8. Set a Handrail (80) onto the Right Upright (85).
Make sure that the Upright Wire (87) is not
pinched.
Attach the Handrail (80) with two 5/16" x 2"
Screws (4) and two 5/16" Star Washers (13).
Start both Screws before tightening them.
Attach the other Handrail (not shown) in the
same way. Note: There is no wire on the left
side.
Remove and discard the two indicated screws
(A) from both Handrails (80) (only one is shown).
9. Set the console assembly face down on a soft
surface to avoid scratching the console assem-
bly. Remove the 1/4" x 1/2" Screws (9). Do not
discard the Screws; the Screws will be used
in assembly step 11.
Identify the Left Tray (61) with the writing on the
bottom. Attach the Left Tray with four #8 x 1/2"
Screws (3). Start all four Screws before tighten-
ing them. Be careful not to overtighten the
Screws.
Attach the Right Tray (50) in the same way.
8
80
9
9
11
4
13
A
87
3
3
3
61
3
Console
Assembly
9
85
50
