright Wire (87). Plastic Tie Attach a Wheel (96) to the Base (95) with a 3/8" x 2" Bolt (8) and a 3/8" Nut (10). Do not over- tighten the Nut; the Wheel must turn freely. Press a Base Cap (89) into the Base (95).
  • Page 9 4. Hold the Right Upright (85) against the Base (95). Be careful not to pinch the Upright Wire (87). Insert two 3/8" x 4" Screws (7) with two 3/8" Star Washers (11) and a 3/8" x 1 1/2" Screw (14) with a 3/8" Star Washer (11) into the Right Upright.
  • Page 10 6. Hold the Left Upright (84) against the Base (95). Insert two 3/8" x 4" Screws (7) with two 3/8" Star Washers (11) and a 3/8" x 1 1/2" Screw (14) with a 3/8" Star Washer (11) into the Left Upright.
  • Page 11 8. Set a Handrail (80) onto the Right Upright (85). Make sure that the Upright Wire (87) is not pinched. Attach the Handrail (80) with two 5/16" x 2" Screws (4) and two 5/16" Star Washers (13). Start both Screws before tightening them. Attach the other Handrail (not shown) in the same way.
  • Page 12 10. With the help of a second person, hold the con- sole assembly near the Right Upright (85). Console Assembly Connect the Upright Wire (87) to the console wire. See the inset drawing. The connectors should slide together easily and snap into place.
  • Page 13 12. IMPORTANT: To avoid damaging the Crossbar (93), do not use power tools and do not overtighten the #10 x 3/4" Screws (2). Tighten four #10 x 3/4" Screws (2) with four 1/4" Star Washers (12) into the Crossbar (93) and the Handrails (80).
  • Page 14 14. Identify the Left and Right Handrail Covers (83, 86). Console Assembly Slide the Left Handrail Cover (83) up against the console assembly and tighten a #8 x 3/4" Screw (1) into the bottom of the Cover. Be careful not to overtighten the Screw.

  • Page 15: Operation And Adjustment

    OPERATION AND ADJUSTMENT HOW TO CONNECT THE POWER CORD nominal 120-volt circuit capable of carrying 15 or more amps. To avoid overloading the circuit, do Use a Surge Suppressor not plug other electrical devices, except for low- power devices such as cell phone chargers, into Your treadmill, like other electronic equipment, can be the surge suppressor or into an outlet on the same circuit.
  • Page 16 CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the console’s stereo sound system The treadmill console offers an impressive array of while you exercise. features designed to make your workouts more effec- tive and enjoyable.
  • Page 17 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
  • Page 18 5. Follow your progress with the displays. When an iFit module is connected to iFit.com, the iFit symbol will light. The matrix—When you select the manual To reset the displays, press the Stop button, re- mode, the matrix will move the key, and then reinsert the key. display a track that rep- resents 1/4 mile (400 6.
  • Page 19 HOW TO USE AN ONBOARD WORKOUT The workout will continue in this way until the last segment of the profile flashes in the display and the 1. Insert the key into the console. last segment ends. The walking belt will then slow to a stop.
  • Page 20 HOW TO USE AN IFIT WORKOUT For more information about the iFit workouts, please see www.iFit.com. Note: To use an iFit workout, you must have an optional iFit module. To purchase an iFit module at When you select an iFit workout, the display will any time, go to www.iFit.com or call the telephone show the name, duration, maximum speed setting, number on the front cover of this manual.
  • Page 21 HOW TO USE THE STEREO SOUND SYSTEM DEMO MODE—The console features a display demo mode, designed to be used if the treadmill To play music or audio books through the console’s is displayed in a store. While the demo mode is stereo speakers, you must connect your iPod, MP3 turned on, the console will function normally when player, CD player, or other personal audio player to the...

  • Page 22: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to the lowest position before you fold the treadmill. left.

  • Page 23: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by follow- d. If the treadmill still will not run, please see the front ing the simple steps below. Find the symptom that cover of this manual. applies, and follow the steps listed. If further assis- tance is needed, see the front cover of this manual.
  • Page 24 Remove the three #8 x 3/4" Screws (1) and care- recalibrate the incline system. If the incline does not fully pivot the Motor Hood (62) off. begin calibrating, press the Stop button again, and then press the Incline increase or decrease button again.
  • Page 25 SYMPTOM: The walking belt is off-center or slips b. If the walking belt slips when walked on, first when walked on remove the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller a. If the walking belt is off-center, first remove the screws clockwise, 1/4 of a turn.

  • Page 26: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 27: Part List

    PART LIST Model No. PFTL59511.0 R0812B Key No. Qty. Description Key No. Qty. Description #8 x 3/4" Screw #8 x 1" Screw #10 x 3/4" Screw Right Foot Rail #8 x 1/2" Screw Frame 5/16" x 2" Screw Roller Bracket #8 x 1"...

  • Page 28: Exploded Drawing

    EXPLODED DRAWING A Model No. PFTL59511.0 R0812B...
  • Page 29 EXPLODED DRAWING B Model No. PFTL59511.0 R0812B...
  • Page 30 EXPLODED DRAWING C Model No. PFTL59511.0 R0812B...
  • Page 31 EXPLODED DRAWING D Model No. PFTL59511.0 R0812B...

  • Page 32: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
