Model No. PFTL43105.0
Serial No.
USER'S MANUAL
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if parts are
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT DI-
RECTLY.
CALL TOLL-FREE:
1-888-533-1333
Mon.–Fri., 6 a.m.–6 p.m. MST
ON THE WEB:
www.proformservice.com
CAUTION
Visit our website at
Read all precautions and instruc-
tions in this manual before using
www.proform.com
this equipment. Save this manual
new products, prizes,
for future reference.
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 595Pi and is the answer not in the manual?

Questions and answers

Related Manuals for Pro-Form 595Pi

Summary of Contents for Pro-Form 595Pi

  • Page 1 Model No. PFTL43105.0 Serial No. USER'S MANUAL Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if parts are damaged or missing, PLEASE CONTACT OUR CUSTOMER SERVICE DEPARTMENT DI- RECTLY.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............3 BEFORE YOU BEGIN .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure free telephone number on the front cover of that all users of this treadmill are adequately this manual and order part number 146148, or informed of all warnings and precautions.
  • Page 4 20. When folding or moving the treadmill, make maintenance and adjustment procedures de- sure that the storage latch is fully closed. scribed in this manual. Never remove the motor hood unless instructed to do so by an 21. Inspect and properly tighten all parts of the authorized service representative.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new PROFORM ® 595 Pi number and serial number before calling. The model treadmill. The 595 Pi treadmill offers an impressive se- number of the treadmill is PFTL43105.0. The serial lection of features designed to make your workouts at number can be found on a decal attached to the tread- home more effective and enjoyable.

  • Page 6: Assembly

    ASSEMBLY To hire an authorized service technician to assemble the treadmill, call toll-free 1-800-445-2480. Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials; do not dispose of the packing materials until assembly is completed. Note: The underside of the walking belt is coated with high-performance lubricant.
  • Page 7 2. Orient the Right Upright (36) so the square hole near the lower end is in the position shown. Attach the Right Upright to the Upright Base (48) with two Upright Bolts (40) and two Upright Star Washers (39). Do not tighten the Upright Bolts yet.
  • Page 8 5. Identify the Right Handrail Endcap (91), which does not have a cutout in the bottom, and slide it onto the lower end of the Right Handrail (11). Make sure that the screw hole in the Right Handrail Endcap is at the bottom. Next, hold the Right Handrail near the Right Upright (36), and insert the Wire Harness (28) into the hole in the bottom of the Handrail and out of the indicated hole in the top.
  • Page 9 8. Lower the Uprights (31, 36) until the Handrails (11, 18) are touching the floor. 31, 36 See the lower drawing. Position the Uprights (31, 36) so the treadmill Frame (74) is centered between them. Firmly tighten the four Upright Bolts (40) and the two 11, 18 Frame Bolts (32).
  • Page 10 10. Remove the knob from the pin. Make sure that the collar and the spring are on the pin as shown. Insert the pin into the Latch Housing (30), and tighten the knob back Knob onto the pin. Spring Collar 11.

  • Page 11: Operation And Adjustment

    OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT tric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. Plug the power cord into a surge suppressor, Your treadmill features a walking belt coated with high- performance lubricant.
  • Page 12 CONSOLE DIAGRAM Note: If there are thin sheets of plastic Clip on the console, remove the plastic. FEATURES OF THE CONSOLE HOW TO TURN ON THE POWER The treadmill console offers an array of features de- Plug in the power cord (see signed to make your workouts more effective.
  • Page 13 Change the incline of the treadmill as desired. HOW TO USE THE MANUAL MODE To change the incline of Insert the key into the console. the treadmill, press the Incline increase and de- crease buttons. Each time See HOW TO TURN ON THE POWER on page a button is pressed, the incline setting will change by 0.5%;...
  • Page 14 To reset the displays, press the Stop button, re- Turn on the fan if desired. move the key, and then reinsert the key. To turn on the fan, press the Fan button. To turn Measure your heart rate if desired. on the fan at high speed, press the button a sec- ond time.
  • Page 15 When the first period is completed, all speed set- HOW TO USE A TRAINER PROGRAM tings will move one column to the left . The speed setting for the second period will then be shown in the flashing Current Period column and the tread- Insert the key into the console.
  • Page 16 the matrix. (The incline settings are not shown in HOW TO CREATE A CUSTOM PROGRAM the matrix.) To program a speed setting and an in- cline setting for the first period, simply adjust the speed and incline of the treadmill as desired by Insert the key into the console.
  • Page 17 When only three seconds remain in the first period HOW TO USE A CUSTOM PROGRAM of the program, both the Current Period column and the column to the right will flash, a series of Insert the key into the console. tones will sound, and the speed setting and the in- cline setting will flash.
  • Page 18 THE INFORMATION MODE/DEMO MODE An “E” for English miles or an “M” for metric kilometers will The console features an information mode that keeps appear in the Speed display. track of the total number of miles or kilometers that the Press the Speed increase but- walking belt has moved and the total number of hours ton to change the unit of mea-...

  • Page 19: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be per- manently damaged. Next, unplug the power cord. CAUTION: You must be able to safely lift 45 pounds (20 kg) to raise, lower, or move the treadmill.
  • Page 20 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the treadmill with your right hand as shown. Pull the latch knob to the left and hold it. Pivot the treadmill down until the frame is past the latch pin. Storage Latch 2.

  • Page 21: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call the toll-free telephone number on the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 22 c. Locate the Reed Switch (63) and the Magnet (67) on the left side of the Pulley (64). Turn the Pulley until the Magnet is aligned with the Reed Switch. Make 1/8” sure that the gap between the Magnet and the Reed Switch is about 1/8”.

  • Page 23: Conditioning Guidelines

    CONDITIONING GUIDELINES begin to use stored fat calories for energy. If your goal WARNING: is to burn fat, adjust the speed and incline of the tread- Before beginning this mill until your heart rate is near the lowest number in or any exercise program, consult your physi- your training zone.

  • Page 24: Ground Wire

    PART LIST—Model No. PFTL43105.0 R0805A Key No. Qty. Description Key No. Qty. Description Hood Lift Frame Washer 3/4” Screw Lift Frame Bolt Left Foot Rail 3/8” Nut Foot Rail Screw Lift Motor Motor Tension Bolt Stop Bracket Motor Tension Washer Incline Motor Bolt, Top Motor Star Washer Incline Motor Bolt, Bottom...

  • Page 26: How To Order Replacement Parts

    HOW TO ORDER REPLACEMENT PARTS To order replacement parts, see the front cover of this manual. To help us assist you, please be prepared to give the following information: • the MODEL NUMBER of the product (PFTL43105.0) • the NAME of the product (PROFORM 595 Pi treadmill) •...
