RDS634UA
MP3-Compatible FM CD Receiver
U S E R ' S M A N U A L
7606 (RDS 634UA)-IM.indd 1
CONTENTS
12/12/06 12:29:33 PM
2
3
4
4
5
5
6
7
8
8
10
11
11
12
13
14
15
16


Advertisement

Table of Contents
loading

Related Manuals for Boss RDS634UA

Summary of Contents for Boss RDS634UA

  • Page 1: Table Of Contents

    RDS634UA MP3-Compatible FM CD Receiver U S E R ’ S M A N U A L CONTENTS Installation DIN front-mount installation DIN rear-mount installation Removing the head unit Detaching the front panel Replacing the front panel General controls Radio controls...

  • Page 2: Installation

    7606 (RDS 634UA)-IM.indd 2 12/12/06 12:29:34 PM...

  • Page 3: Din Front-Mount Installation

    7606 (RDS 634UA)-IM.indd 3 12/12/06 12:29:35 PM...

  • Page 4: Din Rear-Mount Installation

    Before removing the bezel, press the OPEN button to remove the front panel. pull to remove the front panel move left Press OPEN Button to flip down front panel the front panel 7606 (RDS 634UA)-IM.indd 4 12/12/06 12:29:37 PM...

  • Page 5: Detaching The Front Panel

    Press the OPEN button, let the Front Panel arrive in horizontal position and detach the panel by pulling it towards you as illustrated. Press OPEN Button to flip down front panel the front panel move left pull to remove the front panel 7606 (RDS 634UA)-IM.indd 5 12/12/06 12:29:38 PM...

  • Page 6: Front Panel Controls

    Front panel controls GENERAL CONTROLS POWER Press any button to turn unit ON. To turn head unit off, press and hold POWER. OPEN Press to flip down the front panel. DSP When this key is pressed, it is operated as the conversion of each display mode as follow.

  • Page 7: Radio Controls

    RADIO CONTROLS AS/PS Select six strong stations and store them in current band. 1. Select a band (if needed) 2. Hold A/PS button for more than three seconds. The new stations replace stations already stored in that band. Preset Scan Scan stations stored in current band 1.

  • Page 8: Audio Controls

    Front panel controls AUDIO CONTROLS EQ Press repeatedly to cycle through five modes: POP M, ROCK M, CLASS, FLAT M or DSP OFF. SUB Press and hold to engage subwoofer output. MUTE Press to silence the receiver. Press again to return to normal operation.
  • Page 9 RDS CONTROLS TA When pressed short, it is activated as TA mode on or off When TA mode is on and traffic announcement is transmitted – When the unit is it CD/MP3 mode, it will switch to radiomode temporarily. – If the volume level was under the threshold point, it will be raised to the threshold point. –...

  • Page 10: Cd/Mp3 Playback Controls

    CD/MP3 PLAYBACK CONTROLS +10 10 TRACK UP SELECT: TUNE/TRACK BUTTONS Press and release (In case of MP3 files) to advance to next track or to return to the beginning of the current track (track -10 10 TRACK DOWN SELECT: number will be displayed). Press and hold 2 sec.

  • Page 11: How To Select Mp3 Files

    Front panel controls How to select MP3 files Searching Track: • Press “AS/PS”, then search track is activated. • Press “AUDIO” button, then the first digit will flash. • Rotary “VOL knob to right or left”, select first digit desired. • Press “AUDIO”...

  • Page 12: Usb And Front Side Aux In Operations

    USB and front side AUX IN operations USB Port Enhanced control of connected Portable Media such as Flash Drives and digital MP3 Players, by using function keys on the main unit or the remote control unit. This unit features the latest ID3 Tag support, which allows you to see the song’s name and which folder it’s located in, on the LCD display.

  • Page 13: Remote Control Functions

    Remote controls functions POWER Use to turn the CD receiver ON or OFF SEL Turning the VOL knob Right or Left, you can adjust VOL/BASS/TREB/BAL/FAD. To select other functions, press the SEL button shortly until the desired functions is shown on the display. VOLUME Use to increase or decrease volume level.

  • Page 14: Wiring Diagram

    Electrical connections LINE OUT (FRONT) ISO CONNECTOR L (WHITE) R (RED) LINE OUT ANTENNA (REAR) L (WHITE) R (RED) CONNECTOR LINE IN L (WHITE) R (RED) SUB WOOFER CONNECTOR A CONNECTOR B 4. CONSTANT +12V 1. REAR RIGHT SPEAKER (+) 5.

  • Page 15: Troubleshooting

    7606 (RDS 634UA)-IM.indd 15 12/12/06 12:29:50 PM...

  • Page 16: Specifications

    Specifications RDS634UA MP3-Compatible FM CD Receiver CD/MP3 PLAYER > 60dB Signal to Noise Ratio Channel Separation > 45 dB Frequency Response 20Hz - 20 kHz RADIO FM Section: Frequency range 87.5-108 MHz Intermediate frequency 10.7 MHz 3 µV Sensitivity Stereo separation 30 dB Signal to noise ratio 50 dB 50 kHz Channel step...
